LIBERTY SERIES™

ALUMINUM SOLID RAMP INSTALLATION MANUAL

PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL

Table of Contents

Need help?

Do you have a question about the Liberty Series and is the answer not in the manual?

Questions and answers

Summary of Contents for National ramp Liberty Series

Page 3 In the event that the installer does not do so, any warranty issued by National Ramp shall be considered to be void and liability for the results of the installer’s failure in this regard or any malfunction of the equipment resultant therefrom shall be solely borne by the installer.
Page 4: Table Of Contents
Contents 1. Welcome 2. Guide to the Liberty Series™ Installation Manual 3. Quick Install Guide 4. Ramp Terminology 5. Ramp System Components 6. Hardware Kit Components 7. ADA Guidelines and Local Code EVALUATION OVERVIEW 8. Common Ramp Configurations 9. Correct Incline Determination 10.
Page 5 20. Layout Configuration 1 | 90° Turn 21. Layout Configuration 2 | Switchback Ramp RAMP MAINTENANCE AND CARE 22. Liberty Series Warranty 23. Liberty Series Maintenance And Care 24. Warranty Registration [ 5 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 6 [ 6 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 7: Welcome
1. Welcome Thank you for your interest in the Liberty Series™ ramp. This installation manual will review everything you need to know for a successful ramp installation. We have laid out step-by-step instructions as well as start-to- finish guides for your reference.
Page 8: Guide To The Liberty Series™ Installation Manual
Table of Contents to guide you to your answers. The manual starts with a quick install guide, a top-level look at the Liberty Series™ installation process. Then, a glossary of terms for the ramp process and an overview of the ramp safety guidelines laid out by the Americans with Disabilities Act.
Page 9: Quick Install Guide
14. Install the Ramp and Platform Brackets, end loops, leg caps, and other miscellaneous items. 15. Lastly, do a final safety check to ensure all hardware is tight, and there are no exposed sharp edges or burrs that could hurt someone. [ 9 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 10: Ramp Terminology
UPGRADE  an upward slope of the ground, from the ramp’s start to its end. If the measured ƒ height at the ramp’s ending is less than the measured height at the start, that property has an upgrade. [ 10 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 11 THRESHOLD RAMP  a ramp without handrails, used to provide a smooth transition over short elevations, including door thresholds or steps. [ 11 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 12: Ramp System Components
A list of all components, with brief descriptions of each item’s use, begins on page 14. image 1 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTAL [ 12 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 13 2 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL [ 13 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 OF NATIONAL RAMP.
Page 14 OF NATIONAL RAMP. 3.MAXIMUM CROSS SLOPE-1:48 (1/4''/FOOT) SHARED, MODIFIED, DISTRIBUTED, REPRODUCED, OR your ramp system. They can create a solid surface at The standard Liberty Series™ ramp section is 36” wide. REUSED WITHOUT THE EXPRESS WRITTEN PERMISSION Scale: Sheet of 4.ALL RAMPS &...
Page 15 The picket on a ramp handrail are angled, so they will be straight railings on a platform handrail are straight. when installed on a ramp with a 4.8° slope. [ 15 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 16 Sheet of 4.ALL RAMPS & PLATFORMS 36'' AND OVER ELEVATION REQUIRE CROSS BRACING OF NATIONAL RAMP. OF NATIONAL RAMP. Made to connect with the Liberty Series , the step Made to connect with the Liberty Series , the gate system can provide an alternate exit off the ramp for...
Page 17 Placed on top of each leg to prevent anyone from or TTP at the top of a ramp starting at the door, or cutting themselves on the leg. instead of end loops if requested. [ 17 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 18 OF NATIONAL RAMP. OF NATIONAL RAMP. A piece used to create a continuous toe guard on A piece used to fill in handrails on 5'x5' turn platforms, platforms where needed. or in switchback platforms. [ 18 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 19 Used to fasten the TTP into place, the legs into the Used to secure legs and handrails to the universal universal bracket, toe guards to the platform, and the bracket. Ramp and Platform Bracket into place. [ 19 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 20: Hardware Kit Components
4.ALL RAMPS & PLATFORMS 36'' AND OVER ELEVATION REQUIRE CROSS BRACING Scale: Sheet of 4.ALL RAMPS & PLATFORMS 36'' AND OVER ELEVATION REQUIRE CROSS BRACING Scale: Sheet of OF NATIONAL RAMP. OF NATIONAL RAMP. [ 20 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 21 2464 Platform Toe Guard Corner Cover (per each) 2465 New Plastic Elbow Connector (ea) 2470-01 36" Handrail Filler Pipe (1.5"OD) - per each 8581 #10 x 3/4" Phillips Pan Driller 8781 [ 21 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 22 3/8"-16 ***Large Flange*** Serrated Flange Nut 8626 3/8"-16 x 1-1/4" Hex Head Bolt 8627 3/8"-16 x 2.5" Hex Head Bolt 8821 1/4"-20 Nut 8823 1/4" SAE Washer 8824 8825 1/4"-20 Acorn Nut (1/4" thread) [ 22 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 23 3/8"-16 x 5" Hex Head Bolt 8823 1/4"-20 Nut 8824 1/4" SAE Washer 1/4"-20 Acorn Nut (1/4" thread) 8825 DISCLAIMER: Parts and hardware are subject to change without notice. Please contact National Ramp for any questions. [ 23 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 24: Ada Guidelines And Local Code
This guideline is to ensure the slope of the ramp is not too steep for safe passage. ƒ National Ramp recommends no greater than a 1:8 pitch/6.4˚ slope, and only for users ƒ in a power wheelchair or manual wheelchair being pushed up the ramp by a caretaker.
Page 25 Grass and dirt aren’t recommended for a landing surface where it can be avoided. Landing pads are available by National Ramp to provide a safe landing surface where needed.
Page 26 [ 26 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 27: Evaluation Overview
EVALUATION OVERVIEW [ 27 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 28: Common Ramp Configurations
5'x5' platform can make a by 180°. This configuration maximizes the amount of right turn, or function as a rest platform. ramping that can fit onto the property. [ 28 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 29 ADA guidelines. A platform that changes the OF NATIONAL RAMP. ramp’s direction by 90° or 180° also functions as a rest platform. In the pictured diagram, the rest platform is in the middle of the 30' run. [ 29 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 30: Correct Incline Determination
28" 15.0˚ 13.5˚ 30" 14.5˚ INCLINE CHART * This chart is provided as a resource only and National Ramp assumes no responsibility for determining a safe ramp incline on any specific ramp. [ 30 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 31: Evaluation Process
Measure the starting height, including door thresholds, and then measure the height from the door threshold to the ending point (use of the laser level is strongly advised). [ 31 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 32 Screen door vs. inset door: For a screen door, the ramp cannot impede with the ability to ƒ open and close the door. For an inset door, you need a smooth transition between the ramp and door. [ 32 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 33: Considerations For Bariatric Ramps
11. Considerations for Bariatric Ramps The Liberty Series™ system is available in two widths: 36" and 48". The 36" wide standard ramping has a weight capacity of 1,000 lbs, and the 48" wide bariatric ramping has a weight capacity of 1,200 lbs.
Page 34: Measuring A Ramp
Porch Width Door to Corner of Porch Porch Depth Porch to Corner of House Rise at Porch Porch to Driveway Width of Steps House to Sidewalk Rise of Steps (Total) Porch to Sidewalk [ 34 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 35: Drawing Your Configuration
5’ x 5’ 5’ 5’ 3’ lamp post Lawn NOTES: National Ramp. All rights reserved. 709 Executive Blvd., Unit A, Valley Cottage, NY 10989 USA. Customer Service: 877-884-RAMP(7267) | Fax: 845-358-1469 | sales@nationalramp.com [ 35 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 36 5’x4’ 4’x5’ level level 5’x8’ platform platform NOTES: National Ramp. All rights reserved. 709 Executive Blvd., Unit A, Valley Cottage, NY 10989 USA. Customer Service: 877-884-RAMP(7267) | Fax: 845-358-1469 | sales@nationalramp.com [ 36 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 37: Grade Variations
UPGRADE  upward slope of the ground DOWNGRADE  downward slope of the ground CROSS SLOPE  change in slope that runs across the width of the ramp [ 37 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 38 [ 38 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 39: Overview Of The Liberty Series™ System
OVERVIEW OF THE LIBERTY SERIES™ SYSTEM [ 39 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 40: Liberty System
2. 5'x5' Turn Platform 8. Section Handrails 3. T-Post 9. Bottom Transition Plate (BTP) 4. Ramp Sections 10. Landing Pad 5. 5'x5' Turn Platform 11. End Loops 6. Legs 12. Filler Pipe [ 40 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 41 FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL 1. Elbows 2. Celebration Footer Pads™ 3. Leg Caps 4. End Caps 5. Corner Cover 6. Universal Brackets 7. Bottom Transition Plate (BTP) [ 41 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 42 The Liberty Series™ ramp system is made from 100% aluminum, with a slip-resistant surface. The system connects through a tongue and groove system. PLATFORM Tongue Tongue Groove Groove image 6 DATE FRACTIONAL PROPRIETARY AND CONFIDENTIAL APPLICATION RAMP Bottom Tongue Groove image 7 1.
Page 43 Place all handrails next to each platform and ramp section. Place all hardware bags on each section or platform. Confirm that all components are on-site and undamaged. Complete any needed site prep. [ 43 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 44 ƒ Tape Measure ƒ 3/16" and 5/32" Allen Keys ƒ Pipe Cutter for 1 1/2" tubing ƒ Sanding/Filing Tool/Deburring Tool ƒ Sawhorses or other portable workbench ƒ String ƒ www.nationalramp.com | 877-884-RAMP(7267) [ 44 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 45: Celebration Footer Pad™ Use
8 DRAWN When a leg is going to rest on a Footer Pad or paver stone, the leg height will be measured to the Footer Pad, and not to the ground. [ 45 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 46: Leg Placement
3 sides. on 3 sides. on 3 sides. 4' x 4' 4' x 4' LEVEL LEVEL PLATFORM PLATFORM 4' x 4' LEVEL PLATFORM [ 46 ] NATIONAL RAMP™ | FREEDOM NOW [ 46 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 47 PLATFORM LEGS LEGS TONGUE TONGUE SWITCHBACK BRACKET SWITCHBACK BRACKET [ 47 ] [ 47 ] Liberty Series™ Ramp Installation Guide-Revision 4/1/2020 Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 48 | 877-884-RAMP(7267) [ 48 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 49: Ramp Install
RAMP INSTALL [ 49 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 50: Step-By-Step
(or ramp section) should be below the door threshold allowing the door to open without interference. CORRECT INSTALL image 9 ACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL www.nationalramp.com | 877-884-RAMP(7267) [ 50 ] NATIONAL RAMP™ | FREEDOM NOW OF NATIONAL RAMP.
Page 51 OF NATIONAL RAMP. Mount the handrails, hand-tightening the bolts to allow for later adjustments. 18.1.3. Insert universal bracket and mount T-Post if ramp is starting with a turn platform. 18.1.4. image 11 [ 51 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 52 Select the shortest leg that is at least 2" above the measured height. 18.1.7. 8" 6" image 13 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL www.nationalramp.com | 877-884-RAMP(7267) [ 52 ] NATIONAL RAMP™ | FREEDOM NOW OF NATIONAL RAMP.
Page 53: Installing A Platform
CEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. image 15 [ 53 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL...
Page 54 (1/4" per foot) to allow for rain runoff. Height to set leg from travel surface to ground image 17 Pro je c t: www.nationalramp.com | 877-884-RAMP(7267) [ 54 ] NATIONAL RAMP™ | FREEDOM NOW C usto m e r:...
Page 55 18.2.6. Any edge without a toe guard requires a toe guard installation. The toe guard is affixed to the platform with two pan head driller screws. image 18 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONA [ 55 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 56: Installing A Ramp Section
Ramp sections of 2', 3', 4', 5', and 6' will need one set of legs at the end of the section. Ramp sections of 8' and 10' will need two sets of legs, one in the middle and one at the end of the section. www.nationalramp.com | 877-884-RAMP(7267) [ 56 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 57 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. Tongue/Top Groove/Bottom Height to set leg from travel surface to ground image 21 [ 57 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL...
Page 58 Tongue Groove Bottom image 22 www.nationalramp.com | 877-884-RAMP(7267) [ 58 ] NATIONAL RAMP™ | FREEDOM NOW 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL...
Page 59: Special Platform Configurations
Use a switchback bracket to install a leg on the inside corner of the switchback platform. ƒ TIPS AND TRICKS For any questions on leg placement, please reference pages 46 and 47. image 23 SWB SWITCHBACK BRACKET [ 59 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 60 18.4.4. Attach the leg to the bolts of the switchback bracket. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL 18.4.5. Continue with the installation of the next platform. OF NATIONAL RAMP. www.nationalramp.com | 877-884-RAMP(7267) [ 60 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 61 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. image 25 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL [ 61 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 OF NATIONAL RAMP.
Page 62: Installing A T-Post
OF NATIONAL RAMP. Place the section upright on sawhorses, with the tongue side facing forwards. Slide the BTP 18.6.1. into the groove end of the section. Tongue/Top Groove/Bottom image 27 www.nationalramp.com | 877-884-RAMP(7267) [ 62 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 63: Finishing The Ramp
18.7.1. section between platforms. The ramp sections should follow the string. String image 28 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL [ 63 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 OF NATIONAL RAMP.
Page 64 30 www.nationalramp.com | 877-884-RAMP(7267) [ 64 ] NATIONAL RAMP™ | FREEDOM NOW MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL...
Page 65 Remove the two halves of the elbow from the packaging. One half will have the nut and bolt 18.7.2. to join the two halves. image 32 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL [ 65 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 OF NATIONAL RAMP.
Page 66 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. image 34 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL www.nationalramp.com | 877-884-RAMP(7267) [ 66 ] NATIONAL RAMP™ | FREEDOM NOW OF NATIONAL RAMP.
Page 67 There are two options for installing the handrails on the inside corner of this platform: elbows or a 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL T-post. OF NATIONAL RAMP. The correct installation of either method will result in a secure handrail. [ 67 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 68 18.7.11.5. Cut the pieces of filler pipe and attach it between the handrails. Trim filler pipe tubing here image 37 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL www.nationalramp.com | 877-884-RAMP(7267) [ 68 ] NATIONAL RAMP™ | FREEDOM NOW OF NATIONAL RAMP.
Page 69 18.7.12.4. Insert elbows on the outside corner of the T-Post and ramp handrails, and measure filler pipe to fit between the two elbows, using a right angle or triangle to make sure the railings will be at 90°. [ 69 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 70 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. OF NATIONAL RAMP. 18.7.15. Make sure the connector and handrail are aligned to prevent sharp edges before tightening with an Allen key. www.nationalramp.com | 877-884-RAMP(7267) [ 70 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 71 For code compliance, there must be 1.5" of clearance between the railings. [ 71 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 72 18.7.17. Center TTP on top of the starting ramp section or platform and the door threshold or porch, securing with driller screws. image 43 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. www.nationalramp.com | 877-884-RAMP(7267) [ 72 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 73 Step 5  Install all Ramp and Platform Brackets. National Ramp requires installing all Ramp and Platform Brackets to ensure the safety and security of the ramp system. Tongue/Top Groove/ Bottom image 44 Use the below chart to determine how to position the bracket and which holes to drill for each configuration.
Page 74 Step 6  Place all leg caps, corner guards and end caps needed. DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. Corner Guards End Caps Leg Caps image 47 www.nationalramp.com | 877-884-RAMP(7267) [ 74 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 75 Step 8  Have the ramp user(s) traverse the ramp to make sure they feel comfortable and are happy with the result, before reviewing maintenance and care. [ 75 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 76: Miscellaneous Installation Processes
1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL The TTP cannot be repositioned and must be cut to be removed once installed to the threshold ramp. OF NATIONAL RAMP. image 49 www.nationalramp.com | 877-884-RAMP(7267) [ 76 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 77 This threshold ramp can be affixed to the home by using screws through the side 19.1.2.1. tabs of the fixed leg height threshold. image 52 [ 77 ] 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 OF NATIONAL RAMP.
Page 78: Landing Pad
19.2.3. Make sure the landing pad doesn’t wobble. Pack dirt or gravel underneath the landing pad if needed to keep it level and supported. 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. www.nationalramp.com | 877-884-RAMP(7267) [ 78 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 79: Cross Bracing
3. CROSS BRACING MUST BE USED ON EVERY OTHER RAMP SECTION. DOCUMENT ARE PROPRIETARY AND MAY NOT BE SHARED, MODIFIED, DISTRIBUTED, REPRODUCED, OR REUSED WITHOUT THE EXPRESS WRITTEN PERMISSION Scale OF NATIONAL RAMP. [ 79 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 80 All ramps and platforms 36" and over elevation require cross bracing. Refer to chart(s) for cross brace lengths to use. www.nationalramp.com | 877-884-RAMP(7267) [ 80 ] NATIONAL RAMP™ | FREEDOM NOW ƒ Platform cross bracing must be installed on all four sides: Total of 8 cross braces ƒ...
Page 81 19.3.6. Install using 1/4"-14 x 1" driller screws. image 56 DATE FRACTIONAL PROPRIETARY AND CONFIDENTIAL APPLICATION [ 81 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 82: Hurricane Tie-Downs
19.4.5. Screw the anchor firmly into the ground, leaving only the eye exposed. 19.4.6. Thread the end of the cable to the anchor, and clamp in place where it loops through the eye of the anchor. www.nationalramp.com | 877-884-RAMP(7267) [ 82 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 83 OF NATIONAL RAMP. Incorrect Installation image 59 VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. [ 83 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 84: Pie Platforms
Install three (3) legs at the three (3) corners of the pie platform.  Groove/Bottom Tongue/Top image 61 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL www.nationalramp.com | 877-884-RAMP(7267) [ 84 ] NATIONAL RAMP™ | FREEDOM NOW OF NATIONAL RAMP.
Page 85 Trim filler pipe here Trim filler pipe here Groove/Bottom Tongue/Top image 63 [ 85 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL...
Page 86 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. Groove/Bottom Tongue/Top 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL image 65 OF NATIONAL RAMP. www.nationalramp.com | 877-884-RAMP(7267) [ 86 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 87 19.5.1.3. Lining up the elbow joints with the change in direction, trim the handrails, clearing any burrs. Groove/Bottom Tongue/Top image 66 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. [ 87 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 88: Step And Gate Systems
3/16" Allen bit/wrench ƒ ƒ Drill ¼" drill bit ƒ ƒ 3/8" socket Level ƒ ƒ 7/16" socket and/or wrench Pipe cutter ƒ ƒ 9/16" socket Sanding/Filing Tool ƒ ƒ www.nationalramp.com | 877-884-RAMP(7267) [ 88 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 89 69 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. [ 89 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 90 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL Short Tubes Facing Bottom Of Stairs OF NATIONAL RAMP. 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL image 71 OF NATIONAL RAMP. www.nationalramp.com | 877-884-RAMP(7267) [ 90 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 91 REUSED WITHOUT THE EXPRESS WRITTEN PERMISSION Sc a le : She e t o f L RAMPS & PLATFORMS 36'' AND OVER ELEVATION REQUIRE CROSS BRACING OF NATIONAL RAMP. image 73 [ 91 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 92 Four (4) ¼" washers ƒ Two (2) ¼"-20 acorn nuts ƒ image 75 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. www.nationalramp.com | 877-884-RAMP(7267) [ 92 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 93: Vertical Pickets
If the picket railings are only be used for part of the ramp, it is recommended that OF NATIONAL RAMP. the change between vertical picket and dual rail handrails take place at a platform. [ 93 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 94 78 In addition to the tools required to install the Liberty Series™ Ramp System, the following are also needed: 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP.
Page 95 Do not over-tighten handrails to allow for later adjustments. 19.7.6. Inside Corner Installation: Tongue/Top Groove/Bottom image 81 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL [ 95 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 OF NATIONAL RAMP.
Page 96 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL image 83 OF N www.nationalramp.com | 877-884-RAMP(7267) [ 96 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 97 ONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL to the extended bolts. OF NATIONAL OF NATIONAL RAMP. Groove/Bottom Tongue/Top image 86 [ 97 ] 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 98 9/16" open end wrench. OF NATIONAL RAMP. Tighten Using an Open-End Wrench image 88 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. www.nationalramp.com | 877-884-RAMP(7267) [ 98 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 99 19.7.7. Once all handrails have been installed, insert round plug caps to the ends of all handrails. Groove/Bottom Tongue/Top image 90 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. [ 99 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 100 Install two (2) ¼" – 14 x 1" pan head drilling screws to secure the switchback bracket to ƒ the platform. 19.7.11. Once all handrails connections have been made, fully tighten all leg and handrail nuts. 19.7.12. Inspect the entire ramp installation. www.nationalramp.com | 877-884-RAMP(7267) [ 100 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 101 [ 101 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 102 | 877-884-RAMP(7267) [ 102 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 103: Two Layout Configurations Start To Finish
1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF N OF NATIONAL RAMP. [ 103 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 104: Layout Configuration 1 | 90° Turn
12' to the right to a 5'x5' platform, turning left with a final 7' ramp run to a 5'x5' landing pad. The overall height is 19". image 92 OT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF N www.nationalramp.com | 877-884-RAMP(7267) [ 104 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 105 OF NATIONAL RAMP. CORRECT INSTALL image 94 [ 105 ] FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 OF NATIONAL RAMP.
Page 106 Attach universal brackets and bolts for the handrails and legs. Groove, Bottom image 95 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL www.nationalramp.com | 877-884-RAMP(7267) [ 106 ] NATIONAL RAMP™ | FREEDOM NOW OF NATIONAL RAMP.
Page 107 The platform can be installed at up to a 1° angle cross slope (1/4" per foot) to allow for rain runoff. 20.4.7. Install Toe Guards. Place toe guards at the two (2) outside corners of the platform, and affix each with two driller screws. [ 107 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 108 20.5.6. Using a level, make sure the ramp section is level across the ramp and at the correct slope. Make sure the BTP is fully supported and firmly on the ground across its length. www.nationalramp.com | 877-884-RAMP(7267) [ 108 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 109 20.7.2. Stretch the string from the top of the first 6' section to the bottom of the second 6' section between platforms. The ramp sections should follow the string. 20.8  After confirming all legs are plumb, tighten all the leg bolts. [ 109 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 110 20.9.2.2. Cut the handrails using a pipe cutter, double checking there are no burrs left. 20.9.2.3. Insert the elbow between the platform and section handrails and tighten. www.nationalramp.com | 877-884-RAMP(7267) [ 110 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 111 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL 20.10 Corner handrail options for 5'x5' turn platforms  OF NATIONAL RAMP. 20.10.1. Option 1  Diagonal railing using elbows Tongue, Top Groove, Bottom image 101 [ 111 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 112 90°. 20.10.2.5. Cut the handrails using the pipe cutter and connect the elbows after clearing any burrs. www.nationalramp.com | 877-884-RAMP(7267) [ 112 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 113 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. OF NATIONAL RAMP. [ 113 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 114 Install all Ramp and Platform Brackets. 20.11.3. National Ramp requires installing all Ramp and Platform Brackets to ensure the safety and security 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL of the ramp system. Install these brackets on both sides of the ramp.
Page 115 ENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL Corner Guards OF NATIONAL RAMP. End Caps Leg Caps image 109 [ 115 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 ENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL...
Page 116 Run your hands across all railings to check for any sharp edges or burrs. 20.11.10. Have the ramp user(s) traverse the ramp to make sure they feel comfortable and are happy with the result, before reviewing maintenance and care. www.nationalramp.com | 877-884-RAMP(7267) [ 116 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 117: Layout Configuration 2 | Switchback Ramp
5’x5' platform (creating a 5x10 switchback platform), with a final 7' of ramping to the ground. Overall height is 19". image 110 PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL [ 117 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 118 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. CORRECT INSTALL image 112 www.nationalramp.com | 877-884-RAMP(7267) 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL [ 118 ] NATIONAL RAMP™ | FREEDOM NOW OF NATIONAL RAMP.
Page 119 6" less than the Groove, Bottom platform height. image 114 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL [ 119 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020 OF NATIONAL RAMP.
Page 120 (2) sets of handrails and two (2) of the three (3) legs needed for this platform. (The switchback bracket will need to be added to hold the third leg). www.nationalramp.com | 877-884-RAMP(7267) [ 120 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 121 Repeat steps 1-6 of Step 4; however, there will only be two (2) legs placed opposite the 21.5.1. OF NATIONAL RAMP. tongue. 21.5.2. Install toe guards. Place toe guards along the inside edges of the platform, and affix each with two (2) driller screws. [ 121 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 122 21.7.2. Stretch the string from the top of the first 6’ section to the bottom of the second 6' section between platforms. The ramp sections should follow the string. 21.8 After confirming all legs are plumb, tighten all the leg bolts.  www.nationalramp.com | 877-884-RAMP(7267) [ 122 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 123 Place the edge of the elbow against the fixed platform handrail and mark the top and lower ramp handrails. 21.9.4. Cut the handrails using a pipe cutter, double checking there are no burrs left. 21.9.5. Insert the elbow between the platform and section handrails and tighten. [ 123 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 124 21.9.9. Repeat the process for the interior handrails, starting with the T-Post on the starting platform. OF NATIONAL RAMP. Trim filler pipe here image 120 www.nationalramp.com | 877-884-RAMP(7267) [ 124 ] NATIONAL RAMP™ | FREEDOM NOW 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL...
Page 125 Predrill and place driller screws into each leg to lock into place. Ensure flange nut is tight 21.10.1. to secure leg. image 122 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. [ 125 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 126 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL OF NATIONAL RAMP. Tongue, Top Groove, Bottom image 124 www.nationalramp.com | 877-884-RAMP(7267) [ 126 ] NATIONAL RAMP™ | FREEDOM NOW 1. FOOT PLACEMENT DIMENSIONS MUST BE VERIFIED BASED ON FIELD CONDITIONS AND ACTUAL INSTALL...
Page 127 National Ramp requires installing all Ramp and Platform Brackets to ensure the safety and security of the ramp system. Install these brackets on both sides of the ramp. Use the below chart to determine how to position the bracket and which holes to drill for each configuration.
Page 128 Run your hands across all railings to clear any remaining burrs. OF NATIONAL RAMP. 21.10.10. Have the ramp user(s) traverse the ramp to make sure they feel comfortable and are happy with the result, before reviewing maintenance and care. www.nationalramp.com | 877-884-RAMP(7267) [ 128 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 129 [ 129 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 130 | 877-884-RAMP(7267) [ 130 ] NATIONAL RAMP™ | FREEDOM NOW...
Page 131: Ramp Maintenance And Care
RAMP MAINTENANCE AND CARE [ 131 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 132: Liberty Series Tm Warranty
22. Liberty Series Warranty National Ramp, a division of The Landmark Group, Inc., (herein referred to as Manufacturer), warrants that the equipment sold shall be free from defects in material and workmanship under normal use and service for Aluminum Ramps for a lifetime from the date of original purchase. This limited warranty applies to the original purchaser only and is not transferable or assignable by contract or by operation of law, either directly or indirectly.
Page 133 Manufacturer reserves the right to change or improve its products without any obligation to change or improve any product it previously manufactured. [ 133 ] Liberty Series™ Ramp Installation Guide-Revision 8/1/2020...
Page 134: Liberty Series Tm Maintenance And Care
If you believe that your Liberty System ramp has a defect, call National Ramp at (877) 884-7267.
Page 135: Warranty Registration
Congratulations on the purchase of your new National Ramp! Welcome to our happy family of National Ramp owners who have found the freedom of their choice. Each of our National “Rampers” is special to us, and we would like you to know that you truly do belong to a family who cares about your needs and your freedom.
Page 136 If your ramp picture is better than the rest, we will send you a $100 gift card! If your ramp picture includes you on the ramp, you will win a $200 gift card! Thank you for making National Ramp your choice. We wish you all the best as you enjoy your freedom!
