Summary of Contents for Agbar Musa iMeter IMI-40-E
- Page 1 Models: IMI-40-E and IMI-40-E-Ex Pulse collector for remote water meter-reading by GPRS Agbar Mantenimiento, S.A. Guidelines for setting up the iMeter and Operating instructions Barcelona, August 2011 20110810_iMeter_guidelines.doc Page 1/16 10/08/2011...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ..........................3 IMeter deployment........................4 2.1. Connection to a meter and pulse captor................4 2.2. iMeter installation ........................6 iMeter setting up........................8 3.1. PaLFI dongle settings ......................8 3.2. IMeter PDA manager to set up..................10 3.2.1. PalFI iMeter configurator....................11 3.2.2. Connect to iMeter.......................12 3.2.3. -
Page 3: Introduction
The iMeter collects pulses according to the frequency displayed by its configuration, and delivers the data to the AGBAR servers, where is collected and processed by AGBAR systems. This data is showed in the AGBAR AMR (Automatic Meter Reading) webpage. -
Page 4: Imeter Deployment
IMeter deployment The iMeter is installed on site, where the meter is placed. Before the installation it doesn’t need any process. The installer only need to know in which meter the iMeter is going to be installed to, in order to have a pulse captor appropriate for the brand and model of the water meter. The iMeter can be produced directly connected to the pulse captor, which makes easier and simpler the deployment process. - Page 5 pulse Type of pulse captor function captor iMeter brown brown Itron Cyble 2 wires Pulses (BF) white white brown brown Pulses (AF) grey white Itron Cyble 5 wires Direction yellow yellow Cable cut detection green green brown brown Sensus HRI-A1 Pulses (I1) white white...
-
Page 6: Imeter Installation
Figure 2. iMeter connected to an Itron meter 2.2. iMeter installation In the case of the Boundary boxes, the placing of the iMeter depends on the type and shape of the box. It can be placed on the wall or under the box cover. The fixing must be done putting screws in the holes prepare for that of the iMeters. - Page 7 Figure 3. iMeter installed on site in a boundary box, connected to a Sensus meter Figure 4. iMeter installed on site, connected directly to a Flow Meter 20110810_iMeter_guidelines.doc Page 7/16 10/08/2011...
-
Page 8: Imeter Setting Up
iMeter setting up Once the iMeter is physically placed and connected to the meter, the iMeter must be set up by the PaLFI dongle and a PDA, which set the installation configuration to the iMeter, and starts the iMeter Figure 5. Tools to set up the iMeter: PDA and dongle 3.1. - Page 9 Figure 6. Optimal position for the dongle for installing ON/OFF button Battery and RF activity light Bluetooth light Figure 7. Dongle lights and button 20110810_iMeter_guidelines.doc Page 9/16 10/08/2011...
-
Page 10: Imeter Pda Manager To Set Up
The ON/OFF button is used to switch on the Bluetooth state and to switch off back to the low consumption mode. The Bluetooth light (green) can show the following states: • OFF, when the dongle is low consumption mode • Flashing, when the dongle is ON but it still doesn’t receive any Bluetooth connection •... -
Page 11: Palfi Imeter Configurator
Figure 8. Installation process using the PDA and dongle 3.2.1. PalFI iMeter configurator After application starts, the main screen is displayed: Figure 9. Screen capture of the main screen of the PDA software 20110810_iMeter_guidelines.doc Page 11/16 10/08/2011... -
Page 12: Connect To Imeter
3.2.2. Connect to iMeter In the main screen we can push the button Connect to iMeter to start communicating. The PDA will try to establisg a Bluetooth communication with the PaLFI, and subsequently the PaLFI will try to communicate with the iMeter. If the communication is successful, a screen with the iMeter serial number and some other data about the last connection result is displayed: Figure 10. - Page 13 Figure 11. Screen captures of the iMeter configuration parameters of the PDA software • Select pulse captor: press this button to actually select the pulse captor model that will be configured to the iMeter. This shows the same screen but we can choose one value. As before, note that the same value can be valid for several captor models.
-
Page 14: Activate Imeter
3.2.4. iMeter activation Now after the parameters are selected as desired, we can start the actual configuration process by pressing the Turn on button. This makes the program send the configuration to the PaLFI to be subsequently written in the iMeter. The screen shows the progress of the operation step by step: •... - Page 15 After countdown exhaustion, the iMeter performs the connection with the server. This process goes through several states, which are displayed updating each few seconds: Figure 14. Screen capture of activation process If the process finishes correctly, the OK button will be enabled, allowing returning to the main screen.
-
Page 16: Long Term Imeter Using
Once the iMeter is installed and the installation results were ok, the iMeter configuration is done remotely with the AGBAR AMR website. There is no need to come back on site where the iMeter is. The iMeter is controlled only by the internet webpage. In the configuration webpage is possible to configure the reading and delivering frequencies, as the iMeter alarm settings.
