HUGOAI HG02 User Manual

Smart table lamp
Hide thumbs

Advertisement

Quick Links

Download this manual
Works with
Works with
alexa
Smart Life
Smart Table Lamp
User Guide
Setup instructions for Smart Life App,
Alexa and Google Assistant.
2.4Ghz WiFi
Works with
Works with the
Google Assistant
Siri Shortcuts
Scan the QR code to read the detailed
instruction in
https://www.hugo-ai.com.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HG02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HUGOAI HG02

Summary of Contents for HUGOAI HG02

  • Page 1 Smart Table Lamp User Guide Setup instructions for Smart Life App, Alexa and Google Assistant. 2.4Ghz WiFi Works with Works with Works with Works with the alexa Scan the QR code to read the detailed Smart Life Google Assistant Siri Shortcuts instruction in https://www.hugo-ai.com.
  • Page 2 Product Specification Product Diagram Smart Life App Setup APP Operation Instructions Connect to Alexa 9-10 Connect to Google Assistant Enable Siri Shortcuts (For use with iPhone) Problems and Solutions 13-14 Federal Communication Commission (FCC) Statement for Users...

  • Page 3: Product Specification

    Product Specification Package Includes Specification ●　1 x LED Table Lamp Model HG02 ●　1 x AC Adapter Wattage ●　1 x User Manual Adapter Input 100-240V/AC 50/60Hz Adapter Output 5V/1A Current Ripple Flicker Free ±3% Network WIFI IEEE802.11b/g/n(2.4GHz) Luminous Flux / Intensity 450lm@4000K, Red:7.2cd, Green:12cd, Blue:6.6cd...

  • Page 4: Product Diagram

    Product Diagram Control Panel Press to turn on and off the lamp Lamp Cover Press to turn on RGB Mode Press to switch color temperature 2000K 3000K 4000K Slide to adjust Base brightness or color Type-C Port Press to set timers. It will set the light to 2000K 30 minutes...
  • Page 5 Smart Life App Setup Preparation 1. Connect to 2.4GHz Wi-Fi net- 2. Install the Smart Life app from the 3. Register an account and allow work and turn Bluetooth on. Apple Store/ Google Play Store, the app to use Bluetooth. or via scanning the QR code.
  • Page 6 Smart Life App Setup Prepare the Lamp for Connection ② Press the timer button for more than 5s ① Charge and turn on the lamp. until the indicator flashes quickly in green. more than 5s...
  • Page 7 Smart Life App Setup Add the Lamp to Smart Life (via Bluetooth) ① The lamp will appear automatically waiting to be added when you open the Smart Life App. ******** ********** Click “Go to add”. Select the table lamp. Enter 2.4GHz Wi-Fi Wait for adding device.
  • Page 8 Smart Life App Setup Add the Lamp to Smart Life (Manually) ② Or you could add the lamp to Smart Life manually. ******** ********** Tap "+" in the upper Tap "Lighting" and then Enter 2.4GHz Wi-Fi Wait for adding device. You can edit the lamp right corner or you can tap "Lighting(BLE+Wi-Fi)".
  • Page 9 APP Operation Instructions Tunable White RGB Mode Scene Mode Note: For the scene modes: Night, Read, Working and Leisure, their color settings are fixed and could not be customized. ① Brightness Control However, you can customize the color ① Brightness Control ②...
  • Page 10 APP Operation Instructions Music Mode Schedules & Timers Schedules Timer Set schedules Set the timer to Choose Music Sync to match color changes based around turn off the lamp to the beat of the music playing on your your preferences automatically.
  • Page 11 Connect to Alexa Launch the Alexa App then tap Search "Smart Life" in the input box and on the Menu. Choose “Skills& Click "ENABLE TO USE". select Smart Life App in the search results. Games” in the option bar.
  • Page 12 Connect to Alexa Tap “Devices” on the Menu. Here is a Log in Smart Life account and authorize message “1 lightdiscovered” on the top. Then you could control the lamp via Alexa. Alexa. Then click “CLOSE”. The lamp is connected to alexa successfully.
  • Page 13 Connect to Google Assistant Launch the Google Assistant To add a device tap on the Search "Smart Life" App. Tap "Assistant" and Choose App then tap on the icon in Circle(+) located in the lower Then log in your Smart Life "Home Control".
  • Page 14 Enable Siri Shortcuts (For use with iPhone) Tap ”Smart” on the bottom Set a condition and setting Click “Add to Siri” on the Edit the wake-up command menu bar and then create of “Tap-to-Run” command. right corner. and save shortcut. a “Tap to Run”...

  • Page 15: Problems And Solutions

    Problems and Solutions If the app can't control your lamp but its status shows "on": Check if the device you're using is connected to network and if the lamp is within range of your Wi-Fi. Check if the power supply of the lamp is working and make sure the power adapter is plugged into a working socket. If the indicator turns red: The red light indicates that the lamp is disconnected with the network.
  • Page 16 Problems and Solutions How to find Mac Address of the lamp? Here are two ways to find the MAC address of your smart lamp out. The first way is to connect your lamp with AP mode: 1. Click "Switch Paring Mode" in the Smart Life App when you fail to connect the lamp with Wifi. 2.
  • Page 17 Federal Communication Commission (FCC) Statement for Users Federal Communication Commission (FCC) Statement for Users Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.
