Summary of Contents for ARCHELON XTR
- Page 1 Enclosure + Charging Base ASSEMBLY INSTRUCTIONS Additional items you may need to assemble your Archelon (not provided): • Tape • Drill • ¾" Drill Bit • ¼" Drill Bit...
- Page 3 Your package should include the following: Front Plate (not shown) Back Plate (not shown) Charging Base (not shown) Top Adapter Bolt Cap Home Button Cover Audio Jack Cover (3) Power / Volume Toggles (6) Security Screws Keys 30-Pin to Mini USB Charging Cord (shown) —or—...
- Page 4 Place Front Plate on non-slip surface for assembly. If you would If you would like to disable access to the home button after like to have access to the home button after installation, keep installation, press in Home Button Cover into home button hole.
- Page 5 Place Bottom Adapter onto Front Plate by snapping it into the Position cord to the right. bottom of the Front Plate. The toggles should ‘hook’ over the edge of the frame and touch the iPad’s If you want access to the Power and / or Volume Buttons, place buttons.
- Page 6 Pop in the Top Adapter as shown onto Back Plate. This photo shows the Top Adapter in place. Place Back Plate next to Front Plate and iPad if you haven’t This photo is a close-up of the Mini USB connector on the Back already done so.
- Page 7 If you want to disable access to the Audio Jack, snap Audio Jack Place Back Plate onto Front Plate. Cover into Back Plate. If you want access to the Audio Jack, skip this step. Screw each Security Screw into the Back Plate using Security Plug Mini USB to USB Charging Cord into the bottom of the Driver .
- Page 8 Using the supplied mounting template, tape into place where you would Thread your Charging Cord through the Mounting Thimble like to mount your Archelon. Using a 3/4" drill bit (for thimble hole as shown. only!), drill through your surface. Using a 1/4" drill bit, drill bolt hole.
- Page 9 Install Lag Bolt (or Machined Bolt) with supplied Pan Press the Bolt Cap into place. Washer , Nut & Lock Washers To charge unit, plug the Charging Cord into an iPad power Attach enclosure to base and lock with Key as shown.
- Page 10 Position Charging Base onto Mounting Base, placing the INSTRUCTIONS FOR OPTIONAL MOUNTING BASE: Thread Mini USB to USB Charging Cord through thimble hole of Mounting Base. Mounting Thimble into the larger (3/4") hole. Install Machined Bolt with supplied hardware. Remove the VHB Thread cord through the cord management canal as shown.
- Page 11 Find the PERFECT accessories to compliment your new Ergonomic Swivel Point-of-Sale Extended Charging Hand Grip Card Reader Kits Cords For more products and accessories, visit www.ArchelonEnclosures.com...
