Summary of Contents for MSTS Tolls OBU

Page 1 EETS OBU User Manual...
Page 2: Table Of Contents
Normal Light and Sound Guide Section 5 | Vehicle Axles and Weight • Changing Vehicle Axles Guide • Changing Vehicle Weight Guide Section 6 | Other Information • Preparation before driving • Transporting the OBU • Power Supply • Emergency Procedures...
Page 3: Section 1 | Introduction
SECTION 1 Introduction This user manual will help you understand how to install and use the OBU. Warning Carefully follow the installation instruction. Customer is liable if they do not read the OBU (LED and acoustic) signals correctly and continue driving.
Page 4: Section 2 | Installation Guide
SECTION 2 Installation Guide OBU Placement Hydrate the suction cups placed on the back of the OBU Step 1 and wipe the inside of the windshield. Place the holder with four suction cups in the desired Step 2 location on the windshield.
Page 5: Power Source
- ignition conductor 15 black - skeleton conductor 31 Connect the OBU fixed installation power cable to the vehicle’s electrical system according to the wiring diagram above, including the protective fuses for conductors 15 and 30. • Ensure that the fuses and their holders are approved for use in the vehicle’s electrical system...
Page 6: Section 3 | Unit Structure
SECTION 3 Unit Structure Main Screen Display The OBU is equipped with display, which shows to user the basic information concerning the current state of the OBU. Picture of the Truck Picture of the Trailer and (tractor) Bus and selected selected number of axles.
Page 7: Physical Box
(LED above display) Acoustic signalization (built-in buzzer) Control Buttons Rechargeable battery Connector of Power supply rechargeable connector battery The USB port can only be used by support technicians. Intervention or alteration may cause malfunctions of the OBU or payment system.
Page 8: Main Control Buttons
For safety reasons, the function of the buttons is locked at a speed higher than 15 km/h. Main Control Buttons The OBU is equipped with four control buttons and 3 signalization elements. Browse downwards in the list of menus Browse upwards in the list of menus...
Page 9 (longer than 3 seconds) External Power Supply OBU is connected to supply system of the vehicle OBU is not connected to supply system of the vehicle. Please connect the OBU to a power supply (page 4) Locked Status OBU is locked for techincal reasons or from the portal.
Page 10: Section 4 | Led Light And Sound
SECTION 4 LED Light and Sound OBU Background Light flashes when a “Successful Payment Msg” or one of the “Error Msgs” is displayed on the screen . Error Msgs disappears from the screen when user presses any button. Current Toll Domain...
Page 11 DSRC Transaction (Toll Payment) incomplete. Beeping 10s Action Do not drive on Toll Road. Follow the instructions of Toll Charger and use the degraded payment solution. OBU Locked for Stable Red technicalities, faults, or No Beeping by remote command. Action...
Page 12 Blinking Yellow OBU Running from Battery Regime Beeping 20s Action Check connection of power supply, and connect OBU to external power supply (see page 4). Blinking Yellow OBU battery is running out soon Beeping 10s Action Check connection of power supply immediately, and connect OBU to external power supply (see page 4).
Page 13 Toll Roads (e.g. Austria). In these Toll Domains, the user of the OBU is required to confirm if the vehicle picture is displayed on the Main Screen is consistent with the actual number of axles or weight of the vehicle.
Page 14: Section 6 | Other Information
• Axle number of Tractor and Trailer • Actual vehicle weight Step 2 Check the activated Toll Domain list on this OBU: • Press “ “ to enter the Main Menu • Select “Activated Toll Domains “ to enter the list of activated Toll Domains Step 3 Connect OBU to the Power Supply.
Page 15: Transporting The Obu
Transporting the OBU Before transporting the OBU, set the OBU into Transport Mode: • Use the Portal to send a request to set the OBU into Transport Mode. • Transport Mode Symbol “ “ will show on the screen with a green LED light.
