Monsoon M2 D5 Premium Instructions Manual

Dual bay reservoir
Hide thumbs

Advertisement

Table of Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M2 D5 Premium and is the answer not in the manual?

Questions and answers

Summary of Contents for Monsoon M2 D5 Premium

  • Page 2 To ensure all threads are in working order, we populate all threaded holes and ports prior to shipping. Monsoon is not responsible for damage caused by over tightening of screws or fittings and all returned parts will be inspected prior to the resolution of an RMA. If you have damaged threads, replacement parts are available at your favorite reseller or directly from Monsoon.
  • Page 3 D5 body are near their extremes for tolerance. Obviously, this is not good and can cause damage to your pump. USE THE RED LINE 1.5MM O RING AT YOUR OWN RISK. MONSOON ACCEPTS NO LIABILITY IN THE EVENT YOU DAMAGE YOUR PUMP.
  • Page 4 PUMP MOUNTING CONTINUED: Set the pump body onto its face, (soft cloth on the work surface first) place the O ring into the pump area located on the back of the reservoir in the location shown in the above image. The O ring should easily drop into position without stretching or compressing being needed.
  • Page 5 PLUG INSTALLATION: There are four plugs included with your Monsoon reservoir. Two are used on the convenient top fill ports. PLEASE NOTE that for a limited time all Monsoon reservoirs are shipping with two FREE Silver Bullet Antimicrobial Plugs--these are already installed in the top fill ports and you must remove the rubber anti tarnish covers prior to use.
  • Page 6 CASE MOUNTING: Your new Monsoon Series 2 reservoir features vibration isolation mounting to reduce noise. Although mounting is essentially the same as mounting any other device in an optical bay, there are a few small differences. The goal of vibration isolation is to break any hard mechanical paths between the reservoir and your case that would normally allow vibration from the pump to be transmitted to the chassis causing “squeaks”.
  • Page 7 Monsoon Series Two D5 Premium Reservoir runs. You can find many other parts and products that are designed to work with the Monsoon Modular Reservoir System at your favorite reseller or at http://www.monsooncooling.com/...

This manual is also suitable for:

M2-d5p
