Symphony TV Bed
Assembly Instuctions - Please keep for future reference
Dimensions 4 ft 6
Depth x Width x Height
219cm x 146cm x 107cm (Double)
Dimensions 5 ft
Depth x Width x Height
229cm x 160.5cm x 107cm (King)
Dimensions 6 ft
Depth x Width x Height
229cm x 190.5cm x 107cm (Super King)
Important - Please read these instructions fully before starting assembly
If you have a fault with your product or missing fittings, please contact our customer service team on
01992 450333 (Monday to Friday 08:30 - 17:30 excluding bank holidays).
5cm Max TV Depth
32inch TV MAX
Advertisement
Summary of Contents for Sleep Secrets Symphony
- Page 1 Symphony TV Bed Assembly Instuctions - Please keep for future reference Dimensions 4 ft 6 5cm Max TV Depth Depth x Width x Height 219cm x 146cm x 107cm (Double) Dimensions 5 ft 32inch TV MAX Depth x Width x Height 229cm x 160.5cm x 107cm (King)
- Page 2 Safety and Care Advice Assembly time: 1.5 Hours Warnings • Retain these instructions for future reference • Unwrap all packaging materials and place the components on top of the carton or on a clean soft floor to prevent it from scratches •...
- Page 3 Components If you have damaged or missing components call the Customer Helpline: 01992 450 333 Tick boxes provided to check the components Headboard Footboard Right Side Rail Bracket x 2 Left Side Rail Tray Tray Foot Supports x 2 Centre Support Rail x 1 Centre Support Legs x 2 Centre Slat Caps Slat Caps...
- Page 4 Components If you have damaged or missing components call the Customer Helpline: 01992 450 333 Tick boxes provided to check the components 10cm M8 x 18mm M8 x 40mm M8 x 20mm Washer Bolt Bolt Bolt (not supplied) If you have a fault with your product or missing fittings, please contact our customer service team on 01992 450333 (Monday to Friday 08:30 - 17:30 excluding bank holidays).
- Page 5 Assembly Instructions Step 1 Inserting bolts Loosely attach 2 x bolts to both corners of the head- board . Then repeat for the footboard shown. M5 Allen key (supplied) Parts (A) Headboard (B) Footboard (2) Bolt M8 18mm x 8 M5 Allen Key If you have a fault with your product or missing fittings, please contact our customer service team on 01992 450333 (Monday to Friday 08:30 - 17:30 excluding bank holidays).
- Page 6 Assembly Instructions Step 2 Attaching side rails Hook on the side rails & on the headboard then securely tighten the bolts. Do not over tighten. Repeat this step on the footboard Parts Footboard Headboard (C) Right Side Rail (D) Left Side Rail M5 Allen Key If you have a fault with your product or missing fittings, please contact our customer service team on 01992 450333 (Monday to Friday 08:30 - 17:30 excluding bank holidays).
- Page 7 Assembly Instructions Step 3 Attaching the tray a) Attach the 2 x brackets to tray by inserting 2 x bolts with 2 x washers b) Insert 2 x feet to the other side of the tray by rotating them anti-clockwise. c) Place the brackets (that are now attached to the...
- Page 8 MK4 Cabling Components If you have damaged or missing components call the Customer Helpline: 01992 450 333 Tick boxes provided to check the components (2R) Wireless Control Box (1R) TV Power Supply AC / DC Adaptor (4R) Motor Power Supply (3R) (2032 Battery is included)
- Page 9 TV Mechanism MK4 Cabling Guide This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
- Page 10 TV Bed MK4 Remote Control Guide When necessary, you will need to use a 2032 battery in the remote for replacement. Your remote control system is pre-set and you can use this immediately. You will only need to reset the remote system if your hand set does not respond. Operation –...
- Page 11 Fitting the TV Note: When raising the Note: If you are not fitting the TV at this point, please move directly mechanism without the to the next step. TV fitted, lift the lid on the footboard first. Do not let the lid touch the 5cm max TV depth mechanism whilst it is in motion at any time,...
- Page 12 Adjusting TV Bracket Should you need to adjust the position of the TV bracket to best fit Remove 4 bolts your TV, follow these from plate. steps: 1. Remove the 4 bolts on the front plate as shown. 2. Move the bracket up or down as required.
- Page 13 TV Bracket The position of the mounting holes your TV use will vary depending on the 200mm make and model. The TV bed has a universal can accomodate TVs with the following standard VESA 200mm compliant sizes. 100mm 100mm 200mm 100mm 200mm 100mm...
- Page 14 Assembly of Slats Attach the support legs to the centre rail by using bolts washers on each one. Fit the centre rail into position against the headboard . Then attach them by using 2 x bolts and 2 x washers Repeat this step with the footboard 10mm...
-
Page 15: Assembly Is Now Complete
Assembly of Slats Slot the bed slats into the end centre plastic caps as shown. Step 1 Step 3 push the end caps into Step 2 the wooden support on Side rail push down the middle support slat cap into place on the centre rail.
