Summary of Contents for Arachnid Labs Re:load Pro
- Page 1 User Manual Arachnid Labs Re:load Pro Copyright 2014, Arachnid Labs http://www.arachnidlabs.com/reload-pro/ Licensed CC-BY-SA...
-
Page 2: Ec Declaration Of Conformity
2004/108/EEC The Electromagnetic Compatibility Directive 2001/95/EC The General Product Safety Directive hereby declare that: Equipment Re:load Pro DC Active Load is in conformity with the applicable requirements of the following docu- ments Title EN 61326-1:2013 Electrical equipment for measurement, control and laboratory use. -
Page 3: Safety Notices
Do not operate in wet/damp conditions Do not operate in an explosive atmosphere Keep product surfaces clean and dry Measurement Category The Re:load Pro is intended to be used for measurements in Measurement Category I. Re:load Pro User Manual... - Page 4 • Open Source, with a USB bootloader, so firmware can be modified and upgraded without expensive development tools. The Re:load Pro was made possible by the generous support of 361 back- ers on Kickstarter. 2. Calibration Before initial use, calibrate the Re:load Pro. The calibration procedure re- quires test leads, a power supply capable of supplying at least 2 amps DC, and a current meter, either integrated into the PSU or discrete.
-
Page 5: General Usage
3. General Usage 1. Attach a USB cable between the Re:load Pro and a computer or USB power source. The Re:load Pro will boot up and display the splash screen. After 3 seconds, this will clear to display the readouts. -
Page 6: Display Configuration
Arachnid Labs vent damage to the device in case of overtemperature. If this engages, the Re:load Pro will set its current limit to 0, and display a message indicating an overtemperature condition. Pressing enter dismisses the message and allows you to resume using the device as normal. -
Page 7: Factory Reset
Should user data become corrupted or invalid, it may be necessary to perform a factory reset. To perform a factory reset, plug the Re:load Pro into a USB power source or computer, and wait for the splashscreen to display. As soon as it does, press the knob in, and hold it until the main display is shown. -
Page 8: Specifications
Ambient Temperature Operating 10°C ~ 40°C Non-operating -20°C ~ +60°C Cooling Natural Convection Humidity ≤90% Relative Humidity Altitude Operating 3,000m or below Non-operating 15,000m or below Mechanical Size Width 112mm Height 59mm Depth 120mm Weight 510g Re:load Pro User Manual...
