Summary of Contents for Swiss Rotors CA-2-27
- Page 2 Please read the following documentation carefully before performing installation, maintenance and operating of Swiss Rotors rotary heat exchangers motors. In case of doubts contact Swiss Rotors official support. This manual must only be used by a qualified installer/service technician. TABLE OF CONTENT 1.
- Page 3 The following instruction, unless otherwise stated, applies to all Swiss Rotors counterflow heat exchangers. In exceptional circumstances, differences will be noted. This document is a property of Swiss Rotors, licensors or affiliates, protected by international trademark and copyright laws. Swiss Rotors constantly develops its products and this document is...
- Page 4 2.1 Construction Swiss Rotors produces series of counterflow heat exchangers in two types of materials - with aluminum or polymer plates with casing made of Aluzinc. The core is made of plates joined together in a define distance of 2 or 3 mm depending on a chosen type.
- Page 5 2.2 Operational limits Our counterflow units are prepared to work within temperature conditions oscillating between -40oC and +70oC for the aluminum plates and -20oC up to +50oC for polymer plates. Maximum differential pressure between supply and exhaust airflow – for both aluminum and polymer exchanger is equal to 800Pa. We strongly recommend keeping the maximum pressure drop beneath 300Pa.
- Page 6 Pay attention to the way in which the goods were delivered. – Fig.3. Swiss Rotors prepares shipments using professional labels and Figure 3. Packing model transport descriptions. If you see that the shipping company did not follow the instructions - refuse to accept the parcel.
- Page 7 5. MAINTENANCE & CLEANING 5.1 Maintenance Swiss Rotors strongly recommends checking the condition of exchangers systematically. Technical control is obli- ged to the user. Properly frequent checks allow early detection of irregularities in the system and may help avoiding serious damages resulting from various random factors. Please refer to our general proposed inspection checklist and timetable presented below.
- Page 8 It may turn out that self-cleaning effectiveness is insufficient in given work environment and some manual cleaning will be necessary. Swiss Rotors recommends following methods of cleaning: •...
