Part A: Front Wheel Bracket
Part D:
Part E:
Front Support Plate
Back Support Plate
Part H: Handles (x2)
Part J:
Part K:
Front Wheels (x2)
Back Wheels (x2)
FRONT
ASSEMBLED BIG-4 WHEELER
Wheeler
COMPONENTS
Part B: Back Wheel Bracket
Part C: Support Straps
Part F:
Part G: Leg Supports (x2)
Front Bump Bracket
Part I: Hardware
Part L: 8 or 10 cubic ft Tray
TOOLS NEEDED
BACK
• RATCHETS:
1/2
"
and 24mm
• WRENCHs:
"
1/2
and 24mm
• SCREWDRIVER
COMPONENTS LIST
• Front Wheel Bracket
• Back Wheel Bracket
• Support Straps
• Hardware:
• Front Support Plate
- 3" round head bolts : 8pcs
• Back Support Plate
- 2-1/4" round head bolts : 2pcs
• Front Bump Bracket
- 1" hex bolt with washer : 10pcs
• Leg Supports (2)
- 1" round head bolts : 2pcs
• Handles (2)
- Nuts: 22pcs
• Front Wheels (2)
- Big nuts : 4pcs
• Back Wheels (2)
- Big washer: 4pcs
• 6 cubic ft Tray
- Rubber washer : 4pcs
BIG-4
8 and 10 Cubic Foot Wheelbarrow
Let the BIG-4 Wheeler DO THE WORK FOR YOU!
Just Push it! NO LIFTING or BALANCING!
10 cb ft
HOLDS
UP TO
8 cb ft
500 LBS
HOLDS
UP TO
400 LBS
Wheeler
LITTLE-4
Wheeler
ASSEMBLY
INSTRUCTIONS
and component list
WARNING: Not a toy
Distributed by:
Custom Quest
www.custom-quest.com
866-346-2250
© 2012 Made in China
