- Page 1 Operation Manual TACTICAL ResQmax the NEW Generation " T h e G l o b a l L e a d e r i n i n t r i n s i c a l l y s a f e l i n e - t h r o w i n g e q u i p m e n t "...
- Page 2 Manufacturer. The Tactical ResQmax is extremely powerful and propels a Projectile at high speed. It is NOT a firearm, but the same precautions should be used. If misused, this equipment could cause serious bodily injury or death.
-
Page 3: Table Of Contents
Table of Contents Introduction ....................5 Purpose of the Tactical ResQmax..................5 Applications ..........................5 Performance Range .........................5 Safety Features ...........................6 Multi-Shot Capacity ........................6 Fueled by Compressed Air .....................6 Main Components & Accessories ..............7 Launcher ............................7 Line Containers ..........................7 Folding Stock ..........................7 Streamline Filler Hose Assembly ..................8... - Page 4 Connecting the Lines ......................23 Climbing Grappling Hook ....................24 Preparing the Climbing Grappling Hook for Deployment ........24 Deployment ....................26 Deploying the Tactical ResQmax ..................26 Maintenance ....................27 Care of the Projectile ......................27 Care of the Launcher ......................27 Replacing the O-Rings in the Nozzle Valve ..............
-
Page 5: Introduction
Introduction Purpose of the Tactical ResQmax The Tactical ResQmax is a new generation tactical line-throwing appliance fueled by compressed air, specifically designed to deploy: • a line only • a grappling hook and climbing line • a grappling hook and ascending ladder to an otherwise inaccessible point in both land-based and maritime environments. -
Page 6: Safety Features
CAUTION: The use of any other compressed gas, either flammable and/or air mixture that combustible (including nitrox or other oxygen-enhanced mixtures), may result includes an in a spontaneous explosion causing severe injuries or death. elevated level of oxygen. Tactical ResQmax Operation Manual... -
Page 7: Main Components & Accessories
Figure 2 - Launcher, left side view Line Containers #772 and #773 The Line Container for your Tactical ResQmax is selected according to the length and diameter of the Line used. Some line options require the Large Line Container (Fig. 1) while others may utilize the Compact Line Container (Fig. -
Page 8: Streamline Filler Hose Assembly
Projectile. Please ensure that your Streamline Filler Hose is equipped with proper fitting for your source of compressed air. A complete list of available adapters is outlined below. Multiple fittings may be supplied with each Tactical ResQmax to permit charging from multiple air sources if required. -
Page 9: Projectiles
Each hook is treated with EFEX Sound Signature Reducer. Design Rating: Figure 6 - Climbing Ultimate Strength of 2,200 lbs / 1,000 kg. Grappling Hook #750 Recommended loads not to exceed 730 lbs / 330 kg. Tactical ResQmax Operation Manual... -
Page 10: Climbing Line And Tactical Ladder Options
When equipped with an extending handle and rollers, these cases are used for transport and storage of your unit (Fig. 9). Figure 9 - Pelican Transport/Storage Case #908 Tactical ResQmax Operation Manual... -
Page 11: Launcher
2. Fold the Folding Stock over the top of the Launcher (Fig. 9b - Step 2). 3. Engage the butt of the Folding Stock with the sighting hook on the front of the Launcher (Fig. 9b - Step 3). Step 3 Step 1 Step 2 Figure 9b - Collapsing Folding Stock Tactical ResQmax Operation Manual... -
Page 12: Connecting The Launcher To The Line Container
2. Slide the Launcher back and out of the “dead end” from the Launcher grooves on the Line Container (Fig. 10b Eyelet in order - Step 2). to disconnect the Line Container from the Launcher. Figure 10b - Disconnecting Launcher from Line Container Tactical ResQmax Operation Manual... -
Page 13: Operating The Safety Push Knob
This arm provides – indicating that the Safety Assembly has been for easy use if re-engaged and the Safety is in the ON position the end-user is (Fig. 11a). wearing gloves. Figure 11c - Reset Safety Tactical ResQmax Operation Manual... -
Page 14: Loading The Projectile In The Launcher
Cut-Away Pin which fastens the Line Container Door closed (Fig. 22, pg. 23). Align Nozzle Protector & Mechanism Correctly Figure 12a - Align "V" Groove Bridle Lines “V” Groove Quick-Link Figure 12b - Line Projectile with Bridle Lines Tactical ResQmax Operation Manual... -
Page 15: Operating The Nozzle Valve To Pressurize The Launcher
Nozzle Valve (Fig. 13a). Step 2: Step 2: Rotate Rotate Step 1: Step 1: Press In Press In Figure 14 - Opening Nozzle Valve Figure 15 - Closing Nozzle Valve Tactical ResQmax Operation Manual... -
Page 16: Operating The Launcher Bleed Screw
Operating the Launcher Bleed Screw Each Launcher is equipped with the Bleed Screw – located near the Tactical ResQmax label on the Launcher (Fig. 16a). The Bleed Screw Handle swivels over the Bleed Screw Bolt to permit the Note: Bleed Screw to be turned without interfering with the Folding Stock. -
Page 17: Projectiles
Projectiles Using the Line Projectile Note: A black Projectile Protector (Fig. 17a) is recommended when deploying a Line with the Tactical ResQmax. Each Any damage to Line Projectile is supplied with a Projectile Protector the Projectile slipped over the Projectile Cylinder. -
Page 18: Filling The Projectile
Filler Block (Fig. 18c) and insert the neck of the Quick Coupler inside the Nozzle Protector to connect the Filler Hose to the Figure 18c - Figure 18d - Nozzle (Fig. 18d). Retract Collar Attach Filler Hose Tactical ResQmax Operation Manual... - Page 19 Bleed Screw, draining pressure will be reduced to pressure from the Filler Hose Assembly. approximate the service pressure. Drain Port Open / Close Bleed Screw Figure 18h - Bleed Air from Filler Hose with Bleed Screw Tactical ResQmax Operation Manual...
-
Page 20: Storing The Projectile
CAUTION: If the Projectiles are subjected to extreme heat, the pressure could rise sufficiently to rupture the Pressure Relief Assembly allowing the air to escape and temporarily preventing use of the equipment. Refer to page 29 for instructions on removing and replacing the Pressure Relief Assembly. Tactical ResQmax Operation Manual... -
Page 21: Checking Projectile Pressure
“0” (refer to page 16). 4. Disengage the Safety Assembly by pressing the Safety Push Knob (refer to page 13). 5. Pull the Trigger to release the Projectile into your hand or the ground. Tactical ResQmax Operation Manual... -
Page 22: Payloads
Payloads Packing the Climbing Line All lines used with the Tactical ResQmax may be repacked in the field by hand as necessary, Note: without a use of any special equipment. Each Line has a dedicated “dead end” and “live end”... -
Page 23: Packing The Ascending Tactical Ladder
“Live end” will Attach to Grappling Hook Eyelet or to the Line Projectile Secure “dead end” to Launcher Eyelet Figure 21 - Tactical Ladder does Figure 22 - Climbing Line not have a “dead end” “live and dead ends” Tactical ResQmax Operation Manual... -
Page 24: Climbing Grappling Hook
4. Fasten the Line to the neck of the into the grooves Projectile with the Velcro strap provided on the side of (Fig. 23c). the Launcher Barrel when Velcro Strap the Projectile is engaged. Figure 23c - Attach Line to Projectile Tactical ResQmax Operation Manual... - Page 25 Figure 23e - Align Line and Bridle Lines along (Fig. 23f) . each side of Projectile Bridle Lines attached to loop with Cut-Away Pin “Dead End” Secured to Eyelet on Launcher Figure 23f - Line and Climbing Grappling Hook Ready for Deployment Tactical ResQmax Operation Manual...
-
Page 26: Deployment
Deployment Deploying the Tactical ResQmax 1. Conduct a visual inspection to ensure that the Bridle Lines are properly connected to the Note: “live end” of the Line and that the “dead end” of the Line is connected to the Eyelet on the Launcher if applicable (Fig. -
Page 27: Maintenance
Launcher Bleed Screw is properly tightened (refer to page 16). If the Launcher Bleed Screw is closed and the leakage persists, the Mechanism O-ring should be checked and replaced if necessary; please contact the Manufacturer for instructions or service. Tactical ResQmax Operation Manual... -
Page 28: Replacing The O-Rings In The Nozzle Valve
If the Projectile is unable to hold air, the O-rings on the Nozzle Plug in the Nozzle Valve may have become worn or damaged and it will be necessary to replace them. Only use the O-rings supplied by Rescue Solutions International, Inc. These O-rings are of a special composition and hardness and are specially selected for this purpose. - Page 29 8. Remove the Installation Tool and verify that all O-rings are properly seated on the Nozzle Plug (Fig. 28c). 9. Lubricate the new O-rings with petroleum jelly. 10. Lubricate the bore of the Nozzle and the Nozzle Plug with a light film of petroleum jelly. Figure 28c Tactical ResQmax Operation Manual...
-
Page 30: Replacing The Nozzle Pressure Relief Assembly
T30 Torx wrench (Fig. 30 - supplied in the optional ResQmax Tool Kit). 2. Clean the opening and lightly lubricate with Corrosion Block. 3. Install a new Pressure Relief Assembly (Fig. 26, pg. 28). Figure 30 - Torx Wrench and Pressure Relief Assembly Tactical ResQmax Operation Manual... -
Page 31: Service
Manufacturer in the repair of this equipment. Please contact your Rescue Solutions International, Inc. distributor for more information or the Manufacturer by calling 800-709-5018 or by e-mail at info@resqmax.com. Tactical ResQmax Operation Manual... -
Page 32: Service & Maintenance Record
Service & Maintenance Record For your protection, please ensure that this record is kept with your Tactical ResQmax and updated. When sending your Tactical ResQmax in for service, this record must be included. Date of Purchase: ResQmax Serial #: Projectile Serial #:... -
Page 33: Frequently Asked Questions
Launcher? positions. Which ever position permits the Valve Key to fully depress will represent the position of the Nozzle Valve. If horizontal, the Nozzle Valve is Open. If vertical, the Nozzle Valve is Closed (page 15). Tactical ResQmax Operation Manual... - Page 34 (pages 28 and 29). If none of these steps solves the problem, please contact your Rescue Solutions International, Inc. distributor for assistance. I accidentally tried to fire When you prepare to fire the Launcher, the Mechanism is t h e L a u n c h e r w i t h o u t under pressure.
-
Page 35: Limited Warranty
90 days of discovery of the problem. You will be given instructions on where to send your Tactical ResQmax for repair or replacement. If the problem is covered by this warranty, Rescue Solutions International, Inc. will repair or replace your Tactical ResQmax, or otherwise notify you, within 30 days of receipt of the Tactical ResQmax. -
Page 36: Technical Specifications
19.48 49.5 37.7 17.1 Pelican Cases material: Copolymer with Black finish. *Please Note: All values are displayed as maximum, external measurements. ©2014 Rescue Solutions International, Inc 708 SW Umatilla Ave Redmond, OR 97756, USA TACTICAL Phone: 541-504-9300 Fax: 541-504-9301 ResQmax e-mail: info@resqmax.com...
