Summary of Contents for ROTOSHOVEL ROTOSHOVEL
- Page 1 Operation Manual Read before use to ensure operator safety. Document Version 201208A Richard Goren Enterprises LLC. All Rights Reserved...
- Page 2 United States Warranty Information ..............8 Richard Goren Enterprises LLC. 9010 Technology Ln. Fishers, IN 46038 (317) 360 – ROTO (7686) info@rotoshovel.com The latest instructional videos, safety information and operation manual can be found at rotoshovel.com Richard Goren Enterprises LLC. All Rights Reserved...
- Page 3 USER SAFETY This product is only for use by adults (age 18+). The Rotoshovel is not a toy. Keep work area clean and well lit. Do not operate power tool in the presence of explosive liquids, gases, or dust.
- Page 4 Do not use in wet conditions. Wet conditions increase the likelihood of electric shock. BATTERY SAFETY Only charge included batteries using the charger included with the Rotoshovel. Using other chargers brings the risk of fire or causing damage to the battery or charger. ...
- Page 5 Product Description Battery charger 12volt lithium-ion battery Rotoshovel – grip, controls, and motor Shovel backing Auger Allen wrench Auger Shovel backing Motor head Battery charge indicator Auger rotation directional switch Power switch Grip Battery Richard Goren Enterprises LLC. All Rights Reserved...
- Page 6 Operating Instructions Do not insert the battery until assembly is complete. 1. Line up the shovel backing to the chuck-end of the Rotoshovel. 2. Twist the shovel backing clockwise to fasten securely. 3. Secure Allen bolt to shovel backing. Richard Goren Enterprises LLC. All Rights Reserved...
- Page 7 4. Insert the auger into the chuck-end of the Rotoshovel. 5. Hold the chuck bottom and rotate the top clockwise to tighten. 6. Insert a battery into the tail end of the Rotoshovel. 7. Ensure proper functionality before worksite use.
- Page 8 1. Ensure a stable footing before operating to provide adequate control while digging. Do not step on the Rotoshovel! 2. The Rotoshovel is designed to dig dirt efficiently. Do not attempt to dig other materials. 3. If the Rotoshovel hits an obstacle, the motor will automatically stop.
