control4 GSM Gateway Setup

Roger Althaus

control4all

13.06.2014

Table of Contents

Need help?

Do you have a question about the control4all and is the answer not in the manual?

Questions and answers

Summary of Contents for SenseNet control4all

Page 1 2014 control4 GSM Gateway Setup Roger Althaus control4all 13.06.2014...
Page 2: Table Of Contents
Prepare control4 System ............................4 Configure GSM Gateway ............................. 5 Logon to Gateway ..............................5 Network Settings ..............................5 Route Settings ................................6 SIP Settings .................................. 8 Troubleshoot ..................................10 control4all by SenseNet GmbH Guldifeld 42 3182 Ueberstorf 031 742 11 21 www.control4all.ch...
Page 3: General
General Introduction This Document describes the integration of the control4all Mobile Gateway into a control4 system. Features Ring to a external Phone when someone is Ringing at the Doorstation with 2-way Audio.* Trigger the Door Relay to open the Door. * Ring from a external Phone to a Panel or Intercom Group.
Page 4: Installation
Place the Card that the Edge of the Card is right in front to you  Close the Cover  Connect the Antenna, Ethernet and Power Supply. control4all by SenseNet GmbH Guldifeld 42 3182 Ueberstorf 031 742 11 21 www.control4all.ch...
Page 5: Configuration
Goto “System Design”  Add „3rd Party SIP Phone“ Driver to Project  Enter desired Username and Password (i.e. User “100” and Password “1234”)  Click “Apply” control4all by SenseNet GmbH Guldifeld 42 3182 Ueberstorf 031 742 11 21 www.control4all.ch...
Page 6: Configure Gsm Gateway
(default: 192.168.0.100)   Enter Default Username “voip” and Password “1234”  Click “Login” Network Settings Verify Network Settings. We recommend to use static IP Address Configuration. control4all by SenseNet GmbH Guldifeld 42 3182 Ueberstorf 031 742 11 21 www.control4all.ch...
Page 7: Route Settings
Route Settings LAN to Mobile Position * = any IP allowed to Dial, or i.e. Subnet 192.168.3 only. CallNum Number to dial control4all by SenseNet GmbH Guldifeld 42 3182 Ueberstorf 031 742 11 21 www.control4all.ch...
Page 8 The Rule Number. The Fist matching is taken Caller ID. If you put a “*” any call is accepted. The Format is: <panel_mac_id>@<controller_ip> for a Single Panel <intercom_group>@<controller_ip> for a Intercom Group control4all by SenseNet GmbH Guldifeld 42 3182 Ueberstorf 031 742 11 21 www.control4all.ch...
Page 9: Sip Settings
DTMF Setting These Settings are important if you want to able to trigger the Relay on the Koch-Doorstation. This can be done by pressing “*7” on the called phone. control4all by SenseNet GmbH Guldifeld 42 3182 Ueberstorf 031 742 11 21...
Page 10 Due an incompatibility on the control4 SIP implementation make sure that ”183 Session in Progress” is set to OFF. All other Settings on the Gateway can be left as default. control4all by SenseNet GmbH Guldifeld 42 3182 Ueberstorf 031 742 11 21...
Page 11: Troubleshoot
