Hindon L Series Manual

Vibrators are heavy duty industrial rotary electric vibrators

Advertisement

Quick Links

SECTIONS
1.0
INTRODUCTION........................................................................................................ 1
2.0
RECEIPT AND STORAGE........................................................................................ 1
3.0
INSTALLATION ......................................................................................................... 2
3.1 Mechanical ............................................................................................................ 2
3.1.1 Vibrator Mounting..................................................................................... 3
3.2 Electrical ............................................................................................................... 4
3.2.1 Cable Connection .............................................................................. 4 & 5
3.2.2 Twin Vibrator Applications ...................................................................... 5
3.2.3 Thermistor Wiring....................................................................................... 5
4.0
OPERATION................................................................................................................ 5
4.1 Electrical................................................................................................................ 5
4.2 Mechanical ............................................................................................................ 6
4.3 Start-up .................................................................................................................. 6
5.0
MAINTENANCE .......................................................................................................... 7
5.1 Routine Maintenance ............................................................................................ 7
5.2 Bearing Lubrication................................................................................................ 7
5.2.3 Models BL 40 to BL 75.............................................................................. 8
5.3 Vibrator Overhaul .................................................................................................. 8
6.0
TROUBLESHOOTING ............................................................................................. 10
6.1 Vibrator Is Not Running....................................................................................... 10
6.1.1 Verify Correct Voltage ............................................................................. 10
6.1.2 Verify Terminal Connections ................................................................... 10
6.2 Vibrator starts but will not continue to run ................................................. 10 & 11
6.4 Vibrator surface temperature is excessive............................................................ 11
6.5 Noisy vibrator.............................................................................................. 11 & 12
6.7 Twin vibrators not synchronizing......................................................................... 12
FIGURES
Figure 1 Illustration of Vibrator Out of Balance Weight ............................................................. 2
Figure 2 Terminal box connections for 460 Volt, 3 Phase, 60 Hz operation............................... 5
Figure 3 Terminal box connections for 230 Volt, 3 Phase, 60 Hz operation............................... 5
Figure 4 Proper Thermistor Winding........................................... ................................................. 6

TABLE OF CONTENTS

DESCRIPTION
DESCRIPTION
i
PAGE
PAGE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hindon L Series

  • Page 1: Table Of Contents

    TABLE OF CONTENTS SECTIONS DESCRIPTION PAGE INTRODUCTION......................1 RECEIPT AND STORAGE..................1 INSTALLATION ......................2 3.1 Mechanical ......................2 3.1.1 Vibrator Mounting..................3 3.2 Electrical ....................... 4 3.2.1 Cable Connection ................4 & 5 3.2.2 Twin Vibrator Applications ..............5 3.2.3 Thermistor Wiring..................
  • Page 2 TABLE OF CONTENTS (Cont'd) TABLES DESCRIPTION PAGE Table 1 Vibrator Internal Fastener Torque Values and Tension............3 Table 2 Vibrator Mounting Bolt Torque Values (NC Threads) ............4 Table 3 Bearing Relubrication Intervals and Amounts ..............9 Table A-1 Vibrator No Load, Full Load, & Starting Currents for 3 Phase, 60 Hz ......A-1 Table A-2 Vibrator Normal Resistance Readings................
  • Page 3: Introduction

    • Use only personnel trained in the repair of Invicta Vibrators. As a point of interest, the L Series model designation includes an indication of maximum centrifugal force output. Actual force is 100 times the centrifugal force figure stated. Example:...
  • Page 4: Installation

    INSTALLATION Mechanical Ensure shaft rotates freely by hand prior to mounting. This will require removing one end cover to access the out-of-balance (O.B.) weights. Unless otherwise requested, vibrators are supplied with the O.B. weights set to give a maximum centrifugal force output. To adjust O.B. weights to the required force output, follow these steps and refer to Figure 1.
  • Page 5: Vibrator Mounting

    INTERNAL FASTENERS O/B WEIGHT FASTENERS SIZE (EXCLUDING O/B WEIGHTS) * TORQUE (LBS-FT) SOCKET HEAD HEX HEAD SOCKET HEAD CAP HEX HEAD CAP SCREWS BOLTS SCREWS BOLTS * Values are for factory supplied fasteners. 3.1.1 Vibrator Mounting It is recommended that the fasteners (bolts, nuts and hardened flat washers) be a minimum of grade 5 and a maximum of grade 8.
  • Page 6: Electrical

    1 1/4" - 7 1105 1792 * Values are for non-lubricated, unplated carbon steel fasteners. Please contact Hindon for further information if other types of fasteners are to be used. Electrical It is a good policy, prior to vibrator mounting, to measure winding insulation resistance by meggering;...
  • Page 7: Twin Vibrator Applications

    STAR - 460 or 575 Volts DELTA - 230 Volts Figure 2: Terminal box connections for 460 Figure 3: Terminal box connections for 230 or 575 Volt 3 Phase, 60 Hz Volt, 3 Phase, 60 Hz operation. operation. Ensure foam packing is in place to protect electrical leads from vibration. Be sure to fit the rubber gasket or o-ring into place prior to installing the terminal box lid to ensure a watertight seal.
  • Page 8: Electrical

    SENSOR INPUTS ONE (1) SENSOR PER PHASE INTERNAL CONTACT SHOWN IN TERMINATED AT VIBRATOR "TRIPPED" CONDITION TERMINAL BOX 120 VAC INPUT RESET SWITCH TO CONTROL CIRCUIT VIBRATOR CONTROL MODULE TO SENSOR WIRING DIAGRAM Figure 4: Proper Thermistor Wiring OPERATION Electrical Prior to operation, ensure that the electrical voltage is correct and that feed cable(s) to the vibrator(s) are correctly sized for the load and mechanical requirements.
  • Page 9: Maintenance

    MAINTENANCE Routine Maintenance Routine maintenance deals predominantly with the proper lubrication of the vibrator bearings. The lubrication intervals and amounts vary greatly depending on the vibrator model and are further affected by outside factors such as duty cycle, ambient temperatures and operating environment.
  • Page 10: Models Bl 40 To Bl 75

    Due to the mechanical tolerances and specific reassembly procedures involved with these vibrator repairs, it is recommended that vibrators requiring full overhaul be shipped to Hindon Corporation. This is to ensure that factory qualified service and O.E.M. quality replacement parts will be used.
  • Page 11 Table 3: Bearing Relubrication Intervals and Amounts Relub. Interval * Grease Amount Initial Grease Fill Vibrator Model (Hours) Per Brg. (Ounces) Per Brg. (Ounces) 2 Pole BL 24/25-10/2 1600 BL 24/25-13/2 1400 BL 30 ALL BL 40-30/2 BL 40-40/2 BL 50-50/2 4 Pole BL 24/25-11/4 3500...
  • Page 12: Troubleshooting

    NOTE: The above tests can be performed with instruments such as resistance measuring devices and/or a megger. If sections 6.1.1 and 6.1.2 have been performed and vibrator is still inoperable, please contact Hindon Corporation for further assistance. Vibrator starts but will not continue to run Verify correct motor starter operation: Verify correct "heater"...
  • Page 13: Vibrator Current Consumption Is In Excess Of Table A-1 Ratings

    If vibrator surface temperature is in excess of 185° F. Record ambient temperature and advise Hindon (external fan cooling may be needed to cool the vibrator and reduce the risk of failure). Verify section 6.3. steps 1 thru 4.
  • Page 14: Noisy Vibrator

    Noisy vibrator NOTE: Vibrating machines are inherently louder than industrial motors. Check for loose or failed vibrator mounting fasteners. Check for loose end cover fasteners and internal fasteners. Check for loose O.B. weight clamping bolts. CAUTION: Always ensure electrical power is de-energized prior to handling rotor shaft with hands.
  • Page 15 APPENDIX A Additional Vibrator Specification Tables and Parts Lists...
  • Page 16 Table A-1: Vibrator No Load, Full Load & Starting Currents for 3 Phase, 60 Hz 230 Volt 460 Volt 575 Volt Vibrator Watts Model 2 Pole 3456 RPM 60 Hz BL 03-1/2 0.18 0.28 0.13 0.17 0.12 0.14 BL 05-2/2 0.32 0.53 0.23...
  • Page 17 Table A-2: Vibrator Normal Resistance Readings Resistance (OHMS per line) Vibrator Model 230 Volt 460 Volt 2 Pole BL 03-1/2 70.7 BL 05-2/2 36.8 BL 15-3.5/2 36.8 BL 20-5/2 17.1 51.2 BL 24/25 ALL 22.8 BL 30 ALL BL 40 ALL BL 50-50/2 4 Pole BL 03-0.5/4...
  • Page 18 Table A-3: Vibrator Parts List for Models BL 03 to BL 25 Part # Description Quantity Bearing Housing End Cover O/B Weight Assembly 1 set Bearing Rotor Shaft Assembly Terminal Box Sealing Ring (Models BL 05 -BL 25) Terminal Box Gasket (Model BL 03) Sealing Ring –...
  • Page 19 Table A-4: Vibrator Parts List for Models BL 30 to BL 75 Part # Description Quantity Bearing Housing Bearing Housing Cap End Cover Sealing Ring O.B. Weight Assembly 1 set Roller Bearing Rotor Shaft Assembly Sealing Ring - Terminal Box (BL 30 thru 50) Gasket - Terminal Box (BL 60 &...
  • Page 20 Table A-5: Factory Specified Vibrator Bearings Vibrator Model Hindon Part # Weight (lbs.) BL 03-1/2 PSN 364/4 0.09 BL 05 ALL PSN 1631/5 0.33 BL 15-3.5/2 PSN 1631/7 0.70 BL 15-3/4 PSN 1631/6 0.46 BL 20-5/2 PSN 1631/9 1.26 BL 20-5/4 PSN 1631/8 0.92...
