Divine Tribe v3 Ceramic Donut Atomizer Quick Start Guide
I want to use it now!
The atomizer works best with slow low draw hits. The donut takes a
couple seconds from cold to make vapor. Let off the fire button a few
seconds before you stop drawing. This helps keep the air holes open by
cooling any reclaim left in the atomizer. Load small
smaller. Usually three to five 10
a lot of material at once it will just leak out the air holes and into
–
the base. DO NOT suck like a vacuum cleaner
splatter all over the cap. Now to setup your mod.
My mod has TCR mode – Stellar!
10mm donut TCR 240 20-24 watts
●
13mm donut TCR 345 30-35 watts
●
The above settings should allow the temperature on the screen to be
pretty close to the donut. F or the best results using TC, lock your
atomizer resistance at room temperature. Don't be afraid to tweak
these settings higher TCR number will make the donut hotter than
–
the screen number and a lower TCR number will make the donut temp
lower than screen number.
My mod does TC but not TCR – Your best bet here is to use Ni
mode at 30-20 watts and a temperature limit somewhat lower than
the desired donut temperature. The ideal TCR number for the donut
is between 200 and 400 while the TCR number for Ni is around
600. A temperature between 280-360 should yield donut temps
between 360 and 420. Lock your atomizer resistance when cold.
My mod doesn't do temp control (TC)
to make enough heat to vaporize oil, but getting to 400F will take 5
seconds or so. 20-30 watts heats the donut faster but you MUST
pulse the fire button to keep from blowing the donut. If you are using
a mod in wattage mod only, you probably already know this.
© Copyright DivineTribe ineedhemp.com 2017
–
bb size or
–
15s hits on that bb. DO NOT load
–
you'll just get
–
At least 12w are needed
–
Advanced TC configuration
F or those with an eLeaf, Joyetech or Wismec mod and are pretty
handy with computers. A windows computer or windows virtual machine
is required to run the NFE toolbox which provides for configuring and
loading the ArcticF ox firmware (AFF) onto your mod. Also provided is
a device monitor for real time monitoring of the mod in use. AFF
allows a profile based configuration with intelligent switching of up to 8
atomizers. AFF also has support for PI regulator temperature control
and fully customizable screen output. All configurations can be
performed on the mod or via the NFE Toolbox interface. If all of this
still makes sense and sounds like a good idea
back.
The process of reflashing the firmware is very simple. Download and
unzip the NFE toolbox from
https:/ /github.com/TBXin/NfirmwareEditor/releases
recent build of the AFF from
https:/ /github.com/ maelstrom2001/ArcticF
Plug your mod into the USB port on your computer and launch
Ntoolbox.exe. Use 'Firmware Updater" to reflash your mod. Choose the
AFF .bin file you downloaded.
Now you can configure profiles using "ArcticF ox Configuration". Start
with the same TCR configuration to the left. Then click the "setup"
button next to temp control and enable PI-Regulator. The percentage
value is when the PI-Regulator kicks in
enabled from start to finish while a number indicates percent of
desired temperature. I leave 0% and set P=1000 and I=20. Testing
with an IR thermometer with emissivity set to 0.65 shows my donut
temp tracks within 10F of the displayed temperature. I create one
profile for 10mm donuts and one for 13mm donuts. I also like to
increase the puff cutoff time to 15 seconds on the "Advanced" tab.
(ArcticF ox Firmware)
proceed, you won't look
–
and the most
ox.
a zero value means it's
–
