MAXBrite Tri-Proof LNW-55K2430 Quick User Manual

Hide thumbs

Tri-Proof

YEAR

WARRANTY

IP65

Part Number

CCT (Kelvin)

LNW-55K2430

5500K

LNW-55K4845

5500K

LNW-55K6060

5500K

LED Type / PCS

Power Consumption

SMD 2835 / 192 LEDs

30 WATT

SMD 2835 / 264 LEDs

45 WATT

SMD 2835 / 384 LEDs

60 WATT

Luminaires

Triple Protection Refined Solution

Luminous Flux

Voltage

2,850lm

100-277V AC

4,250lm

100-277V AC

5,700lm

Viewing Angle

Weight

120°

3.5 lbs.

23-5/8'' x 3-1/ 2'' x 2-7/8''

120°

6.0 lbs.

47-1/4'' x 3-1/2'' x 2-7 /8''

59-1/16'' x 3-1/2'' x 2-7/8''

120°

7.5 lbs.

Dimension

Table of Contents

Need help?

Do you have a question about the Tri-Proof LNW-55K2430 and is the answer not in the manual?

Questions and answers

Summary of Contents for MAXBrite Tri-Proof LNW-55K2430

Page 1 59-1/16’’ x 3-1/2’’ x 2-7/8’’ LNW-55K6060 5500K SMD 2835 / 384 LEDs 60 WATT 100-277V AC 5,700lm 120° 7.5 lbs. © 2016 MaxBrite LED Lighting Technology - 1740-B Junction Ave. - San Jose, CA 95112 - Toll Free: 1-800-297-2210 - Fax: 1-408-437-1602 | www.maxbriteled.com...
Page 2 PVC End Caps SYSTEM DIMENSIONS Polycarbonate Lens 23-3/4’’ 3-1/2’’ LNW-55K2430 47-1/4’’ 3-1/2’’ LNW-55K4845 59-1/4’’ 3-1/2’’ LNW-55K6060 © 2016 MaxBrite LED Lighting Technology - 1740-B Junction Ave. - San Jose, CA 95112 - Toll Free: 1-800-297-2210 - Fax: 1-408-437-1602 | www.maxbriteled.com...
Page 3 Connect NEMA 3-Conductor lead to 100-277V AC input source Appropriate Hardware Mounting Bracket Included Appropriate Anchors © 2016 MaxBrite LED Lighting Technology - 1740-B Junction Ave. - San Jose, CA 95112 - Toll Free: 1-800-297-2210 - Fax: 1-408-437-1602 | www.maxbriteled.com...
Page 4 These products are guaranteed to be free from defects in materials and workmanship for the warranty period stated below, as long as the MaxBrite LED products and Power Supplies are used together as a system. If any LED product or Power Supply fails to perform, as specified during the warranty period in accordance with the terms and conditions set forth herein, MaxBrite LED will replace, or at its discretion, repair free of charge, the non-performing product on a pro-rata basis.
