Summary of Contents for ReForms TETSU 532
- Page 1 TETSU Portable Laser Tattoo Removal Machine 532 | 1064 | 1320...
- Page 2 Portable Laser TattooRemovalMachine User&Trainning Manua FQ015 第 一 章...
-
Page 4: Table Of Contents
Contents - The process of Removal Red and other color Tattoo Treatment Principle Technical Parameter Technological Advantages Application User Tips Product Specifications Important safety information Warranty service Interface operation Service cost charging Please refer to the following table Accessory for troubleshooting before requesting service How to use this machine? -
Page 5: Treatment Principle
Treatment Principle The energy of Q-Switched ND: YAG Laser can be absorbed by the blue and black melanin. The melanin will be fragmented so small that they can be metabolized by the lymphatic system or be egested out of the body. Thus the tattoo or other pigmentations will be removed without injury to normal tissue. -
Page 6: Technological Advantages
Technological Advantages • With the 5 times continuous each second’s amount to 10000 light points to produce when the indoor temperature reach to 30 degrees，it has obvious advantage comparing with other similar products. • With the multi-language interface (8 languages), which has been favour with overseas and domestic customers •... -
Page 7: User Tips
User Tips Before the machine start work ,you should add full water for it. ★After open the packing box of the machine ,install the laser handpiece and the foot switch of the machine . ★Then use the Water Funnel add water for the machine ★When add the water ,we should observe the water line which is on the left side of the machine.This machine can hold water about 2500ml. - Page 8 Be sure to keep the metal pins of the power plug free from dust or moisture.When cleaning,use a cloth-cleaner. Using multiple products on a single outlet is not recommended. Keep the unit and the power plug away from heaters or stoves. Do not pull the power plug by force or with wet hands.
- Page 9 Injury may occur when the following instructions are not Warning followed. Do not beam direct on to unshielded eyes.Do not use the unit to eyes or eyelids. The unit is not to be used by children or persons with reduced physical,sensory or mental capabilities ,or lack of experience and knowledge,unless they have been given instruction.
-
Page 10: Interface Operation
Do not use to this devise if you…… Are photosensitivity or sun allergy patients(porphyria,polymorphous light eruption ,transient urticaria ,erythematous) Yes/No Are wound or skin closure strips Yes/No Have tattoo dye allergy and granuloma formation. Yes/No Are administered with a heart pacer ,insulin pump,or any other medical device. Yes/No Have had skin cancer or has a higher chance of contracting skin cancer。... - Page 11 Open the machine. Connect with the energy line Add water Add as more as the machine can,when the water spill out,then stop to add water. If without water,the machine will be burn.
-
Page 12: Accessory
Accessory 532nm/Black doll/1064nm Laser Handpiece A Water Funnel A Power Cord Care-protective Glasses Protective Goggles... -
Page 13: How To Use This Machine
How to use this machine? - The process of Removal Black and Royal Dark Blue Tattoo 1 Pre-operation 1）Shaving Shave the hair for the treatment area with razors. ★Users must wear the care-protective glasses when operate the machine 2）Cleaning Clean the treatment skin area and make sure it is dried and free from grease or oil. 2 Operation 1）Checking the Treatment head Check if the treatment head is use for “Black and Royal Dark Blue... - Page 14 Setting the machine If this is new machine ,please start with Power 500mj ★As different person’s skin condition is different ,users can adjust the POWER from 100mj to 2000mj。 ★If the users are the first time to operate the machine ,we suggest to adjust the FREQ 2 or 3. ★For the user’s ease ,the Fluence and Frequency will be saved when it is OFF and ON again.
- Page 15 Post-operation ☆After treatment, softly using cotton bud clean the treatment area Then we should smear a thin layer of the repair ointment on the treatment area,2-3 times a day. ☆Do not use water washing treatment area within 3 days. ☆After terminate the procedure, if blisters or vesicles appear on the site area. ☆If the blisters or vesicles is big, with a sterilized needle punctured it.
-
Page 16: The Process Of Removal Red And Other Color Tattoo
- The process of Removal Red and other color Tattoo 1 Pre-operation 1)Shaving Shave the hair for the treatment area with razors. ★Users must wear the care-protective glasses when operate the machine 2) Cleaning Clean the treatment skin area and make sure it is dried and free from grease or oil. 2 Operation 1) Checking the Treatment head Check if the treatment head is use for “Black and... - Page 17 Setting the machine If this is new machine ,please start with Power 500mj ★As different person’s skin condition is different ,users can adjust the POWER from 500mj to 1000mj。 ★If the users are the first time to operate the machine ,we suggest to adjust the FREQ 2 or 3. ★For the user’s ease ,the Fluence and Frequency will be saved when it is OFF and ON again.
- Page 18 When the unit emit the handpiece should be vertical snapping the skin Checking the reaction after treatment When have operate the entire treatment area , the skin will be slight bleeding and redness. Post-operation ☆After treatment, softly using cotton bud clean the treatment area Then we should smear a thin layer of the repair ointment on the treatment area,2-3 times a day.
-
Page 20: Technical Parameter
Technical Parameter Voltage AC 110V-240V/50-60Hz Laser wave length 1064nm/532nm/Black doll The pulse energy 1-2000mj Pulse width 1-6P/S Screen 8 inches touched screen Gross weight 15Kg Measure 56*46*45cm Q:Is the Laser harmless if I see it direct? A. We have equipt the care-protective glasses for the users Q:What is the lamp life? A. - Page 21 Q: If we need to replace the water after finished the treatment every time? A. It is no need to replace every time,unless the machine is overheated,but we need to operate it in a short time ,we can choose to replace the half of hot water in the machine to cold water .
-
Page 22: Product Specifications
It remove all color tattoo? * The laser is with 1064nm & 532nm treatment heads. The 1064nm remove black, brown, cyan color pigment and the 532nm removes red, bule, coffee, yellow and other color pigment. How many times needed to remove all tattoo? * It depends. -
Page 23: Warranty Service
The design and specifications may be subject to change without prior notice in order to improve the product performance. Warranty service Within the Warranty After the Warranty Consumer service information period period Service requested within a year from the Replace the product part Not applicable date of purchase under normal use or operation Defects in workmanship or... -
Page 24: Service Cost Charging
Service cost charging *please be sure that you read the warranty and troubleshooting information before sending the unit to service. In case you ask the unit to service is not out of order, just caused by misconceived defects as one of following reasons, you will be charged the cost of expenses 1.if the defects are caused by any other means than cleaning, adjusting instruction or installation. -
Page 25: Please Refer To The Following Table
Please refer to the following table for trouble shooting before requesting service Symptom Checkpoint Troubleshooting Make sure that the power connection is Check the power securely in placeTurn off the unit for 30 connection.Ensure the unit is minutes to relieve overheating or connected to AC power.Check if replace the hot water in the machine to the unit is overheated. - Page 26 CALL US at : 9810866966/8383846378...
