compact
Ø 10 mm
inStruction manual
WarNING!
the laser light emitted by this unit may be in the infrared (non-visible) region of the electromagnetic
spectrum. avoid exposure to direct or scattered radiation from the laser. use extreme caution at all times
when the laser is in use.
the output power of these laser devices is sometimes high enough to cause permanent damage to the
human eye. You should wear appropriate laser safety goggles at all times when the laser is operational.
all laser safety warning labels are provided on the unit and be taken into note. Warning labels comply
with iec-60825-1:2014.
Structured light and
laSer beam Shaping SolutionS
laser module
Advertisement
Table of Contents
Related Manuals for OSELA COMPACT LASER
Summary of Contents for OSELA COMPACT LASER
- Page 1 Structured light and laSer beam Shaping SolutionS compact laser module Ø 10 mm inStruction manual WarNING! the laser light emitted by this unit may be in the infrared (non-visible) region of the electromagnetic spectrum. avoid exposure to direct or scattered radiation from the laser. use extreme caution at all times when the laser is in use.
- Page 2 operating the laSer the laser can be focused with the aid of a focusing tool provided with the laser, or any other similar tool • Fit the focusing tool in the notches as shown in the image. this will allow you to move the focal point •...
- Page 3 operating environment the lasers operating temperature range is from -10°c to 45°c. as a protection, at approximately 45°c the lasers will automatically shutdown. Full operation will resume once the laser falls within its normal working temperature range. using a heat sink with the laser is recommended. as with all semiconductor materials, avoid exposure to electrostatic discharges.
- Page 4 1869 32 avenue, lachine, Qc, h8t 3J1 canada info@osela.com 514 631.2227...
