HATRIA FUSION BATT YXC1 Installation And Maintenance

4 INSTRUCTIONS FOR CHECKING ND REPL CING B TTERIES
19
The electronic flushing system FUSION B TT is fed by 3 low-cost and readily available
batteries • The batteries used are of alkaline type of 1.5 V-Size
20
Vdc (3 x 1.5V). • The batteries durability is approx. 4 years for 200 operations per day • Do not
use rechargeable batteries • Purchase only batteries that have a stamped expiry date which is
a minimum of 4 years after the date of your purchase. This will ensure a long durability of batteries
and a correct use of your electronic flushing system FUSION B TT. • Do not replace the
batteries with wet or damp hands, in damp places or with damp tools. • Water must never be
inside the battery pack otherwise batteries will be immediately discharged!
21
When the red LED (2) (Fig. 2) starts to flash at regular intervals of 2 sec., it means that batteries
are being used up. However they will keep a residual period of operation which varies according
to the number of operations. To replace the batteries effect the following operations :
16
) Disconnect (16) the battery pack and the circuit.
B) Remove the cover (19) of the battery pack by unscrewing 4 screws (20). Take the batteries out.
C) Insert the new batteries in the battery pack by paying attention to the polarity + and -.
D) Remount the cover of the battery pack paying attention at the gasket (21) in its seat.
E) t this point it may be reset the connection (16) between the battery pack and the circuit.
FIG. 7
IT IS RECOMMENDED TO EFFECT THE DISPOS L OF THE USED UP B TTERIES CCORDING TO THE NORMS IN FORCE
5 CLE NING RULES
The urinal pod sensor's boady is in ST INLESS STEEL
therefore very resisitant to corrosive products. However it is
recommended, for cleaning the urinal pod to use warm water
and do not use abrasive detergents. To avoid damaging the
sensors do not use corrosive products or metallic, abrasive
sponges.
OTHERWISE THE W RR NTY WILL BE INV LID !
OVER LL DIMENSIONS
IN
MAX
fasteners
325
FISSAGGI
80
305
OUT
FIG. 9
CHECK
• The operation voltage is 4,5
REPL CEMENT
!
FIG. 8
ISI 316
mm
Hatria S.p.
tel. +39 059 384556 • fax +39 059 384212
venditeitalia@hatria.com •
exportdpt@hatria.com • www.hatria.com
A
FUSION B TT
ODE YX 1
Circuit version "SB39"
Flush when moving away
!
VT 04/10
Rev. 2
• BEFORE USING THE PRODUCT RE D C REFULLY THE INST LL TION INSTRUCTION S WELL S
THE ENCLOSED DRILLING DI GR M FOR MOUNTING THE CER MIC URIN L POD TO THE W LL.
• H TRI DECLINES LL LI BILITY FOR D M GE OR INJURY C USED BY THE F ILURE TO FOLLOW LL
THE INSTRUCTIONS PROVIDED IN THIS INSTRUCTION BOOKLET.
• THE PRODUCT'S OVER LL RELI BILITY ND DUR TION RE ENSURED BY CORRECTLY PERFORMING
LL THE OPER TIONS PROVIDED IN THIS BOOKLET.
• KEEP THIS BOOKLET IN
• THIS PRODUCT MUST BE INST LLED BY PROFESSION LLY QU LIFIED PERSONNEL.
• THE PLUMBING SYSTEMS CONNECTED TO THE EQUIPMENT MUST COMPLY WITH THE ST ND RDS
IN FORCE.
FUSION B TT
ELECTRONIC FLUSHING SYSTEM
LK LINE B TTERIES (3X1,5V) OPER TED
INST LL TION ND M INTEN NCE
INSTRUCTIONS ND DRILLING DI GR M FOR
MOUNTING THE URIN L POD TO W LL
ENG
S FE PL CE.
FOR URIN L POD
!
