SMO DIPLE Instructions

DIPLE
The Revolutionary Microscope For Any Smartphone
Thanks for purchasing DIPLE, a product designed and
manufactured by SmartMicroOptics Srl.
With your smartphone and DIPLE you can have a microscope
anytime. Within the portable box of size 175 mm x 100 mm x 40 mm
and in less than 0.5 Kg, you will get powerful and extra-solid lenses
and accessories for taking videos or pictures at the microscopic
scale, with your phone.
You do not have to mount anything on the phone; just lay your
device down on the DIPLE box, aligning the phone camera with
the objective lens and with the light source under it.
You can also use your phone without removing your personal
protective cover.
A minimal footprint for a microscope;
but extremely powerful.
Patent Pending
DIPLE
is a SMO Registered Trademark
SmartMicroOptics srl
Via Greto di Cornigliano 6R – 16152 – Genova – Italy
info@smartmicrooptics.com – www.smartmicrooptics.com
WARNING:
CHOKING HAZARD - Small parts.
Not for children under 3 years.
diple.smartmicrooptics.com
(*) depending on the purchased item.
Fine Stage:
with fine stage the user can move
a sample on common glass
Slide (76 mm x 26 mm) using two
screw-driven systems, along two
perpendicular directions. Rotating
the two wheels it is possible to
shift the slide positioned over the
light in controlled way. The Fine
Stage can be used also like the
Standard Stage, removing the
two lateral elements that keep the
glass slide or the slide shifter in
position.*
Standard Stage:
remove the protective film from
its surface; with the standard
stage, the user shifts manually the
sample under the DIPLE lens.*
Lens Tiles:
up to 3 different objective lenses.*
Red Lens (35x, res. 3 micron)
Grey Lens (75x, res. 1 micron)
Black Lens (150x, res. 0.75 micron)
Up to 3 screws for fine
regulation of the lens
elevation.*
3 prepared glasses:
1 Zoology, 1 Histology, 1 Botanical
+1 plain slide for your samples.
Optional:
1 microscope ruler
(0.01mm each division).
Slide Shifter:
use it under the glass slide, for
fast, manual shift of the sample.
Coverslips:
for covering your samples.
Box:
container & structure supporting
light, stage and your phone, when
the product is in use.
Light source:
white LED for brightfield
microscopy.
Works with two CR2032 batteries.
2 screw feet:
additional mechanical stands
for the phone, if the box is not
enough.
Screwdriver:
use it for releasing/adjusting
the blocks that keep the lens
tiles in position or, for the fine
stage, the elements that keep
the glass slide in position.
Pipette:
for liquid drops on slides.
