Summary of Contents for Airpatch 2AU4S-716

Page 1 E L E V A T E Y O U R P L A Y T H E B O A R D B E Y O N D Wireless Effects Pedal Controller Guide...
Page 2 What’s Included Controller + Attachment System Charging Cable Dock...
Page 3: Table Of Contents
Table of Contents TA B L E O F CO N T E N T S A I R PATC H D O C K PA I R I N G YO U R A I R PATC H A I R PATC H CO N T R O L L E R C H A R G I N G YO U R CO N T R O L L E R CO N T R O L L E R AT TA C H M E N T M A K I N G I T YO U R O W N...
Page 4 Airpatch Dock Select the eff ects pedals you want to use with your Airpatch and connect them between the Send and Return jacks on the Airpatch Dock. (See Figure A.1 for connection example.) The audio source connects to the Input jack...
Page 5: Pa I R I N G Yo U R A I R Patc H
Use your Airpatch Dock Button—with the Airpatch Sonic Bars—to cycle through modes and pair your Controller. Hold the Dock Button down for 3 seconds until the Dock’s LED starts blinking. Press your Airpatch Controller once to pair it. The Dock’s LED will then stop blinking and remain ON.
Page 6: Airpatch Controller
Airpatch Controller When you press your Airpatch Controller, the surface will ﬂ ash white. When the LED ﬂ ashes red, your battery is low (~1 hour remaining). If the light does not ﬂ ash at all, your battery is depleted and your...
Page 7: Charging Your Controller
Charging Your Controller Charge your Airpatch Controller with the magnetic USB cable provided and a standard 5V USB power supply. The magnetic charging connector is designed to ﬁ t one way only so look for the light to appear red indicating your Controller is charging. It will turn white once it’s complete (~45 minutes).
Page 8: Co N T R O L L E R At Ta C H M E N T
Controller ttachment Your Airpatch includes a Mounting Plate with a release lever and a removable, ﬁ nish-friendly adhesive pad, allowing you to quickly and easily attach and detach your Airpatch from a variety of instrument surfaces and positions. Simply peel off the white ﬁ lm from the Mounting Plate’s adhesive pad to expose the permanent adhesive...
Page 9: Making It Your Own
Your Airpatch makes it possible. Airpatch encourages freedom of movement and expression. Experiment by placing the Airpatch Controller in diff erent locations on your instrument until you ﬁ nd the position that’s most comfortable and best suited to your playing style. Airpatch uses medium-pressure silicone switches to avoid accidental eff ects switching.
Page 10: Mode Selection
With responsive control, your eff ects are activated Momentary by pressing and holding the Airpatch Controller. Your eff ects default to ON. Reverse The eff ects loop is bypassed Momentary for as long as the Airpatch Controller is pressed and held.
Page 11: Prepare For Launch
Launch Prepare for Figure A.1 — Airpatching Your Effects Pedals Instrument...
Page 12: Flight Modes
Delay + Momentary/Latch Mode — Your Airpatch will continue to send your audio signal into the delay pedal even when it’s bypassed, preserving your delay trails. Dial in long delay times and use your Airpatch to bring in the ambient delay trail during phrases and chords.
Page 13 Send to the Return with just one patch cable. No pedals necessary. This provides you with two killswitch options. Use a distortion pedal in your Airpatch eff ects loop and a second distortion outside of your eff ects loop to stack other-worldly tones...
Page 14: A I R Patc H S P Ec I F I C At I O N S
Over 50 feet of range (line of sight). • Long-lasting battery life Controller that lasts for multiple performances on a single charge. • USB charging cable for Airpatch Controller with magnetic connection. • Estimated 45-minute charging time. • Wireless controller LED indicator blinks white when button is activated.
Page 15: Stay Patched In
Patched In Stay aviateaudio.com contactus@aviateaudio.com @aviateaudio @aviate_audio Disclaimer FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
