- Page 1 SMART IoT PLATFORM www.omniflow.io...
- Page 2 The OMNILED® smart energy platform for IoT is based on the award winning wind & solar hybrid electrical power generation OMNIFLOW® concept. It is a multifunctional a device designed for street lighting while being a power and location platform for urban monitoring, internet access and mobile telecommunications 1.
- Page 3 As soon as you finish the installation, do not forget to activate the warranty, by sending an email with the serial number(s) of the installed equipment’s and its location(s) to info@omniflow.pt. For any questions or comments, feel free to contact your OMNIFLOW reseller or directly our company through info@omniflow.pt. OMNIFLOW OWNER’S MANUAL...
-
Page 4: Safety Instructions
LED/optic lens with your bare hands. Check communications in OmniConnect platform. This should be done 1-5min after connection the fuse with the lifting equipment still in place in case anything is not correct. Do the LED test if unit has LED’s. OMNIFLOW OWNER’S MANUAL... -
Page 5: Specifications
Specifications Caution: Please read these instructions carefully before installation Technical Data OMNILED 07 Dimensions (W/H/D) ft [m] 3.94 [1.2] / 1.0[0.3] / 3.94 [1.2] Generator Direct drive, ironless stator permanent magnet generator DC controller Hybrid wind/solar regulator Power Wind - 100Wp / Solar - 60Wp + (optional Extra solar 60Wp PV) Weight lb [kg] 77.16 [35] –... -
Page 6: Installation
Installation Use a safe lifting device to position the OMNILED in to the top of the mast previously fixed to the foundations. Only use masts/foundations or projects provided or approved by Omniflow. OMNIFLOW OWNER’S MANUAL... - Page 7 (Recommended drill size M11 / Metal thickness 4mm) Install the Omniled. Insert the bolts into Remove the protections Keeping the protections. the holes and tighten after installation Bolt tightening torque Bolt Size (mm) Strength Grade (N·m) The OMNIFLOW® should be ready for operation OMNIFLOW OWNER’S MANUAL...
- Page 8 Optional Equipment (GRID-TIE): Live Earth Neutral Grid-Tie cable will come out of the center metallic structure OMNIFLOW OWNER’S MANUAL...
-
Page 9: Frequently Asked Questions
Check for tall buildings or trees in the direction of the prevailing wind *** (check diagram) Rotor spins at low speed Normal when the batteries are fully-charged Effect on the wind of an obstruction (buildings or trees) Region of highly turbulent OMNIFLOW OWNER’S MANUAL... -
Page 10: Warranty
• If the products are opened and altered with other electronics not supplied by Omniflow. Equipment’s being returned to distributor/manufacturer should be properly packaged to protect from damage during transportation. Shipping and insurance costs required to return to Omniflow, SA or its Distributor(s) are the solely responsibility of customer. - Page 11 Contacts Omniflow SA, Rua Delfim Ferreira, 776-C 4100-199 Porto | Portugal info@omniflow.pt www.omniflow.io...
