Manuale istruzioni
Versione N° 02
DENPEX /OTOPEX
Via Dell'Artigianato 305/319
del 08/01/2008
Castelbolognese – RA
1/19
I
NSTRUCTION MANUAL
Italy
Italiano /English
MANUALE ISTRUZIONI
INSTRUCTION MANUAL
DELLA POLTRONA
O
F THE CHAIR
OTOPEX / DENPEX
Leggere il presente manuale prima di utilizzare la poltrona
Read this manual bifore operating the chair
VERSIONE/
REDATTO/DREW BY
DATA/DATE
APPROVATO/
DATA/DATE
VERSION
G. Andraghetti
08/01/2008
APPROVED BY
08/01/2008
N.02
M. Longo
Questo documento è realizzato da EUROCLINIC S.r.l.
È' vietata la duplicazione e la divulgazione non autorizzata
This document has been made by EUROCLINIC S.r.l.
It is prohibited to double or divulge it without authorisation.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OTOPEX and is the answer not in the manual?

Questions and answers

Related Manuals for Euroclinic OTOPEX

Summary of Contents for Euroclinic OTOPEX

  • Page 1 APPROVED BY 08/01/2008 N.02 M. Longo Questo documento è realizzato da EUROCLINIC S.r.l. È’ vietata la duplicazione e la divulgazione non autorizzata This document has been made by EUROCLINIC S.r.l. It is prohibited to double or divulge it without authorisation.

  • Page 2: Important Directions

    All kind of information, technical specifications and pictures, which you will find in the following pages, are not binding. EUROCLINIC reserves itself the right to make modifications and make technical improvements without modifying the following instructions. Original text of this manual is in italian and english language.
  • Page 3 Working: 1 minute Rest: 10 minutes • EUROCLINIC guarantees about security, reliability and performances of its equipments. • Warranty is conditioned by the following indications respect: Observance of conditions which you can find on warranty certificate.
  • Page 4 08/01/2008 Castelbolognese – RA 4/19 NSTRUCTION MANUAL Italy pressione atmosferica da 700 a 1060 hPa DUE USE AND IMPLOYMENT WAYS OTOPEX chairs are medical equipments for E.N.T treatement. DENPEX chairs medical equipment for dental treatment. Attention! Maximum load of the chairs is kg 170. This value must not be surpassed.

  • Page 5: Installation

    Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 5/19 NSTRUCTION MANUAL Italy INSTALLATION Lift the chair out from the package, without inclining it, and place it on the floor. Insert the rubber feet inclining the chair only...

  • Page 6: Funzionamento

    Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 6/19 NSTRUCTION MANUAL Italy FUNZIONAMENTO WORKING Tutte le funzioni si attivano dal pedale All functions are activated by the foot pedal. Pulsante sx (A)/Button sx (A)
  • Page 7 Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 7/19 NSTRUCTION MANUAL Italy By pushing the right push button, the backrest reaches automatically the maximum upright position without changing the height of the seat in order to facilitate the rinsing operation.
  • Page 8 Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 8/19 NSTRUCTION MANUAL Italy MOBILE ARMREST In order to facilitate patient’s lifting and lowering, armrests can be orientated laterally, as you can see on the picture.

  • Page 9: Seat Rotation

    Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 9/19 NSTRUCTION MANUAL Italy SEAT ROTATION When needed, the seat can rotate both to right side and to left side. To set free the rotation, please, kindly press A lever turning it in anti-clock wise.
  • Page 10 The concentrations listed below are the maximum ones that are consented and they cannot be surpassed: Quaternary Ammonium: maximum 2% Glutaric Aldehyde: maximum 2% EUROCLINIC WILL NOT BE HELD RESPONSIBLE FOR DAMAGES CAUSED BY USE OF DISINFECTANTS WHICH CONTAIN ACTIVE SUBSTANCES DIFFERENT FROM THOSE ABOVE MENTIONED.

  • Page 11: Identification Label

    You will find equipment serial number below on the left. According to European regulations in force CE and discharge symbols are transferred. The chair OTOPEX (DENPEX) according to norms 60601.1 regarding safety electrical is of CLASS II B (double...
  • Page 12 Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 12/19 NSTRUCTION MANUAL Italy...
  • Page 13 Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 13/19 NSTRUCTION MANUAL Italy...
  • Page 14 Castelbolognese – RA 14/19 NSTRUCTION MANUAL Italy E S P L O S O – S P A R E P A R T S L I S T CENTRALINA - PEDALE OTOPEX/ OTOPEX CONTROL BOX- FOOT CONTROL 22200017 22200010...
  • Page 15 Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 15/19 NSTRUCTION MANUAL Italy SCHIENALE E POGGIATESTA OTOPEX / OTOPEX BACKREST AND HEADREST 20001714 23500127 52086003 X4 20001735 X 2 52062001 20001736 26001725 22500120 23500126...
  • Page 16 Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 16/19 NSTRUCTION MANUAL Italy 20001728 51200068 51200069...
  • Page 17 Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 17/19 NSTRUCTION MANUAL Italy TAPPEZZERIA OTOPEX – OTOPEX UPHOLSTERY Poggiatesta - HEADREST Schienale - BACKREST Tabella codici tappezzeria otopex – Codes table for Otopex upholstery 207027 _ _ Seduta-gambale –...
  • Page 18 Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 18/19 NSTRUCTION MANUAL Italy BASAMENTO – OTOPEX / OTOPEX BASE 51200007 51200009 21500113 21500109 21500106 54313002 X4 21500112 21500115 56036014...
  • Page 19 Manuale istruzioni Versione N° 02 DENPEX /OTOPEX Via Dell’Artigianato 305/319 del 08/01/2008 Castelbolognese – RA 19/19 NSTRUCTION MANUAL Italy GRUPPO SEDUTA OTOPEX – OTOPEX SEAT GROUP 20700004 X2 54349003 21500138 DX 21500137 SX 21500117 22500095 22500118 22500119 21001724 22500111 56036014...

This manual is also suitable for:
