Summary of Contents for AIRxTOUCH KIOSK 2 Series
- Page 1 Installation guide v2.0 The Touchless Revolution...
- Page 2 Studio SA. Copyright © 2021 · iNUI Studio SA. BRANDS AIR TOUCH® and AIRxTOUCH® brands and logos are the exclusive property of iNUI Studio SA. All other trademarks and copyrights are the property of their respective owners.
- Page 3 PRECAUTIONS Before using this product, please read the safety precautions to avoid any injury to yourself or others, or damage the unit. Do not open or disassemble the unit, no element is useable inside. Refer servicing to qualified staff. WARNINGS TO PREVENT PRODUCT FAILURE, PERSONAL INJURY, ELECTRICAL SHOCK, FIRE AND EXPLOSION INSTALLATION AND SAFETY.
- Page 4 CONTENT PACKAGE 1 Keyboard Top sensor L-shaped metallic pieces 9 × M4 screws · 8 mm Left sensor Screws & washers 4 × M8 screws · 35 mm 4 × M8 washers Right sensor NUC Player Intel Core i5 ...
- Page 5 CONTENT PACKAGE 2 55” Professionnal Display · SAMSUNG QH55R User documentation Power cable Remote Batteries AAA × 2...
- Page 6 CONTENT PACKAGE 3 ACCESSORIES You will find a plastic bag inside the stand (front side) which contains: 1 × HDMI cable 1 × power cable · For the stand 1 × 5V "Leicke" power cable · For the top sensor 1 ×...
- Page 7 BE READY STAFF TOOLS › 3D clamping printed tool — provided › Box spanner · Size 6 › Hex key · Size 3 › Hex key · Size 6 up to 3 persons DURATION Work package 1 · WP1 › 15 minutes ›...
- Page 8 ASSEMBLY ASSEMBLY OF THE VESA MOUNT You have to add the 4 L-shaped metallic pieces to the back of the VESA mount. › 2 long pieces On each long piece: 3 screws requiring 1 × M4 Bolt + 1 × M4 Washer each ›...
- Page 9 ASSEMBLY ATTACH THE STAND TO THE SCREEN 4.1 Put the VESA mount on the back of the screen (which is placed on the foam pad). 4.2 Adjust the position of the VESA mount, making sure to align the 4 holes (colored in yellow on the illustration below) with those of the screen.
- Page 10 ASSEMBLY ATTACH THE 3 SENSORS TO THE VESA MOUNT For a easier identification, each sensor has a color sticker on it: Find your Serial number (identical for all sensors) on a sticker applied on each sensor. Place and screw on each sensor with 3 × M4 screws 8 mm (black screws): ›...
- Page 11 ASSEMBLY CONNECTING THE TV 6.1 Plug the TV Power cable on the back of the screen. 6.2 Plug the HDMI cable into the HDMI 2 port. SAMSUNG Screen Power (6.1) VESA mount Gather cables in this area HDMI (6.2) Bottom Gather all cables in the center of the 4 VESA screws via the top and bottom of the area to facilitate the next step.
- Page 12 ASSEMBLY PREPARE THE STAND FOR THE VESA MOUNT & SCREEN Behind the stand: remove the back of the stand by unscrewing it from the top. HEX KEY 3 Detail (inside view) Back To replace the back of the stand, simply follow the same steps reverse.
- Page 13 ASSEMBLY INSTALL THE FINISHING PLATE ON THE STAND 8.1 Insert the finishing plate on the 2 holders on the front side of the stand (fig. 1). Important: The notch of the finishing plate (fig.2) must be upward. Notch up Fig. 2 Fig.
- Page 14 ASSEMBLY INSTALL THE VESA MOUNT & SCREEN ON THE STAND 9.1 Be ready to carry the VESA mount + screen package (built during the WP1) 2 persons 9.2 Bring it in front of the stand and insert the 4 screw threads in the lowest holes of the stand (colored in yellow on the illustration see below).
- Page 15 ASSEMBLY CONNECTIONS (1/2) 10.1 Run the screen power cable down to the power strip (yellow) at the bottom of the stand. Then, plug the screen power cable into the power strip. 10.2 Place the NUC Player into the built-slot: slide down and the screw will hold the player inside the slot. Important: the connection ports of the NUC Player must face upwards! 10.3 Plug the NUC Player...
- Page 16 ASSEMBLY CONNECTIONS (2/2) 10.1 Inside the stand, connect the Ethernet cable to the NUC Player. 10.2 Plug the global power cable and the external Ethernet cable (if you have one) on the back of the stand and turn the NUC Player on. 10.3 Check that the NUC Player is launched before closing the stand.
- Page 17 Source content orientation landscape 12.5 To close the menu, press "Menu" twice on the remote. You should see appear the AIRxTOUCH® Apps Launcher. You can control it "in the air" with hand gestures. If necessary, you can also use the provided...
-
Page 18: Driver Settings
DRIVER SETTINGS 14.1 Please right click on the Driver tray icon / Driver settings in order to configure your system. 14.2 When the Driver is correctly launched, the Driver tray icon is green. During the Driver initialization, the Driver tray icon is yellow. Driver is launched Driver is initializing You have the possibility to change the PowerLine frequency as well as the... - Page 19 I DO NOT RECEIVE ANY TOUCH POINT 1. Check if the Driver is running The Driver tray icon must been green, not yellow. Type here to search Launched Initializing AN OFFSET IS ALWAYS APPLIED TO THE TOUCHPOINT (X AND Y COORDINATES) 2 screen resolutions are supported: ›...
- Page 20 THE DRIVER IS NOT LAUNCHED (NOT VISIBLE AMONG THE WINDOWS TRAY ICONS) Please click on the Driver shortcut on the taskbar. Type here to search If the shortcut is missing, you can find the executable (.exe) file in Program Files: C:\Program Files\AIRxTouch\AIRxTouch Kiosk\AIRxTouch Driver\iNUI.AIRxTouchDriver.exe...
- Page 21 THE TOUCH POINT (X,Y,Z) IS TOTALLY INCORRECT Double-check on the NUC Player that the 3 AIR TOUCH® Sensors are correctly connected. Color stickers are visible on each sensors as well as on the NUC Player. These stickers has to match. To rearrange the sensors connection scheme: you can launch the Configuration Manager Tool to modify the parameters.
- Page 22 Studio SA · Technoport 2 · Rue du Commerce L-3895 Foetz Luxembourg · contact@inui-studio.com...
