Summary of Contents for Rising SEED-710A-55
- Page 1 SEED-7I0A-55 SEED-7I0A-55 User Manual...
- Page 2 SEED-7I0A-55 Preface SEED-7I0A-55 is a new generation display screen of Shanghai Rising Digital Co.,Ltd.. It is a monitoring and control platform specially designed for construction machinery products. The display screen is based on cortex-a9 platform and adopts a new digital display scheme. It...
-
Page 3: Functions And Features
SEED-7I0A-55 1.Functions and features 7 Inch Touch screen with capacitive touch Internal integrated radio with external radio antenna Microphone voice input, audio output 4G, GPS, BLE Support two-way can communication, support ISO11898 CAN2.0B、J1939、CanOpen The interface uses te 2-6447232-3 connector. It is recommended that the harness connector te ... - Page 4 SEED-7I0A-55 Output switch Support switch output Inpu/ output Audio analog signal output Audio analog signal output Support NTSC / PAL analog camera, can access camera Camera acquisition and 1 channel, support single picture, picture display function in picture display Support microphone input, Bluetooth phone function Microphone 6.1 Microphone input Product appearance structure function description...
-
Page 5: Installation Dimensions
SEED-7I0A-55 2、Installation dimensions Fig 2 display screen installation size The outer ring is fixed with 4 × M6 screws (including spring washer and flat washer), and the inner ring is fixed with 4 × M5 screws (including spring washer and flat washer). - Page 6 SEED-7I0A-55 3、Product port function details name function remarks Power on and ground short System circuit into BIOS, wiring digital signal SYS_SET harness is not connected settings input signal One key start signal signal output Electrical signal on battery Digital signal output signal output Start signal...
- Page 7 SEED-7I0A-55 3.Product program download and upgrade 3.1 Hardware development platform Fig.3 USB interface for program download and upgrade of display screen To download and upgrade the display program, please loosen the screw of the metal cover plate on the left side of the display screen, connect the computer with the USB data cable, and download and upgrade the program cable through the upper computer.
- Page 8 SEED-7I0A-55 3.2 Software development platform It supports QT configuration software, adopts standard ide development environment, and can develop QT application program according to project requirements. Can refer to the commonly used sample programs, rapid development of applications. include: 1) QuickStart human-machine interface, including common man-machine operation control 2) QT based communication function library, including can communication, 4G communication, GPS communication, BLE communication。...
- Page 9 SEED-7I0A-55 4.Connection with external controller It is connected with external controller through CAN bus and supports CAN2.0B, CANopen, J1939 and other protocols. USB emulator Terminal Terminal resistance resistance Figure 4 connection with external controller...
- Page 10 Note: If the power supply voltage of video function should be parameters > 14V, otherwise the camera can not be driven. Output voltage：DC 12V，1A Consumption current：0.55A（DC 24 V） Power waste：≤ 14W Video Display: Picture in Picture, 4 Segments/Single Picture 8 | Shanghai Rising Digital Co.,Ltd. ...
- Page 11 After power on, the GPS function is automatically turned on to determine the location of the device. Turn on and find the Music logo in the main interface, click to enter, 88.1 Select or switch the channel, you can use it directly. Select Radio, 9 | Shanghai Rising Digital Co.,Ltd. ...
-
Page 12: Fcc Radiation Exposure Statement
FCC Statement： Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,and (2) this device must accept any interference received, including interference that may cause undesired operation.
