Quick Start Guide
X
RE
300
Version
2
en
www.helmholz.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REX300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Systeme Helmholz REX300

  • Page 1 Quick Start Guide Version www.helmholz.com...
  • Page 2 If the IP address of your PC needs to be changed in order to reach the Webinterface of the REX300, carry out steps A to C next. (See overleaf) Connect the LAN interface of your computer to the LAN interface of the REX 300.
  • Page 3 Quick Start Guide When necessary, the IP address (LAN address) and the subnet mask of the router can be configured via the menu item Network -> LAN. The router is accessible in the LAN network via this IP address. Note: If the IP address is to be changed, it must corre- spond to the address range (subnet mask) of your com- puter.
  • Page 4 Quick Start Guide If the IP address of your computer must be modified in order to reach the REX 300, continue with the follow- ing steps. The REX 300 is delivered with an IP address set to 192.168.0.100. Your computer must be in the same IP address range (subnet).
  • Page 5 Quick Start Guide PG/PC-interface for MPI/PROFIBUS-PLCs (Not possible with REX 300 eco) In order to reach the REX 300 MPI/PROFIBUS-SPSs, the following steps must be carried out. Install the NETL ink®-S7-NET driver, either from the accompanying CD or download the latest version from the Internet at www.helmholz.com.
  • Page 6 The IP address to be entered under “Address” must correspond to the LAN IP address of the REX300. The IP address of the PLC must be in the address range (subnet) of the REX 300 LAN interface. In order to reach the PLC via the VPN, just select the corresponding interface.
  • Page 7 Quick Start Guide Logging in In order to use myREX24, login under www.myREX24.net -> “Request access”. Fill out the fields required there. After “Send”ing the form you will receive your access data by e-mail. Under “www.myREX24.net -> Support -> Download”, use this access data to download the necessary soft- ware (shDIALUP) and an example application.
  • Page 8 Our customers are important to us. We are always glad to receive suggestions for improvement and ideas. Systeme Helmholz GmbH | Phone: +49 9135 7380-0 | Fax: +49 9135 7380-110 E-Mail: info@helmholz.de | Internet: www.helmholz.com...
