AILONET 100 EVALUATION USER MANUAL
Change Record
Revision
Date
0
19.02.2002
1
6.6.2002
MANUAL
AILONET 100
AILONET USER MANUAL
Page affected
Description of Change
All
Initial issue
All
Support for new user interface
Copyright Patria Ailon Oy 2002. All rights reserved.
JTU
JNU
TSU
21846
6.6.2002
Done
6.6.2002
1/24
Advertisement
Table of Contents
Summary of Contents for Patria Ailon Ailonet 100
- Page 1 AILONET USER MANUAL Done Prepared 6.6.2002 Checked Approved AILONET 100 EVALUATION USER MANUAL Change Record Revision Date Page affected Description of Change 19.02.2002 Initial issue 6.6.2002 Support for new user interface Copyright Patria Ailon Oy 2002. All rights reserved. 1/24...
- Page 2 Patria Ailon reserves the right to revise this document or withdraw it at any time without prior notice.
-
Page 3: Table Of Contents
2.3.7 Serial Port Settings ..................20 2.3.8 PC-Card Modem Settings ................21 2.3.9 Password ......................22 2.3.10 Firewall ......................23 2.3.10.1 Interfaces ....................23 2.3.10.2 Advanced....................23 2.3.10.3 Factory settings ..................24 Copyright Patria Ailon Oy 2002. All rights reserved. 3/24... -
Page 4: Overview
Apache Web Server – – LAN Access profile according to Bluetooth 1.1 specification – party application (Plug-in) API DHCP (Dynamic Host Control Protocol) Server – – NAT (Network Address Translation) Copyright Patria Ailon Oy 2002. All rights reserved. 4/24... -
Page 5: Physical Interfaces
Ailonet is either starting up or shutting down. The right-most led indicates for Ethernet connection. If the led is lit half bright Ethernet link to network is established. If the led blinks, data is been transferred. Copyright Patria Ailon Oy 2002. All rights reserved. 5/24... -
Page 6: Switches
(ON) position. User defined settings done in factory settings mode are store nor- mally, but the switch must be switched in up (OFF) position before the unit is restarted. Copyright Patria Ailon Oy 2002. All rights reserved. 6/24... -
Page 7: System Setup
802.11b. This is due to fact that there’s no easy way of finding out Ailonet’s 802.11b IP address. To access Ailonet via 802.11b, use web browser to connect to https://192.168.102.1/ (please verify the IP address from CONFIGURATION STATUS LIST – AILONET SAMPLE IN- FORMATION) Copyright Patria Ailon Oy 2002. All rights reserved. 7/24... -
Page 8: First Connection Using Ethernet
1.3.6 Selecting User Interface Language User interface language can be changed from the top right corner of the screen by clicking appro- priate flag. Currently English and Finnish are supported. Copyright Patria Ailon Oy 2002. All rights reserved. 8/24... -
Page 9: Selecting Internet Interface
Connectable means that Ailonet allows incoming Bluetooth connections with earlier paired devices, but does not respond to inquiries. Discoverable/Connectable means that it responds to inquiries and allows incoming connections. Copyright Patria Ailon Oy 2002. All rights reserved. 9/24... - Page 10 This is due to 802.11b network changes you just made. Now make the same changes into your terminal’s 802.11b settings. By doing that your 802.11b connections are protected in the future. Copyright Patria Ailon Oy 2002. All rights reserved. 10/24...
-
Page 11: Supported Pc Cards
Modems: Nokia CardPhone GSM modem – – Nokia CardPhone2 GSM modem – Nearly all PSTN modems with AT command interface 802.11b Cards: – Orinoco 802.11b Silver – Orionoco 802.11b Gold Copyright Patria Ailon Oy 2002. All rights reserved. 11/24... -
Page 12: Administration
Confirm the shutdown by clicking Yes 2.1.2 Restart Restart step-by-step In Ailonet’s user interface, browse to POWER menu Press Restart hyperlink on the menu Confirm your choice by clicking Yes Copyright Patria Ailon Oy 2002. All rights reserved. 12/24... -
Page 13: Plug-Ins
In Ailonet’s user interface, browse to PLUGINS->Remove Select the plug-in from the list Double-check that the plugin you have chosen is the one you need to remove Press “Remove Plugin” button Copyright Patria Ailon Oy 2002. All rights reserved. 13/24... -
Page 14: Settings
Download or copy a system update package to computer hard disk In Ailonet’s user interface, browse to PLUGINS->System update Press “Browse…” button and select the system update package from the computer hard disk Press “Send” button Reboot after successful transfer Copyright Patria Ailon Oy 2002. All rights reserved. 14/24... -
Page 15: Internet Interface
1.3.7, Selecting Internet Interface. Changing external interface (WAN) step-by-step In Ailonet’s user interface, browse to SETTINGS->Internet Interface Select appropriate interface from External interface list Press Confirm button Copyright Patria Ailon Oy 2002. All rights reserved. 15/24... -
Page 16: Bluetooth
Ailonet cannot be bonded to, but devices previously bonded to Ailonet can connect to Ailonet. If Discoverabe/Connectable is chosen, a Bluetooth device can bond to or es- tablish a connection to Ailonet and can be found on device inquiries. Copyright Patria Ailon Oy 2002. All rights reserved. 16/24... -
Page 17: Device Discovery
10. Choose the Bond link to bond the device and enter the required PIN code. The device ap- pears on the bonded devices list on the Bluetooth front page. Copyright Patria Ailon Oy 2002. All rights reserved. 17/24... -
Page 18: 802.11B
11. Selected Mode (only AdHoc supported at the moment) 12. Select RTS/CTS flow control on/off 13. Enter Encryption key or leave the field blank (no encryption) 14. Press Confirm button Copyright Patria Ailon Oy 2002. All rights reserved. 18/24... -
Page 19: Ethernet Settings
Select DHCP mode (If Client, go to step 8) Enter Ailonet’s IP address in Ethernet network Enter Netmask Enter Gateway IP address Enter Primary DNS IP address Enter Secondary DNS IP address Press Confirm button Copyright Patria Ailon Oy 2002. All rights reserved. 19/24... -
Page 20: Serial Port Settings
Enter Init string Select, if incoming connections are allowed Select if Microsoft Windows modem emulation is used with direct cable connection Enter the Number of rings before answering 10. Press Confirm button Copyright Patria Ailon Oy 2002. All rights reserved. 20/24... -
Page 21: Pc-Card Modem Settings
Choose the number of rings before answering. The number at Number of rings before an- swering defines, how many times the modem allows the line to ring before answering. Confirm the changes by clicking the Confirm-button. Copyright Patria Ailon Oy 2002. All rights reserved. 21/24... -
Page 22: Password
Enter administrator’s new password twice Press Confirm button Changing dial-in password step-by-step In Ailonet’s user interface, browse to SETTINGS->Password Enter old password of dial-in Enter new password of dial-in twice Press Confirm button Copyright Patria Ailon Oy 2002. All rights reserved. 22/24... -
Page 23: Firewall
Listed, in which case a connection can be established from the IP-addresses in the box on the right. The IP-address has the form 192.148.166.221. Instead of an IP-address, a subnetwork can Copyright Patria Ailon Oy 2002. All rights reserved. 23/24... -
Page 24: Factory Settings
Choose interface to be modified. Choose profile to be modified. Start modifying by clicking Modify. 10. Choose settings for different ports or add ports. 11. Click Save. The firewall settings have been changed. Copyright Patria Ailon Oy 2002. All rights reserved. 24/24...
