ASSEMBLY INSTRUCTIONS FOR I-PK & I-CS SERIES
1. Swing out cross
rails to a 90° angle.
3. QUEEN SIZE ASSEMBLY
Fit the rivets on the extender rails into
key-hole slots 1, 2, 11 and 12 as shown:
3. KING SIZE ASSEMBLY
Fit the rivets on the extender rails into
key-hole slots 3, 5, 8 and 10 as shown:
3. CAL-KING SIZE ASSEMBLY
Fit the rivets on the extender rail into
key-hole slots 4, 6, 7 and 9 as shown:
4. FOR ALL SIZES - Lock the extender rail in place with the black plug locks as shown:
2. Install the glides or
the sockets & rollers on
the legs.
Slip plastic caps over
the end of the side rails.
