Summary of Contents for Minder Water Industries MINDERSPEED MXB
-
Page 1: Table Of Contents
MXB PUMP INSTALLATION AND USER’S GUIDE Table of Content: 1. Pump Overview 2. Installation 3. Initial start-up 4. Pump operation & maintenance 5. Disassembly/ Assembly procedure for seal replacement 6. Winterizing procedure 7. Troubleshooting 8. Replacement parts a. MXB... - Page 2 IMPORTANT NOTICE Attention Installer This manual contains important information about the installation, operation and safe use of this product. This information should be given to the owner/ operator of this equipment. WARNING Before installing, read and follow all warning notices and instructions accompanying this filter/ pump.
- Page 3 This document is subject to change without notice Trademarks and Disclaimers: All Minder trademarks and logos are owned by Minder Water Industries Pty Ltd. Minder © trademarks and/or registered trademarks of Minder in Australia and/ or other countries. Unless expressly noted, names and brands of the third parties that may be used in this documents are not used to indicate an affiliation or endorsement between the owners of these names and brands.
-
Page 4: Pump Overview
1. Pump Overview Your recirculating pump is a centrifugal type pump to drive water flow to your water recirculation system and is designed to operate for years with proper maintenance. The pump wet-end case, diffuser, impeller are made from high quality thermoplastic materials. These materials have been selected for their corrosion-resistant nature. - Page 5 WARNING Chemical fumes and/or spills can cause severe corrosive attack to the filter and pump structural components. Structurally weakened the filter or pump components can cause filter, pump or valve attachments to separate and could cause severe bodily injury or property damage.
-
Page 6: Initial Start-Up
19. The wiring to the motor should be kept as short as possible and large enough NOT to cause an excessive voltage drop. Use the wire size table as a guide in selecting minimum conductor size. 20. Install, ground and bond wire according to local code requirement. For direct wiring into main supply, Minder pump is supplied with a power cord that can be plugged into the power source. -
Page 7: Pump Operation & Maintenance
4. Pump Operation & Maintenance The strainer basket in the pump should be inspected and cleaned twice each week. Remove the clear lid and the basket and clean debris from basket. Inspect the lid O-ring; if damaged replace. The pump seal requires no lubrication. Refer to motor service centers for motor servicing. - Page 8 5. WINTERIZING NOTICE: Allowing the water to freeze in pump will damage the pump and cause potential water damage/ flooding and potential property damage. 1. Drain all water from pump housing and piping when freezing temperatures are expected. A drain plug is provided to drain the pump. If the pump has a strainer pot, both the strainer drain plug and the housing drain plug should be removed.
-
Page 9: Troubleshooting
6. TROUBLESHOOTING Problem Cause Solution Pump will not prime 1. No water in strainer Add water to strainer • compartment compartment 2. Strainer compartment lid is not • Tighten lid tight • Replace lid o-ring 3. Damaged lid o-ring (air •... - Page 10 Correct Disposal of this Product This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
