Starting Using for DoHome-PA
Product
DoHome-PA
Input Voltage
90-250V
Rated Current
15A(Max)
Max Load Power
3000W
48*48*52mm
Product Size
Technology Support: Support@doit.am

Advertisement

loading
Need help?

Need help?

Do you have a question about the PA and is the answer not in the manual?

Questions and answers

Summary of Contents for DoHome PA

  • Page 1 Starting Using for DoHome-PA Product DoHome-PA Input Voltage 90-250V Rated Current 15A(Max) Max Load Power 3000W 48*48*52mm Product Size Technology Support: Support@doit.am...
  • Page 2 Warm tips: Please check if the smart plug has any abnormal noise, damage, fracture or other problems. If not, power on the plug and check if the indicator light is blinking slowly. (the light blinks about one time each second). Light blink 1s per second...
  • Page 3 Note: If the smart plug doesn’t blink slowly, please long press the button for 5s to set it to this mode. HomeKit (ONLY for Apple users): Step1: Please open the WLAN setting page of your iPhone (as Fig. 1), find and connect the WiFi hotspot named as Homekit_xxxx.
  • Page 4 input http://192.168.4.1. And then, please wait for entering the interface of configura- tion. ( Fig. 1) Step2: Please choose your home WiFi router name in the pop-up window, key your...
  • Page 5 password and click “join” (as Fig. 2). After the WiFi configuration interface has skipped to the WiFi list page (as Fig. 3), please make sure that the indicator always lights (the WiFi account information in the pictures is only for reference). ( Fig.
  • Page 6 Note: If you don't find your router or smart plug at other states, please look over the Frequent Problems and reconfigure the smart socket. Step3: Please check if you have installed Home APP. If not, please download it in the APP store.
  • Page 7 Step4: Please connect your phone with your home WiFi network (as Fig. 5). Note: Please ensure that the iPhone and the smart plug are in the same 2.4G WiFi network. ( Fig. 5)
  • Page 8 Step5: Please open Home APP, click “Add accessory”. And then, Please put the code (i.e., 123-45-678) of Figure 6 into the frame. Click the device, “Add anyway”. After waiting for the encryption check (about 50s), you have added the switch successfully.
  • Page 9 Note: If the code is not recognized， please click “Don’t have a code or cannot scan”, Click the device, “Add anyway”, and input the code “12345678”. After waiting for the encryption check (about 50s).If Home APP doesn’t show the device, please make sure that the phone and the smart plug are in the same local network.

  • Page 11: For Others

    (1 time every second). Long press the button of smart plug for 5s and observe that the indicator light blinks quickly (10 times every second). Step2: Use your phone to scan the following QR code and download DoHome APP.
  • Page 12 Step3: Open DoHome APP, register your account using your name and password, and then login the DoHome APP.
  • Page 13 Step4: Click the“+”in the upper right corner to add the device according to the hint. Note: If you still have a doubt, please click the menu in the upper right corner (≡) to look for help.
  • Page 14 Step5: If want to use the smart speaker, e.g., Alexa, google assistant, Tmall or Xiaomi, please click the“≡”in the upper right corner to look for the correspond- ing instructions. Technology Support (OTA update): http://support.doiting.com...

  • Page 15: Frequent Problems

    Google Assistant, Tmall genie or XiaoMi audio? 1. Scan the QR code in the following and download DoHome APP. 2. Register and login your account informa- tion of DoHome. Pull down and refresh the interface to look for your smart device.
  • Page 16 Note: The phone and the smart plug must be connected in the same WiFi network. 3. Please open the menu in the upper left corner, click “Manager” and find your device. And then, choose it and click “Bind device”.
  • Page 17 Note: (1). You must login the 3rd platform to login your DoHome account before using it. (2). If you want to use the smart audio, please click the corresponding icon to check the user manual. If you need help, please click the option of help;...
  • Page 18 Q3. Why the device name should be short? A.Because convenient voice controlling function, for example, DoHome. Q4: How to reset the socket to the factory mode? A. Long press the button of the smart plug (5s) and the indicator light will blink slowly.
  • Page 19 Q5.During the network configuration,if there is something you should take attention of? 1.Please make sure that the device, your phone and the router are close to each other during the network configuration. 2.Please ensure that you input the password of the router correctly. 3.During the configuration of network, please keep that the router works in the 2.4G...
  • Page 20 mode of the router is wpa2-psk and the type of authorization is AES. Or both are set to the automatic mode. 5.During the network configuration, if the router opens the wireless MAC address filter, please move the device away from the MAC filter list of the router.please confirm whether the router has the firewall function.
