Stamp IT SIAH1210 Instruction Manual

Pneumatic marking machine (heavy duty)

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Pneumatic SIAH 1210 Marking

Machine (Heavy Duty)

Instruction Manual

Part Number: QSM-004

Table of Contents

Need help?

Do you have a question about the SIAH1210 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stamp IT SIAH1210

Page 2 Address: 202, Sunrise Business Park, Road Number 16, Wagle Industrial Area Thane (West) 400604, Maharashtra, India Phone: 022 6513 1554 Product Type: Marking Machine Product Name: Pneumatic SIAH1210 Marking Machine Model Name: ______________ Serial Number: ________________ Representative Person‟s Name:______________________ Signature:______________________...
Page 3: Table Of Contents
European Quality – Indian Price Table of Contents Warranty Certificate ..............................4 Introduction & Specifications ............................5 Controller ................................. 5 Requirements................................6 Machine Installations ..............................8 Using Different Stylus Assemblies ..........................10 When Using the PH / HF Stylus type........................11 When using the LP / LS Type of Stylus.
Page 4 Use & Care ................................42 Handling ................................42 Noise Emissions ..............................42 Electrical Hazards ..............................42 Possible hazards while operating........................... 43 Exploded View of SIAH1210 machine ......................... 44 Line Diagram of SIAH1210 Machine Head ......................45 Ascii Table .................................. 46 P a g e...
Page 5: Warranty Certificate
European Quality – Indian Price Warranty Certificate The SevenSTAMP Controller with the connected marking head comes with a one year warranty on all parts except for the parts mentioned in the exclusion list. The machine warranty is effective from the date of dispatch, against manufacturing defect or workmanship. In case of any such defect found during the one year from purchase, Stamp „IT Group of Companies, will undertake repairs to the warranted part free of charge.
Page 6: Introduction & Specifications
European Quality – Indian Price Introduction & Specifications SIAH 1210 Integration Head Standard marking window: 120mm X 100mm Type of Machine: Pneumatic Type of Head: Standard Head Material of Cons: MS Sheet Metal Body Color of Machine: Siemens Grey Weight of Machine: 3.3 kg (Only machine head) Mounting Holes: 4 holes for proper mounting Imprinting surface variance: 10mm (P).
Page 7: Requirements
European Quality – Indian Price 1. CN01 Electric Controller ( Computer 2. CN03 Electric Controller(Touch based) screen ) Axes: 2 axis & 3 axis versions. Power Supply: Separate 24VDC 3A Power Adapter for Pneumatic version. Cooling: High Speed Fan provided. Machine Connection: Robust Military Grade Round Bayonet Connectors Display: 7”...
Page 8 European Quality – Indian Price b. If you require a voltage stabilizer for refrigerator or air-conditioning unit at the installation location, then a voltage stabilizer will be essential for the machine. c. Proper Earth connection at the site for connecting the marking machine. Use a multi-meter to measure and verify the status of electrical earth.
Page 9: Machine Installations
European Quality – Indian Price b. Usually, if compressed air supply is not available, then it is required to procure a compressor. Compressor of 1hp capacity with 40 liter tank capacity is sufficient for the working of marking machine. c. Always ensure that the compressed air line is taken directly from the compressor and there is no pneumatic tool or air cleaning gun attached to the compressed air line.
Page 10 European Quality – Indian Price Attach above end of Attach properly above end machine cable to the of machine cable to the controller. machine head. Attach the machine cable on Attach the machine cable on Remove Cap and attach the controller machine Military Connector from the...
Page 11: Using Different Stylus Assemblies
European Quality – Indian Price Fix the Filter Unit in the bracket. Fix this bracket on the Column Frame. Fix one end of the small PU tube on the Filter Fix other end of the small Unit OUT Port. PU tube on the machine Port.
Page 12: When Using The Ph / Hf Stylus Type
European Quality – Indian Price When Using the PH / HF Stylus type. This is the For using the PH or HF Stylus, the Stylus ON Standard delay and Stylus OFF Delay values need to be PH-16 Stylus. set at minimum. Usually, 6 ms is suitable for This will soon these stylus use.
Page 13: When Using The Lp / Ls Type Of Stylus
European Quality – Indian Price This type of stylus is used when customer required deep marking on component. When using the LP / LS Type of Stylus. For using the LP or LS Stylus, the This is the Stylus ON delay and Stylus OFF Standard LP-10 Delay values need to be set at Stylus.
Page 14: Select The Right Stylus
European Quality – Indian Price LP-16 LP-6 Select the right stylus We have various stylus types available for different applications. All the stylus types use tungsten carbide rods. Since we use a solid tungsten carbide rod, these are re-grindable up to 3-4 times. All the stylus tips have similar life and can easily mark 1 million characters of 3 mm height on maximum 35 HRc hard component.
Page 15: Attach The Stylus On The Machine
European Quality – Indian Price stylus has a standard tip angle of 90 degrees included and is also available in 60 and 110 degrees on special request Attach the Stylus on the machine. Take the stylus in your hand and take it near the stylus holder on the machine. STYLUS HOLDER Now attach engage the stylus on the socket threading.
Page 16: Installation Of Stampsoft
European Quality – Indian Price CNO3 controller not need to computer or extra software, this controller have build in marking software which you can use to connect the machine, create, modify the design & send the marking command to the machine. If you select CN01 controller with machine then you needs to install StampSoft software in your computer or laptop for using this marking machine.
Page 17: First Marking With Controller Cn01 (Computer Based)
European Quality – Indian Price First Marking with Controller CN01 (Computer Based) Before start marking you should know software functions. 16 | P a g e...
Page 18: Menu Bar
European Quality – Indian Price o Menu Bar You can do the following using this toolbar.  Create a new design : Press the New Design button to start a blank new design. The new design by default is shown as "Untitled" in the title. In case there is an existing design open and not saved, the following dialog is shown prompting the user whether to discard the design or not.
Page 19 European Quality – Indian Price  Save Design : Press the Save Design Button to save the design. The save design button is enabled only when you have made some changes to the design.  Cut selected blocks : In case you want to cut the blocks in a design say for example as shown here... This is the way you will see the block selected.
Page 20: Draw Toolbar
European Quality – Indian Price  Undo the actions : Press the Undo Button to reverse the actions on the canvas. Any change to the design can be be reversed by using the Undo. Alternatively, you can press Ctrl + Z key also to undo the actions. ...
Page 21 European Quality – Indian Price  Select Tool Press the Select button to select tool. By default, the select tool is always active. In this tool, one can select different blocks from the canvas which is not possible otherwise.  Text Tool Press the text button to select the tool.
Page 22 European Quality – Indian Price Barcode Printer tool is a special tool which prints barcode labels along with marking. Press Barcode Printer button to select this tool. Click on canvas once to insert this block. This is a non-graphic item hence will not be seen on the canvas. ...
Page 23: Machine Tool
European Quality – Indian Price Press the Circle button to select the tool. Click here for step by step guide on drawing circles.  Ellipse tool Press the Ellipse button to select the tool. Click here for step by step guide on drawing ellipse.
Page 24 European Quality – Indian Price 4. Set the marking window of software as per your marking machine head. If your machine marking window is 80X30mm then set from software. o Press this machine setup button of software o Double click on name of machine o To set value of X axis press Axis#1 &...
Page 25 European Quality – Indian Price o Press Save Machine button to save changes. 5. Create marking design 6. Save the created marking design by pressing this icon of software. 7. After creating and saving marking design, put machine on component & check the marking area on marking component using jogging feature of machine.
Page 26: First Marking With Controller Cn03
European Quality – Indian Price First Marking with Controller CN03 1. Power ON the Controller The controller will take a few seconds to power up completely and you will come to the main screen of the controller. Detail explanation of the main screen is covered in this manual. The controller will start by default with a new Design.
Page 27 European Quality – Indian Price 3. Inserting the first block: On the Design screen click the A button and select any point on the canvas to insert the first text block. This block can be selected either by touching any point on the text drawn on canvas or can be selected by touching the Text Block written in the List of blocks to the right on the controller screen.
Page 28 European Quality – Indian Price 4. Change the marking string with on screen keyp ad Now click on Marking String box and then select the keyboard button at the right bottom corner of the screen. A QWERTY keypad will pop up where using the onscreen keys, you can change the marking string as desired.
Page 29 European Quality – Indian Price P re ss ok bu t to n af t e r ch an gin g t h e ma rkin g st rin g. P re ss O k b u tt o n clo se th e b lo ck p rope rt y scre e n . 5.
Page 30 European Quality – Indian Price After creating marking design, put machine on component & check the marking area on marking component using jogging feature of machine. Then press trigger of machine to start marking. During marking process you see this marking preview on controller. You can stop marking by pressing red button from above screen.
Page 31: Some Important Instructions Or Note For Marking Process
European Quality – Indian Price Some important instructions or note for marking process Using the Touch Screen controller. Please note that the controller is fitted with a Resistive touch screen. i.e. The touch will not work like the touch screen phones with your fingers but will need a blunt pen supplied with the controller.
Page 32: Distance Between Stylus Tip And Job
European Quality – Indian Price stylus fitted on the marking head is moved down till the right distance is maintained between the stylus tip and the surface of job which you want to mark on. Distance between stylus tip and job This distance is decided on the type of stylus fitted on the machine.
Page 33: Stopping The Marking Operation
European Quality – Indian Price marking is complete. Stopping the Marking Operation To test the stop marking button, when the marking is in progress, you can either press the Red button on the push button box that is connected to the controller or by press the Red button on the preview screen.
Page 34: What Are Different Day, Month Codes
European Quality – Indian Price Expression Output Return current time of system or controller in minutes Return current time of system or controller in seconds. The similar output can be achieved by using commands like @y@, @Y@ for short or long year, @M@ for month and @D@ for the day in numbers.
Page 35: Some Definitions Explained
European Quality – Indian Price Counter as per the settings specified in the counter settings screen for the given block. Just the Day of the current Date. Example If today is 08/09/14 then it will print Day of Year for the current Year. This is also known as a Julian Date Date Code for the current Date.
Page 36 European Quality – Indian Price Marking Machine: A machine that produces permanent alpha-numeric marks on metal or plastic components primarily for the purpose of traceability. Traceability: The process of keeping track of products with the help of unique identification number. Each product to be traced is assigned a Unique Identification number and the product process or life cycle is tracked against this UID.
Page 37 European Quality – Indian Price Marking Window: The rectangle formed by the maximum movements of the X and Y axes is known as a marking window. The maximum movements are decided by the actual physical limitation of movement of each of the axes. Column Frame: The Structure with pillars or slide and a Base where the slide is used for moving of the marking head in vertical direction and the base is used for holding the jigs or fixtures that hold the components to be marked.
Page 38 European Quality – Indian Price Rectangle, Circle, Ellipse, Polygon: These are different blocks as their name specifies drawn on the canvas. There is a graphics group tool available on the controller for drawing all these 4 blocks on the screen. Point: A point is called as the point block.
Page 39 European Quality – Indian Price the fixed text. Serially incrementing or decrementing counters, shift codes, date codes, date and time, or data received from serial port etc. are few examples of variable text that can be used in the text block and specified by commands. The manual will cover in detail all these commands and the way of using these commands.
Page 40 European Quality – Indian Price point after every marking cycle. However, the marking machine will go back to the true origin after the controller is reset from an emergency stop condition. Array:An array is an orderly arrangement, often in rows, columns or a matrix. For this controller, the array is a tool for creating multiple copies of the selected block that are arranged in form of rows and columns automatically.
Page 41 European Quality – Indian Price Expression Output The abbreviated localized month name (e.g. 'Jan' to 'Dec'). MMMM The long localized month name (e.g. 'January' to 'December' The year as two digit number (00 to 99) yyyy The year as four digit number. If the year is negative, a minus sign is prepended in addition.
Page 42 European Quality – Indian Price This is how the This is how the QRCode Datamatrix Code looks looks on the Software on the Software Screen Screen Marking Mirrored Marking Normal Marking Angle Font Size Spacing Base Circle Shown here are Top Left examples of Constant Length...
Page 43: Preventative Maintenance
European Quality – Indian Price Preventative Maintenance Caution: Always disconnect power source before cleaning or servicing. 1. Keep machine in dry place. 2. Do not use sharp object on screen of controller.(Use only stylus pen which you get with the controller ) Warnings and Instructions Work area safety...
Page 44: Possible Hazards While Operating
European Quality – Indian Price Possible hazards while operating The motors used in the machine are stepper motors. Hence they do not present any hazard. However, care should be taken while operating and maintaining the machine to prevent the hand from coming between the marking pin and the work piece. It is important to keep other object away from the marking area while the machine is working.
Page 45: Exploded View Of Siah1210 Machine
European Quality – Indian Price Exploded View of SIAH1210 machine 44 | P a g e...
Page 46: Line Diagram Of Siah1210 Machine Head
European Quality – Indian Price Line Diagram of SIAH1210 Machine Head 45 | P a g e...
Page 47: Ascii Table
European Quality – Indian Price Ascii Table (Null character) (Percent sign) (Capital V ) & (Ampersand) (Capital W ) (Start of Header) (Apostrophe) (Capital X ) (Start of Text) (round brackets (Capital Y ) (End of Text) or parentheses) (Capital Z ) (End of (round brackets (square brackets...
Page 48 European Quality – Indian Price (Delete) Æ (Latin diphthong indicator ) "AE") º (masculine ô (letter "o" with ordinal indicator) Ç (Majuscule circumflex C-cedilla ) ¿ (Inverted accent or question marks) ü (letter "u" with "o-circumflex") umlaut or ® (Registered ö...
Page 49 European Quality – Indian Price character) "I-acute") Ú (Capital letter "U" ├ with acute (Box drawing Î (letter "I" with accent or character) circumflex ─ accent or "U-acute") (Box drawing character) "I-circumflex") Û (letter "U" with ┼ circumflex (Box drawing Ï...
Page 50 European Quality – Indian Price You may also order via Email to intsales@stampitcnc.co.in; online at www.stampitcnc.com & www.marknstamp.com ; phone at 022 6513 1554 If you do not have the correct parts manual, contact Stamp‟it Robotai & Solutions & Pvt Ltd. Answers to other questions may be found at www.stamitcnc.com or call Stamp‟it Robotai &...
