Summary of Contents for Cinegy Route 11

Page 2: Table Of Contents
2.1. Cinegy Route Directory Service ..............
Page 3 7.1. Overview and Setting Up .............. ...
Page 4: Preface
Delivering a channel is complex – with many interconnected elements costing money, requiring management and needing maintenance. Cinegy Air simplifies these challenges by supporting multiple channels with multiple features in a single box. Deploying Cinegy Air on a server brings Dolby® Digital encoding, Nielsen watermarking and Cinegy CG channel branding to one integrated software solution.
Page 5: User Manual
User Manual Page 2 | Document version: e23d164...
Page 6: Introduction And Setup
Cinegy Route provides the ability to register and secure the details of all of these incoming signals inside the Cinegy Route Directory Service. Once registered, it becomes easy to deal with a huge number of incoming SD, HD and 4K network streams and satellite feeds simultaneously from client stations around the network –...
Page 7: Installation
Cinegy Multiviewer and Cinegy Encode products in the corresponding documentation. 1.2. Installation In order to start the installation of the Cinegy Route components, run the Cinegy Route Setup.exe file from your installation folder. Your system will be checked if Cinegy License Service is installed on your PC;...
Page 8 Press "Next" to proceed with the installation or "Cancel" to abort and exit the setup wizard. Read and accept the license agreement. Press "Next" to proceed. The following dialog box appears: Page 5 | Document version: e23d164...
Page 9 Having selected the tools for installation, press the "Next" button to begin the installation. A progress bar will show the progress of the installation process. Together with the selected Cinegy Route components, the following utilities are installed by default: NetCaptureGUI, NetPlayGUI, and NetSendGUI.
Page 10  Refer to the Cinegy Route Support Tools section for detailed information on these utilities. Page 7 | Document version: e23d164...
Page 11: Stream Management
All the present streams can be registered by Route Directory Service. This service can be installed on any dedicated PC via the Cinegy Route setup wizard and can be used by all ingest and playout stations, as well as by Cinegy Multiviewer.
Page 12: Objects Copying And Moving
"Programs" column for the sources and the "Channels" column for the programs. Objects Copying and Moving Cinegy Route Manager allows you to copy and/or move folders and channels. To copy objects and paste them to a desired location, use the "Copy" and "Paste" context menu commands respectively:...
Page 13: Connection
To move the object(s) from one source group to another, use the "Cut" and "Paste" context menu commands. Connection To establish new connection to Route Directory Service or change the service if you are already connected, press the "Connect…" button located in the main toolbar or in the "File" menu. The connection dialog box will appear.
Page 14 The procedure of creating, editing and deleting the virtual destination groups is the same as for the physical  source group operations. Physical Source Creation To add a new physical source, select the physical group, in which you would like to create it, and press the "Add…"...
Page 15  The service ID is 0 by default.  Port 8888 is the default service port; it cannot be used here. Press the "Visible To…" button to define the visibility parameters for the current network source. To load the stream information directly from the DVB stream, press "Load" and use the "Load from DVB stream"...
Page 16: Virtual Destinations
Enter a name for the new stream and define its type (video or audio) and PID number. Press "OK" to create the stream. Press the "Change…" button to edit the selected object. Press the "Delete" button to remove the selected object. In this dialog box you can also define which streams to use in the current program by selecting the corresponding stream(s) in the "In Use"...
Page 17: Processing Nodes
 Refer to the paragraph for details. Physical Source Groups The virtual destination groups will be shown as separate tabs in the Cinegy Route Control application.  Refer to the section for information about Cinegy Route Control. Cinegy Route Control Virtual Destination Creation To add a new virtual destination, choose "Virtual Destinations"...
Page 18: Visibility Management
2.3. Visibility Management The visibility parameters should be individually configured for all the sources being created via Cinegy Route Manager. Setting the visibility means that others are able to see and use the actual source (or group) in the related applications or the RTP client applications (like Cinegy RTP ingestor, Cinegy Air, etc).
Page 19 "This object will not be visible" is set by default. In this mode, the corresponding object is not visible and not available in the related applications and the RTP/UDP client applications. If you want to make this source visible for the selected clients, set the radio button to "This object will be visible for following users and groups".
Page 20: Server Security
• Routing Administrators; • Routing Users. If users not belonging to these groups and having not enough privileges to work either with Cinegy Route Directory Service or Cinegy Route Control try to connect to these products, the following error message appears: Administrators In the "Administrators"...
Page 21: Routing Administrators
Press the "Remove" button to delete the selected member from the corresponding user group. 2.5. Server Backup and Restoring Cinegy Route Manager provides you with the ability to back up your server content and configuration and restore it back when needed.
Page 22 Here check the backup options and define the backup file path using the button or keyboard. Press the "Backup" button to save the selected sources and/or settings to the defined location. To cancel the server backup and close the "Backup Server" dialog, press "Cancel". When the backup process is finished, the "Done…"...
Page 23 Here choose the sources and/or settings to restore by selecting the corresponding checkboxes and define the location of the backup file using the button or keyboard. Press the "Restore" button to restore your backed up server. To cancel the restoration and close the "Restore Server" dialog, press "Cancel".
Page 24: Route Directory Relay Service
3.1. Overview Cinegy Route Directory Service is quick and easy to set up, and works great in small to medium size environments. However, once the number of connected clients increases, or network topology becomes more complex, the polling request model becomes limited.
Page 25: Configuration
With a great number of RTP streams, this configuration can cause network overload. 3.2. Configuration To configure Cinegy Route Directory Relay Service, the ChannelRelay.exe.config file is used. It is located in the same folder with all other Cinegy Route files.
Page 26 RegistryServer – this value should correspond to the central Cinegy Route Directory Service machine to be relayed. This parameter is used to establish connection from the Cinegy Route Directory Relay Service to the core service, and is embedded inside the multicast data as part of any URL entities, so should be consistent and resolvable by all clients.
Page 27 Once configured, Cinegy Route Directory Relay Service should be restarted to reload any changes. Use of network switch tools should show a multicast stream coming from the service, and it is recommended that client traffic is analyzed via network monitoring tools (e.g.
Page 28: Cinegy Route Browser
Chapter 4. Cinegy Route Browser 4.1. Browsing Cinegy Route provides a convenient Cinegy Route Browser tool for browsing the video streams registered by Route Directory Service and their automatic converting to the RTP/UDP URLs. Cinegy Route Browser allows user to browse the video streams registered by Route Directory Service and can automatically convert them to the RTP/UDP URLs.
Page 29: Rtp/Udp Url
At the bottom of the dialog box you can see the RTP/UDP URL corresponding to the selected source or program. Route Browser supports direct drag-and-drop of the selected program into the Cinegy Air Control playlist (the corresponding live item will be created in this case) or into the text fields (the RTP/UDP URL will be copied).
Page 30 AudioStreamsPids – defines the audio streams PIDs in the program divided by a comma (e.g. "audioPids=136,137").  Setting the VideoStreamPid and AudioStreamsPid parameters is optional. Page 27 | Document version: e23d164...
Page 31: Cinegy Route Control
Server Security article. To start Cinegy Route Control, go to Start > All Programs > Cinegy > Cinegy Route > Cinegy Route Control; the following connection dialog box appears: Enter the Route Directory Service IP address or network name and press "Connect". Cinegy Route will be started: All visible physical network sources available for the currently connected server are displayed in a tree-like form on the left.
Page 32: Locking
You can start/stop the playback by pressing the corresponding buttons. To hide the player, deselect the "Show Player" option. The right side of the Cinegy Route window is divided into two parts: • Virtual Destinations – a panel where all virtual destinations for the currently selected network source are displayed;...
Page 33: Routing
<?xml version="1.0" encoding="utf-8" ?> <configuration> <configSections> <sectionGroup name="applicationSettings" type ="System.Configuration.ApplicationSettingsGroup, System, Version=2.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089"> <section name="ChannelDirectory.Properties.Settings" type ="System.Configuration.ClientSettingsSection, System, Version=2.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089" requirePermission="false" /> </sectionGroup> </configSections> <applicationSettings> <ChannelDirectory.Properties.Settings> <setting name="LogDayStartAt" serializeAs="String"> <value>time</value>...
Page 34: Virtual Destinations Properties
The following dialog box appears asking you to confirm your decision about changing the source: The physical source name will be shown in the bottom part of the virtual destination icon: To disable routing for the current virtual destination, use the "Set blank…" command from the context menu: or press the button in the "Properties"...
Page 35 In the "Properties" window, the preview plays the incoming video for the current virtual destination in real time. Press the "Choose source…" button to select other physical source for the current virtual destination. The "RTP sources" dialog box appears: Page 32 | Document version: e23d164...
Page 36: Processing Nodes
Select the desired physical source you wish to add and press "OK". Press the "Set blank" button in the "Properties" dialog to disable routing for the current virtual destination. 5.3. Processing Nodes A processing node is a special type of the IP source that can be assigned to two input audio streams – primary and secondary, and process them according to the preconfigured audio mixer settings.
Page 37: Properties
As shown on the diagram above, the main part of the audio processing component is the eight-to-four channel audio mixer, which can process up to 8 input stereo audio channels (4 for the primary source, 4 for the secondary one). Properties To see the properties of the processing node, double-click it or use the "Properties"...
Page 38: Audio Settings
Press the "Reset settings" button to return to the default settings. Having set all the parameters for the current processing node, press the "OK" button to return to the Cinegy Route main Page 35 | Document version: e23d164...
Page 39: Processing Nodes Routing
Processing Nodes Routing On the basis of the processing groups and nodes, both the Cinegy Route Manager and Cinegy Route Control applications support extended routing. Refer to the article for detailed information on the Route Manager operating and Cinegy Route Manager ...
Page 40 In the same way the assignment of the processing node to the virtual destination is supported: Page 37 | Document version: e23d164...
Page 41: Cinegy Route Support Tools
• NetSendGUI To access the Cinegy Route support utilities, go to Start > All Programs > Cinegy > Cinegy Route > Support Tools. 6.2. NetCaptureGUI The given tool is used for converting an RTP/UDP stream into an MPEG transport stream file (*.ts).
Page 42: Netplaygui
This utility is used for playing one or several RTP/UDP streams in the dedicated player window(s). Run the NetPlayGUI support component to launch the Cinegy Stream Player utility: Use the drop-down list to select the stream type – RTP or UDP and specify the IP address of the stream to be played.
Page 43: Netsendgui
The NetSendGUI utility is used for transmission of an MPEG transport stream file (*.ts) into an RTP/UDP stream. Run the NetSendGUI support component to launch the Cinegy Stream Multicaster utility: In the "Source transport stream file" field specify the file to be converted into an RTP/UDP stream using the "…" button or the keyboard.
Page 44 • second of the clip from which file transmission will start; • data transfer rate in Mbit per second. This information is read-only in the Cinegy Stream Multicaster utility. However, the start point of the file trasmission can be edited through creating a BAT file.
Page 45 Here the start time value is displayed in seconds. Use the "Stop This Stream" button in the Cinegy Stream Multicaster window to stop the current stream transmission. If several instances of the utility are launched to transmit multiple streams individually, press the "Stop All Streams"...
Page 46: Amino Integration
7.2. Getting Started With a Single A140 The simplest way to use an A140 is to attach a keyboard, and type the URL for the Amino control page hosted by Cinegy Route. With a keyboard attached, it is possible to press the key to access a URL entry dialog (appears along the top- edge of the screen).
Page 47: Amino Dhcp On Windows Server
"Amino" folder. Once this virtual destination is created inside Cinegy Route Manager, you can map a stream or channel to the virtual destination. As soon as this connection is established, the Amino should switch to the described channel (the Amino reboot...
Page 48 2. Set the ASCII value to AMINOx4x: Page 45 | Document version: e23d164...
Page 49  This step is very important, since this is the key the devices will lock onto. 3. Create some custom predefined options against this vendor class, shown below: Page 46 | Document version: e23d164...
Page 50 The Amino manuals show the various codes available to inject here, but the four most useful ones are shown below:  For more details on the codes and their usage, please refer to the Amino website. Code Descriptions The following table contains description of the four most useful codes: Code Description 008 homepage...
Page 51  Please note that this code is useful only when pointing the Amino box at Cinegy Route Control homepages. Global Scope Options Global scope options applied to all units (so all Amino boxes get the same firmware) look as follows:...
Page 52 In a normal environment, using Cinegy Route – Amino integration, it is expected that each Amino box has a reservation, which tells it on boot "what" Cinegy Route virtual destination to bind to (and turns on/off on-screen logging and such).
Page 53: Customizing The A140 Html Control
JavaScript to drive Amino channel selection and other settings. While Cinegy Route comes with a ready-to-go installation of the require HTML files, as well as a simple HTTP server running with the service on TCP port 9996, customers are encouraged to customize and relocate the HTML pages, if required.
Page 54 Please back up the original files before taking customisation steps. Similarly, please be aware that re-  installing Cinegy Route or upgrading the version installed may reset changes made. Examples of other elements that may be altered: • changing branding for popups;...
