mod.: 3B
OPERATION AND MAINTENANCE MANUAL
The ViperX model with the 3B orbit a pneumatic sander designed and built
for sanding small surfaces.
Orbit
Ø Pad
Holes
RPM
Weight
Working pressure
Air consumption
Air inlet
Pad thread
Extraction
Noise:
Vibrations
max aeq sum:
Model
ViperX3B
3 mm
75mm
6 holes
6500 - 11000
675 g
6.2 Bar – 90 PSI
340 l/min
¼" Gas
M8
Centralized
82 db A
3B = 9.54 m/s²
Advertisement
Summary of Contents for Abrex-System ViperX 3B
- Page 1 mod.: 3B OPERATION AND MAINTENANCE MANUAL The ViperX model with the 3B orbit a pneumatic sander designed and built for sanding small surfaces. Model ViperX3B Orbit 3 mm Ø Pad 75mm Holes 6 holes 6500 - 11000 Weight 675 g Working pressure 6.2 Bar –...
- Page 2 After each use, perform general cleaning and check that the start/stop lever is working. Do not use liquids such as water or solvents. If any abnormality is noticed in the rotation (RPM) contact Abrex-System. DISPOSAL: separate the components according to type and material. Take...
- Page 3 2 years if the tool is registered within 30 days of purchase. The warranty for industrial use is for 1 year. Each tool must be individually registered on the www.abrex-system-tools.com website. The warranty for ViperX™ tools covers all manufacturing defects and any defective materials used in the construction of the tool.
- Page 4 (_) complete the code with the letter of the required color - T=Tiffany - Y=Yellow - W=White ABREX SYSTEM SRL - Via del Viticoltore 11 - Loc. Poggio Piccolo 40023 - Castel Guelfo di Bologna (BO) Italy Phone: +39.0542.670827 - www.abrex-system.com...
