WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
A) Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer.
B) Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to prevent power
from being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and
others by observing all safety information. Failure to comply could result in personal injury and/or property damage.
MODULE-AIR AF-24xx SERIES AIR CLEANER
(AF-2423, AF-2433, & AF-2453)
Description
This 8500 CFM Air Cleaner was designed for use as ambient air filtration
where airborne particles are prevalent. The air cleaner consists of 4 intakes
and one exhaust, one motor, one blower, electrical components and a
riveted sheet metal housing.
These units are about 410 pounds, and cannot be handled or
transported without the help of lifting tools.
It is recommended that you consult a professional electrician prior to
installing this product. If this Air Cleaner is to be used in an application that
presents a potential fire hazard, a fire protection expert should be
consulted.
Unpacking
The machine should be unpacked carefully. Check if the machine and
components are consistent with those indicated in the Parts List. If any
doubt arises or if parts appear to be missing, contact your dealer.
MODEL
NUMBER
230V THREE PHASE
AF-24xx230
480V THREE PHASE
AF-24xx480
575V THREE PHASE
AF-24xx575
MODEL
TYPE:
NUMBER
(ALL)
FORWARD INCLINE
SOUND LEVEL: 68 Db(A)
APPROXIMATE WIEGHT
AF-24xx
Operating Instructions & Parts Manual
READ AND SAVE THESE INSTRUCTIONS
Retain instructions for future reference.
MOTOR OPTIONS:
VOLTAGE
HP
5 HP
5 HP
5 HP
BLOWER:
CFM:
8500
410 lbs
Hz
AMP DRAW
60
12.6
60
6.3
60
5
Advertisement
Table of Contents
Summary of Contents for MODULE-AIR AF-24 Series
- Page 1 Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply could result in personal injury and/or property damage. Retain instructions for future reference. MODULE-AIR AF-24xx SERIES AIR CLEANER (AF-2423, AF-2433, & AF-2453) Description This 8500 CFM Air Cleaner was designed for use as ambient air filtration where airborne particles are prevalent.
- Page 2 2. Follow step (1) to remove the prefilter, then if unit is equipped with clips, push them out and away from the bag filter, slide out the old bag filter and slide in new one until clips snap around it. Revised 6-10-2014 Module-Air...
- Page 3 If you have insurance carrier may require such potentially reactive metal dusts a system. Module-Air can offer any questions relative to a (like aluminum, magnesium and basic guidelines for such an particular application, DO NOT use other materials).
- Page 4 The unit can now be lowered and changing filters. recommendations are included for the nuts under the strut can be installation of your Module-Air air tightened up to finish the 13. Turn the unit “off” and filtration system, the suspension.
- Page 5 Revised 6-10-2014 Module-Air...
- Page 6 Three phase motor 480 V Three Phase/ 60Hz 3 phase power Revised 6-10-2014 Module-Air...
- Page 7 Revised 6-10-2014 Module-Air...
- Page 8 NOTE: In order to maintain the one year warranty on MODULE-AIR products replacement filters must be purchased from MODULE-AIR for that first year. Proof of filter orders must be kept on file and be readily available upon request by MODULE-AIR.
