Summary of Contents for allpa 487150
- Page 1 VITROCERAMIC COOKJNG HOB INSTRUCTION BOOKLET PLAQUE DE CUISSON EN VITROCERAMIQUE MANUEL D'UTILISA TION...
- Page 2 This manual constitutes an integral part of the appliance. It must be kept intact and within easy reach during the entire life of the cooktop. Please carefully read this manual and all the instructions contained herein before using the appliance. Keep any spare parts supplied with the appliance. Installation and electrical connections must be carried out by a qualified technician in accordance with the manufacturer's instructions and in full compliance with current laws and safety regulations.
- Page 3 ANY ADJUSTMENT, MAINTENANCE, ETC. MUST BE CARRIED OUT WITH THE HOB UNPLUGGED AT THE MAINS. The glass-ceramic cooktop permits rapid vertical transmission of heat from the heating element below the cooktop to the pots or pans placed on top of it. Heat does not spread horizontally, thus at a distance of just a few centimetres from the cooking zone, the glass remains relatively cool to the touch.
- Page 4 In these hobs the cooking zones are controlled by knobs connected to power selectors Numbers are used to indicate cooking settings where "1" is the minimum setting and the higher one is the maximum setting. Number 0 is the off position. Extensible zones, where available, are activated over max position. To switch on the extending zone, turn the knob beyond the max setting until a click is heard, then return it to any setting from min to max.
- Page 5 Turning Touch Control on/off After start-up, the touch control requires about one second before it is ready for use. After reset, all displays and LED s will flash for about 1 second. After this time, all displays and LED s go off and the touch control is in stand-by status.
- Page 6 Use of the multiple circuits (where supplied) Depending on the model, your appliance can have a DUAL or a TRIPLE heating element. When a multiple plate is activated, the internal circuits are turned on. If you also want to turn on the outermost circuit, you need only select the extended zone key.
- Page 7 These instructions are intended for qualified technicians. The appliance must be installed correctly, in compliance with current laws. Before carrying out any operation on the appliance, it must be disconnected from the electric supply. The hob is designed to be fitted into a work surface which is larger than the hob. The dimension of the hole to be made in the worktop and the minimum distances between rear and side walls and those above are showed on figure n°1.
- Page 8 Overheating of the induction coils Cooling down necessary ER03 & Permanent use of keys; Water or cooking utensils on the Cleaning of the Control unit cuts off after 10 sec glass above the control unit operational surface permanent tone Error on filter board Controller flash defect;...
- Page 9 all / tous induction all / tous induction all / tous induction all / tous 90x33 all types...
- Page 10 Fig.2 Fig.3 Fig.4 Fig.6 Fig.5...
