Hydra 3000 Uno Technical Manual
Technical Manual
Hydra 3000 Uno
Product Codes: OVU20019, OVU20020
Doc Part No.: OVZ20041
© Overview Ltd. 2020
Page 1 of 74
Revision: 01
This is the property of Overview Ltd. No copying without permission.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hydra 3000 Uno and is the answer not in the manual?

Questions and answers

Related Manuals for Overview Hydra 3000 Uno

Summary of Contents for Overview Hydra 3000 Uno

  • Page 1 Hydra 3000 Uno Technical Manual Technical Manual Hydra 3000 Uno Product Codes: OVU20019, OVU20020 Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 1 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 2 Overview Ltd. Overview Ltd assumes no responsibility for any errors that may appear in this document. In no event shall Overview be liable for incidental or consequential damages arising from use of this document or the hardware and software described in this document.

  • Page 3: Table Of Contents

    Setup menu - PTZ .......................... 71 Appendix 2. Accessories List ......................... 73 Appendix 3: Camera Data........................74 Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 3 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 4: Introduction

    Control and imagery are routed via an installer provided Cat5E ethernet cable. Figure 1 Hydra 3000 Uno Figure 2 Hydra 3000 Uno with LED illuminator Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 4 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 5: Safety

    When shipping the camera by air it should only be carried in a pressurized hold as it is a sealed system. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 5 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 6: Contents Supplied

    Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 6 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 7: Product Specification

    The tilt head is protected from solar heating by fixed sun shields. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 7 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 8: Electrical Features

    Camera zooming, Lights on, Wiper on, Motors full load. 96 Watts* Recommended PSU min output power at max temp. 100 watts Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 8 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 9: Ip Features

    7.6. Operating System – Description of Operation See Appendix 1 for a Description of Operation. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 9 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 10: Ptz Capabilities

    Gain Automatic IR filter Automatic with manual override Security HTTPS(SSL), IP filtering, 802.1x, Digest Authentication Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 10 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 11: Installation Drawings

    8.1. Camera PTZ Unit Dimensions in mm Figure 4 Installation Diagram for Hydra Uno 3000 PTZ Unit Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 11 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 12 Dimensions in mm Figure 5 Installation Diagram for Hydra Uno 3000 PTZ Unit with LED Illuminator Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 12 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 13: Electrical Connection To Ptz

    Figure 6 Installation Diagram – Power and I/O connection cable Figure 7 Installation Diagram – Ethernet cable IP connector Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 13 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 14: Installation / Connection

    Video Management Filter System AC Power 110-240V Control Panel Figure 8 Typical System – IP Camera Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 14 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 15: Installation - Mechanical

    The Hydra 3000 spacer should be mounted to the base of the PTZ unit using screws, nuts and washers provided. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 15 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 16 Power and IO Connector Figure 10 Position of electrical connector in base of PTZ Unit Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 16 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 17: Installation Electrical

    A suitable connection box should be used for the connections to this cable, taking into account access/security, weather exposure etc. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 17 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 18: Commissioning And Set-Up

    6. Switch power on and observe the PTZ unit go through its calibration routine. This may take 2 – 3 minutes. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 18 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 19: Maintenance

    Hold in place with the washer and nut. Tighten nut to secure whilst holding blade securely. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 19 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 20 Hydra 3000 Uno Technical Manual Wiper nut Figure 13 Wiper Blade Replacement Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 20 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 21: Appendix 1 Control Instructions For Ip Cameras

    Zoom speed: the bigger the number, the faster the unit will zoom in and out when using the Zoom commands Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 21 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 22 Alarm and relay out Presets and Tours Speaker camera time Alarm icon Motion icon Figure 2: Main screen Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 22 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 23: Presets And Tours

    “modify”. To delete selected position, press “delete”. Figure 3: Tour configuration menu Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 23 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 24: Setup Menu

    Resolution: Select video resolution (Note: available resolution can depend on the codec selected) Frame rate: Select maximum frame rate Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 24 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 25 To make any changes to this setting effective, press “apply” button at the bottom of the menu (see Figure 4). Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 25 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 26 PTZ: Display the PTZ information Press “Apply” at the bottom of the menu to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 26 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 27 Quality: Set the quality of the set area Press “Save” to save the current settings. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 27 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 28 Sample rate: Select the Audio Sample Rate (Note: currently it supports only 8000 Hz) Click “Save” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 28 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 29 Press “save” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 29 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 30: Setup Menu - Camera

    Select a profile from the list and click “Apply” to use selected profile settings. To delete a profile, select it from the list and click “Delete”. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 30 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 31 Press “Save” to save the current value or “Default” to get it back to factory default. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 31 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 32 Press “save” to save the modifications or default to set them back to factory default. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 32 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 33 White LED Mode: If “on” is selected, the LED lights will turn on independently of the rest of settings, and the camera will be set to colour mode. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 33 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 34 Press “save” to save the modifications or default to set them back to factory default. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 34 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 35 Press “save” to save the modifications or default to set them back to factory default. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 35 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 36 Press “save” to save the modifications or default to set them back to factory default. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 36 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 37 Press “save” to save the modifications or default to set them back to factory default. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 37 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 38: Setup Menu - Network

    This menu will show all the information of Network setting in the camera. Settings are changed elsewhere. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 38 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 39 RTSP Port: RTSP port can be set to 554 (default) or in between 1025 to 60000 Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 39 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 40 The Auto IP settings function can be activated/deactivated by pressing on/off button. It will then show the unique ID and Auto IP address. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 40 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 41 Discovery mode: Discovery function can be activated/deactivated Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 41 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 42 Friendly name: Define the friendly name (maximum of 30 characters) Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 42 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 43 Host name of the site, the setup is complete d by entering User Name and Password registered in that DDNS site. Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 43 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 44 User ID: Define User ID to access FTP Server Password: Define Password to access FTP Server Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 44 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 45 Mail content: Define Title and message when the camera sends an email Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 45 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 46 Private Key Password: Define Password for private encryption Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 46 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 47 Press “Apply” to make effective any modifications. RTSP Connection information (if any) will be shown at the bottom. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 47 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 48: Setup Menu - Trigger Action

    To modify an existing rule, select it from the list and press “Modify”. To remove the rule press “Delete”. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 48 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 49 Post-alarm Duration: Define duration of image transferred after an event Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 49 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 50 Duration: Only if Monostable mode is activated. Relay out is operated during the setting time Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 50 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 51: Setup Menu - Events

    To modify an event rule, select it from the list and press “Modify”. Delete it by pressing “Delete” Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 51 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 52 Repeat rule: Set a recurring time the event occurs Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 52 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 53 Press “Save” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 53 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 54 Temperature: Indicates the current temperature of the camera Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 54 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 55 A Normal Closed Contact (NC): Contact is normally closed – activated when open Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 55 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 56: Setup Menu - Record

    • Record Figure 37: Record management menu Record functionality is not available in this model Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 56 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 57: Setup Menu - Security

    IP Address: Define IP address you want to apply the IP filter and press “Add” to add it to the list Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 57 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 58 RTSP stream without supplying a username/password. Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 58 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 59 Certificate: Select client certificate required for TLS authentication Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 59 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 60 Press “Apply” to make effective any modifications (Note: when HTTPS mode is chosen, input https://<IP Address> to connect to the camera). Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 60 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 61 Install CA Certificate: Install CA Certification Properties: Shows information about the selected certificate Delete: Delete the selected CA certificate Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 61 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 62 Figure 46: Service configuration menu SSH: SSH function can be activated/deactivated Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 62 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 63: Setup Menu - System

    Device Name: Define the device’s name Location: Shows camera’s location Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 63 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 64 Note: if the camera is abnormally restarted, a download button will appear to download a file that allows user to check the error information. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 64 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 65 Otherwise, the camera can be left unusable. After updating is finished, the system will be rebooted automatically. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 65 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 66 Date & Time will be updated automatically every hour when connected Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 66 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 67 Date&Time Settings: Set the Start time and End time that the DST apply Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 67 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 68 Operator: Most of the functions are allowed except for accessing “Setup” menu o Viewer: Only monitoring is allowed Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 68 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 69 Press “Refresh” to refresh the log list, “Filter” to view the filtered log and “Backup” to backup the filtered log. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 69 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 70 Only Camera Settings: Reset only camera related settings to factory default Once required option is selected, press “Apply” to reset the unit. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 70 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 71: Setup Menu - Ptz

    Power Up Action: If activated, the camera will perform the selected action when switched on o Action: Set the action to perform Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 71 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
  • Page 72 Note: if the wrong option is selected, the image will show upside down on the viewer Press “Apply” to make effective any modifications. Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 72 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 73: Appendix 2. Accessories List

    3000 (240VAC / 48VDC) suitable enclosure. OVU20028 EMI Filter Power Supply For EMC protection Protection Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 73 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.

  • Page 74: Appendix 3: Camera Data

    Digital Zoom Wonwoo Up to 30x Approx. 65.1° (W) -2.34° (T) Up to 32x MM-308-M2 Doc Part No.: OVZ20041 © Overview Ltd. 2020 Page 74 of 74 Revision: 01 This is the property of Overview Ltd. No copying without permission.
