Summary of Contents for Stout Designs TRAILBLAZER
- Page 1 2020 TRAILBLAZER – OWNER’S MANUAL TRAILBLAZER - Operation Manual Stout Designs, LLC 1/1/2020...
- Page 2 Operating tips: VERY IMPORTANT • Always run TRAILBLAZER at full throttle when cutting. • Make sure the kill switch somewhere close to you so you can shut the machine down in the event you need to. (i.e. if you get the saw in a bind or your around bystanders.) •...
- Page 5 TRAILBLAZER US PAT. D795,307 US PAT. 9,807,928 VERTICAL TRAIL TRIMMER OPERATOR / SAFETY MANUAL !WARNING! Note the following before starting: Please read the operator's manual carefully.
- Page 6 If the retailer who sells your machine is not Stout Designs, LLC or one of our authorized dealers, ask for the address of your nearest service dealer or the product can be returned to Stout Designs, LLC for any repair needs.
- Page 7 The only accessories you can operate with this equipment are ones provided by Stout Designs, LLC and specifically designed for your exact unit.
-
Page 8: Head Protection
! WARNING ! A TRAILBLAZER can be dangerous if used incorrectly or carelessly, and can cause serious or fatal injury to the operator or others. It is extremely important that you read and understand the contents of this operator’s manual. -
Page 9: Hearing Protection
must be worn if the trees being cleared are taller than 2 m. Approved head protection must comply with the ANSI Z89.1. HEARING PROTECTION Wear hearing protection that provides adequate noise reduction. Generally, the louder the noise, the shorter the exposure time before hearing protection is required. For instance, you may be exposed to a noise level of 90 dB for 8 hours per day (unless they experience a Standard Threshold Shift) before hearing protection is required. -
Page 10: First Aid Kit
GLOVES Gloves should be worn when necessary, e.g. when fitting cutting attachments. If a hazard assessment reveals that you face potential injury to hands and arms that cannot be eliminated through engineering and work practice controls, you must ensure that you wear appropriate protection. - Page 11 ! WARNING ! All servicing and repair work on the machine requires special training. This is especially true of the machine′s safety equipment. If your machine fails any of the checks described below you must contact your service agent. When you buy any of our products we guarantee the availability of professional repairs and service.
-
Page 12: Cutting Equipment
TRAILBLAZER blades are laser cut and specially designed to optimize cutting efficiency. These blades need to be replaced by TRAILBLAZER blades only. Replacing blades with any other type of blade will void your warranty and could cause serious injury and possible death to the operator and or others. -
Page 13: Fuel Safety
FUEL SAFETY Never start the machine if one of the following conditions are noted: If you have spilt fuel on it. Wipe off the spillage and allow remaining fuel to evaporate. If you have spilt fuel on yourself or your clothes, change your clothes. Wash any part of your body that has come in contact with fuel. - Page 14 DURING FUELING !WARNING! Taking the following precautions, will lessen the risk of fire: Mix and pour fuel outdoors, where there are no sparks or flames. Do not smoke or place hot objects near fuel. Always shut off the engine before refueling. Always stop the engine and let it cool for a few minutes before refueling.
- Page 15 ATV’s stability if tilted to the blade or left side. Always be mindful that when your ATV tilts left the top of the TRAILBLAZER will tilt out as well possible cutting or engaging a tree trunk in lieu of a limb.
-
Page 16: Equipment Warranty
In lieu of all other warranties, express or implied, we warrant the equipment covered by Stout Designs LLC to be free from defects in material and workmanship under normal use and service and when properly maintained. Use or service with corrosive or abrasive chemicals or cutting materials larger than the 2”... - Page 37 MAINTENANCE GUIDE for TB-001 A machine is only as good as maintenance that it receives. The following checks and service points below are typically used by STOUT DESIGNS, LLC and are highly recommended. COMPONENT MAINTENANCE INTERVAL MAINTENANCE INSTRUCTIONS I/C Engine / Motor See Engine Manual See Engine Manufacturer’s Service Manual.
- Page 38 Check and fill fuel, check oil to make sure oil is Fuel & Engine Oil Before Every Use full. Always check these fluids while on level ground. Fill as required. Check Every 10 Hours See Engine Manual for instructions on Air Filter Replacement per maintenance and replacement intervals...
- Page 39 Check and fill fuel, check oil to make sure oil is Fuel & Engine Oil Before Every Use full. Always check these fluids while on level ground. Fill as required. Check Every 10 Hours See Engine Manual for instructions on Air Filter Replacement per maintenance and replacement intervals...
