Summary of Contents for Rokky Rokky Heat
- Page 1 Rokky Heat Assembly and operating manual Download Startup-guide to find out how to configure and use the application the Rokky system. www.rokky.co/support...
- Page 3 Hello! You have just joined the ROKKY community. We are happy that you are with us. Using the ROKKY heating system, you prove that care for the natural environment is extremely important to you. You have chosen ROKKY, which reduces CO2 emissions by up to 60%, while also saving huge savings on heating.
- Page 4 HEATER’S TECHNICAL PARAMETERS A[mm] B [mm] C [mm] D [mm] 1200 1490 1800 1270 12 mm 50 mm biały czarny...
- Page 5 SAFETY Life is the greatest value. ROKKY is an electrical product. Take care of your and your loved ones’ safety. Familiarize yourself with the ba- sic principles of product use. Use only a working product. If you notice any external damage, con- tact an electrician before connecting the device to a power source.
-
Page 6: Where To Install The Device
WHERE TO INSTALL THE DEVICE? The ROKKY radiator was designed for heating residential, office and ho- tel rooms. If the device is installed in a place for other purposes, consult the manufacturer. The device has been equipped with protection made... - Page 7 When choosing a place to mount the device, it is necessary to keep the minimum distances between the device and other objects in a given room. (drawing) > 5 0 > 5 0 The lightweight design of the device allows its assembly on virtually all types of walls.
-
Page 8: Device Construction
DEVICE CONSTRUCTION Front Back Aluminum radiator body Control Panel Class II power cord (depending on version with or without plug) Radiator control module Power switch Mounting console mounting locations... -
Page 9: Device Installation
DEVICE INSTALLATION Contents of the package: Before proceeding with assembly, additionally obtain the necessary tools such as a spirit level, drill, pencil, tape measure, screwdriver. In order to make the proper installation you will need the appropriate dowels and screws adapted to the type of wall you have. Warning! The device must not be live during installation. - Page 10 Dimensions: see table on page 2.
- Page 12 Warning! Make sure that the radiator slings are securely at- tached to the screws coming out of the wall, and the con- nection itself prevents the radiator from being accidentally removed from the wall.
-
Page 13: Connecting The Device
CONNECTING THE DEVICE The electrical connection of the device is provided with 230 V, 50 Hz. The device does not require and does not have an earthing conduc- tor, therefore it is forbidden to attempt to earthing the device. To connect the device to an electrical voltage: Check whether the voltage in the network corresponds to the va- lue indicated on the nameplate. - Page 14 The device is equipped with a mechanical on / off switch, which is located at the back of the heater at the outgoing cable. Before swit- ching on, check that the switch is in the right place.
- Page 15 HEATER CONFIGURATION REMOTE MODE To set up the heater in remote mode, please refer to the „Rokky System” manual which can be found at www.rokky.co/support or scan the QR code: The ROKKY radiator has a full range of its functionality only in Internet connection mode.
-
Page 16: Operation In Local Mode
OPERATION IN LOCAL MODE ROKKY can work in local mode without internet connection. The devi- ce is completely managed from the level of the keyboard located on the device. Remember that in local mode ROKKY has only standard heating power management functions. -
Page 17: Factory Settings
To restore the radiator’s factory settings, press „-” button located on the radiator control panel for 30 seconds. Performing this function will remove the radiator from the Rokky system. To reconnect the radiator to the system and application, the configuration process described in the Rokky Startup guide must be... - Page 18 WSKAZANIA PANELU STERUJĄCEGO The panel contains 5 two-color LEDs. In the REMOTE mode, the cur- rent radiator power is indicated by white light, in the LOCAL mode by orange light. 100% ERRORS Damage to the thermal protection. The LED system blinks alternately with orange light. Overheating.
-
Page 19: Standards And Directives
SPECIFICITY OF OPERATION Due to the specificity of the radiator design and protection of control components, the marked area is a cold area that does not participate in heating. The above disabled area has no effect on the efficiency and effectiveness of the device. -
Page 20: Terms Of Warranty
TERMS OF WARRANTY The manufacturer gives a 2-year warranty on the products offered by him. The warranty period is counted from the moment the product is purchased by the Consumer, with the proviso that the warranty period is 2 years from the date of purchase, but not more than 3 years from the date of production. -
Page 21: Maintenance
• interference in the construction of the device. The warranty does not cover damage caused by the so-called force majeure, understood as a future phenomenon, impossible to predict and to prevent (eg atmospheric events, disturbances in electrical in- stallations, war, natural disasters). MAINTENANCE We recommend keeping the radiator clean. - Page 22 According to the regulations in force, the electric appliance that your ROKKY radiator is purchased can not be placed together with other wastes, because it is subject to utilization.
- Page 23 Producer Rokky Sp z o.o. www.rokky.co support@rokky.co...
- Page 24 v. 200313 JR...
