- Page 1 2014 NINTENDO BARTOP ASSEMBLY INSTRUCTIONS VERSION 1.0 HARUMANCUSTOMS.COM...
- Page 2 Nintendo Assembly Instructions...
-
Page 3: Main Cabinet Assembly
Tools & Materials Needed: Rubber Mallet Screwdriver Wood Glue Drill & Assorted Drill bits Rags Main Cabinet Assembly: Unpack the box and locate the following parts and lay them out on a clean hard surface:... - Page 4 Take the wood glue and insert into the areas marked red on the right side:...
- Page 5 Insert the Admin Panel and Bottom Panel into the Right Side. Make sure that speaker cutout is near the top:...
- Page 6 Next, insert the Bezel Shelf Panel as shown, with the plexi slot facing UP and closest to the rear of the cabinet (note the part has been colored to help with visualization):...
- Page 7 Insert the Upper Back and Lower Back Panel as shown:...
- Page 8 Install the Top Panel and the Lower Marquee Panel as shown. Make sure the T-molding slot cut in the Top Panel faces the rear of the cabinet.
- Page 9 At this time place a long & short baton in the remaining two slots. Carefully place the remaining side on top (no glue at this time) and line up all the tabs into the slots. When the tabs and slots are aligned, press down. Place a weight on top of the side to apply pressure.
-
Page 10: Monitor Mounting
Once the glue has dried overnight, remove the weight and remove the side that wasn’t glued. Place that side down on a flat surface, slots facing up, and add glue into the slots. Carefully turn over the glued side / panels assembly and insert the tabs into the correct slots, press down, add a weight, and wipe up any excess glue.
