NEWFOUNDLAND
Installation Instructions
The Newfoundland Emergency Hot spot is a large IP67 case with built-
in antennas that are optimized for the extra thick(3.5mm) plastic used
in industry strength cases. Both sets of LTE and Wi-Fi antennas were
designed for maximum performance even in remote areas where the
cellular infrastructure may have been compromised. Parsec has taken
the unique approach to design all the antennas to fit safely into the lid of
the case reducing damage and loss of performance due to hard use. The
Newfoundland is configurable up to a 13 in 1 with up to 2 sets of 4X4
MIMO LTE, 4X4 MIMO WIFI and GPS/GNSS capable of running dual
SIM's simultaneously. This 5G ready, 600 MHz – 6 GHz antenna is both
portable and IP67 rated.
REQUIRED TOOLS
5/32 Hex Allen Screwdriver
Phillips Screwdriver
9" Zip Ties
Scissors
REQUIRED ACCESSORIES
Router (select one of the following routers.)
•
CRADLEPOINT AER2200
•
CRADLEPOINT IBR1700-1200M
•
CRADLEPOINT E3000
•
CRADLEPOINT IBR900-1200M (2)
•
SIERRA WIRELESS AIRLINK MG90
•
SIERRA WIRELESS AIRLINK MP70
•
INSEEGO SKYUS 500
•
INSEEGO SKYUS 300
Battery: Chargetech 54k AC Battery Pack (OPTIONAL)
Ethernet Cords: 4pc (Length as required by the customer)
USB Cords - 1 pc (length as required by the customer)
Power Supply (required for router)
Battery Straps (OPTIONAL)
Extension Cord (NEMA 5-15 Plug to NEMA 5-15 Socket)
Advertisement
Summary of Contents for Parsec Technologies NEWFOUNDLAND
- Page 1 The Newfoundland is configurable up to a 13 in 1 with up to 2 sets of 4X4 MIMO LTE, 4X4 MIMO WIFI and GPS/GNSS capable of running dual SIM’s simultaneously.
-
Page 2: Router Installation
Router Installation: Step 1. Take off the top cover plate by unscrewing the 6 cap nuts using the 5/32 Hex Allen screwdriver. (Figure 1) FIGURE 1 Step 2. Check if the router needs brackets to mount it to the router mount plate. The Cradlepoint AER2200 and E3000 will need brackets to mount. - Page 3 Step 4. Connect the Antenna cables to the router. Clean all connectors so there is no dust in the terminals. Follow the chart to connect the cables. (Figures 5-7) FIGURE 5 FIGURE 6 FIGURE 7...
- Page 4 Step 5. Choose the right AC power supply unit for the router and connect it to the router. Step 6. Mount the router on the router mount base plate. Match the mount holes on the router to the holes on the router mount base plate.
- Page 5 Step 3. Connect the AC adapter of the fan and the router power supply unit to the surge protector. Zip tie the adapters to secure them. Make sure the surge protector is switched on. (Figure 10) FIGURE 10 Battery Connection Instructions (OPTIONAL): Step 1.
- Page 6 Step 3. Turn off the AC switch and Battery power switch. Plug in the AC plug of the surge protector to the AC port of the battery. (Figure 11) FIGURE 11 Step 4. Connect the charging port of the charger to the battery. Connect the AC plug from the charger to the AC adapter on the case.
-
Page 7: Antenna Operation
Antenna Operation: Step 1. Check all connections and make sure they are secure. Make sure all of the cables are connected to the right ports. Step 2. Before turning on the antenna, open the fan caps on the case. Be sure they are always open during operation. When operating, keep the antenna away from any liquids or splashing. - Page 8 Step 3. Plug in one end of the Extension Cord (NEMA 5-15 Plug to NEMA 5-15 Socket) to the case (figure 13) and the other end to the wall. Step 4. Turn on the power source. The router will turn on and display lights will start blinking. If you are using a battery, turn on the main power switch and the AC switch of the battery.
- Page 9 20 cm from all persons to only. It cannot be used as a warranty. Parsec Technologies, Inc. will - Install the mast close to power lines as it can cause serious injuries satisfy RF exposure compliance.
