1.Getting Start
1.1 Setting up the 51806378
Download the MÜZO Player App to your iSO system(iOS 6.0 or later Required)
MÜZO Player App to your iSO system(iOS 6.0 or later Required) from the App Store or for the Android system
Before using the MUZO Player App, make sure that the 51806378
1.2 Specifications
Product Size
270X83X135MM
Unit Weight
N.W:2.1KGS/Unit
Speaker drivers
2.1 HI-FI System： 1 set 10W Subwoofer(3.5")+2sets 5W Tweeters(1.75")
Audio effect
DSP 3D Surround sound
Battery
3 sets SAMSUNG 18650 Battery, 2600MAH each, total Capacity: 7800MAH
3 sets SAMSUNG 18650 Battery, 2600MAH each, total Capacity: 7800MAH
Power Supply
DC adaptor: 15V/2A;
Play Time
Up to 12Hours against 100% Volume, 20Hours against 70% Volume
Up to 12Hours against 100% Volume, 20Hou
2. Playing Modes, there are total five playing modes
Playing Modes, there are total five playing modes
Play Modes
Features
Peer to Peer direct connecting and playing
Peer to Peer direct connecting and playing
Network connection
Network connection
1)connecting internet via Wifi Router;
1)connecting internet via Wifi Router;
2)Independent play or multiple play via MUZO Player;
2)Independent play or multiple play via
3)Play cloud music via WIFI internet;
3)Play cloud music via WIFI internet;
4)Play global internet radios;
WIFI Mode
5)Play music via Pandora,Spotify, TuneIn,iHeart Radio etc. social media;
6)Alarm Clock setting via MUZO
Social communication
Social communication
1)One MUZO Player control more than two sets
song or same song available;
song or same song available;
2) Different iSO or Android system(iPhone/iPad etc) control one or more sets
2) Different iSO or Android system(iPhone/iPad etc) control one or more sets
51806378 available, enjoy the music what you like;
Bluetooth Mode
Bluetooth connection and play music, Max distance: up to 60M;
Bluetooth connection and play music, Max distance: up to 60M;
SD Card Mode
Directly Reading Micro SD or sharing on MUZO Player;
Directly Reading Micro SD or sharing on
Line in Mode
Audio cable connecting to Computer, Mobile, Ipad etc any Line In device;
Audio cable connecting to Computer, Mobile, Ipad etc any Line In device;
Recording Mode
Record the song when you sing, saving to Micro SD card automatically
Record the song when you sing, saving to Micro SD card automatically
51806378 is properly connected and in working condition.
1 set 10W Subwoofer(3.5")+2sets 5W Tweeters(1.75")
radios;
Play music via Pandora,Spotify, TuneIn,iHeart Radio etc. social media;
MUZO Player;
Player control more than two sets 51806378 system, play different
available, enjoy the music what you like;
User Manual
MUSOS 51806378
system from the Google Play Store.
Led Light
Color
White
Blue
White
Green
White

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Y5-PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for MUSOS Y5-PRO

  • Page 1 User Manual MUSOS 51806378 1.Getting Start 1.1 Setting up the 51806378 Download the MÜZO Player App to your iSO system(iOS 6.0 or later Required) MÜZO Player App to your iSO system(iOS 6.0 or later Required) from the App Store or for the Android system system from the Google Play Store.

  • Page 2: Network Connection

    Press mode button once to change to Bluetooth Mode, BT/AUX led light will be slow blinking in blue color,In your device setting, turn Bluetooth ON, pairing with “MUSOS 51806378” , after paired successfully, any music can be played on your device.

  • Page 3: Remote Controller

    3.Remote Controller 51806378 is not only controlled by MUZO player, but also remote controlled, Quick guide for remote panel as below 1.Power button/Sleep/Reboot (need holding 3 seconds for Sleep mode) 2.Pause/Play 3.Modes switch 4.WPS: researching Wi-Fi connection (need to work with MUZO player) 5.Mute button 6.Previous track/Next track 7.Volume down/volume up...
  • Page 4 4.3 Naming your 51806378 After you first add the 51806378, it will show the interface and you can name your 51806378 such as Bedroom etc, or Customized the name by yourself. e.g. if your speaker is in the family room, you can choose “Family Room” as its label. 4.4 Touring your MUZO Player The easy-to-use MUZO Player turns your smart device such as iPhone into a remote to control music playing on all your 51806378s.
  • Page 5 c)Multi-Channels You can listen to the internet radio and your songs with another 51806378 within one room at the same time; d)Music playback Preset music playlists can be played and controlled by your Smart device or 51806378 itself 4.5 Searching Cloud Music all your favorite songs and artists can be searched via the cloud music of MUZO Player.
  • Page 6 4.6 Favorite Songs The Favorite function allows you to freely collect your favorite songs, Just click the heart near the bottom left of the screen, if you want to listen to it next time, just open the Favorite on the main menu, no need to search for the song again. 4.7 My Music Through My Music function, you can playback your local music on your smart device such as iPhone, iPad or Android device.

  • Page 7: Music Service

    2)You can add or remove a song to a playlist 3)You can set the recently created playlist to a preset playlist. (e.g. Set Channel 6 as your most recently created playlist). 5 Music Service 5.1 Spotify Spotify is a digital music service that gives you access to millions of songs. To stream Spotify, you will need a Spotify Premium account. You can control music play through your Spotify app.

  • Page 8: Warranty Info

    media. 5.4 TuneIn Online radio TuneIn is powerful, it can provide a collection of tens of millions of online radio around the world, click TuneIn on the main function control interface: choose your favorite programs, start a wonderful radio trip Remark: All above service has been Authorized by official social Media.
  • Page 9 FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
