Carefully read through the entire Instruction Manual before using your new

Westmix Cement Mixer. Take special care to heed the Cautions and Warnings.

Your Westmix Cement Mixer has many features that will make the job faster

and easier. Safety, performance and dependability have been given top priority

to ensure easy operation and maintenance.

SAVE THIS MANUAL FOR FUTURE REFERENCE

ASSEMBLY

INSTRUCTIONS

MANUAL

2.2CF 65L

CEMENT MIXER

WM2.2MIB1

Table of Contents

Need help?

Do you have a question about the WM2.2MIB1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Westmix WM2.2MIB1

Page 1 Carefully read through the entire Instruction Manual before using your new Westmix Cement Mixer. Take special care to heed the Cautions and Warnings. Your Westmix Cement Mixer has many features that will make the job faster and easier. Safety, performance and dependability have been given top priority to ensure easy operation and maintenance.
Page 2: Table Of Contents
CONTENTS Product Description Maintenance Tools Required for Assembly Operation Description of Symbols Cleaning Specifications General Inspection General Safety Rules Repairs Additional Safety Rules for Cement Mixers 5 Power Cord Product Contents Warranty Assembly Instructions Contact Details...
Page 3: Product Description
PRODUCT DESCRIPTION 1. Cement Mixer Bowl 6. Upper “L” Frame 2. Tipping Arm Handles 7. Middle “L” Frame 3. Motor Cover 8. Front “L” Frame 4. Motor Mount 9. On/Off Switch 5. Wheels TOOLS REQUIRED FOR ASSEMBLY • 8mm, 10mm, 12mm, 14mm, 17mm & 19mm •...
Page 4: Description Of Symbols
b. Do not operate power tools in explosive DESCRIPTION OF SYMBOLS atmospheres, such as the presence of flammable The rating plate on your cement mixer may show liquids, gases or dust. Power tools create sparks symbols. These represent important information which may ignite the dust or fumes.
Page 5: Additional Safety Rules For Cement Mixers
3. Personal Safety e. Maintain power tools. Check for misalignments or binding of moving parts, breakage of parts a. Stay alert, watch what you are doing and use and any other condition that may affect the common sense when operating the power power tools’...
Page 6 Check that there is a ground connection. Prevent • When you leave your workplace, switch off the body contact with grounded surfaces: pipes, motor and pull out the power plug. radiators, ranges, and refrigerator enclosures. • It is imperative to observe the accident Make sure your fingers do not touch the plug’s prevention regulations in force in your area as metal prongs when plugging or unplugging the...
Page 7: Product Contents
PRODUCT CONTENTS Frame Assembly Contents Upper “L” Section 1 unit Middle “L” Section 1 unit Front “L” Section 1 unit Upper Cross Brace - Right* 1 unit Upper Cross Brace – Left* 1 unit Axle Section 1 unit Lower Cross Brace - Right* 1 unit Lower Cross Brace –...
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTIONS 1. “L” FRAME UPPER Ensure that you are working on a clean flat surface. A drop sheet may be useful to ensure parts are not damaged during assembly. Grab the Upper “L” Section (A) and Middle “L” Section (B) and lay on side. Using the bolt (AB) insert the bolt through the hole, slide on the washer and then attach the nut to the end.
Page 9 5. LOWER CROSS BRACE Grab the Lower Cross Brace – Right (G), with bolt (AC) insert this through the brace and then through the hole in the middle “L” section. Grab the Lower Cross Brace – Left (H) and insert this onto the bolt and then slide on the washer and nut.
Page 10 9. BEARING ARM Grab the Bearing Arm Housing Section (J) and place this onto the top of the Upper “L” section. You will need to keep hold of this as it will not sit in place by itself. Grab the Frame Arm Mount (L) and place this over the top of the Bearing Arm Housing Section.
Page 11 12. REAR PULLEY COVER Grab the Rear Pulley Cover (N) and Cover Support – Top (Q). Now grab a bolt (AG) with washer already on and insert it through the inside of the Rear Pulley Cover (N) and then through the Cover Support –...
Page 12 15. MOTOR Grab the Motor (W) and ensure the motor pulley is secure using an 8mm spanner to tighten. Place the Motor on the motor mount with the motor pulley in line with the larger pulley. Insert bolt (AI) through holes in base of motor and through inner holes of Motor Mount.
Page 13 19. MOTOR COVER Grab a bolt (AI) and insert the bolt through the outer hole of the motor mount and then slide on the washer and lightly tighten the nut. Insert bolts onto the remaining three holes. Grab the Motor Cover (P) and place it over the motor and line up the holes in the bottom of the motor cover with the bolts that were placed on the motor...
Page 14: Maintenance
IMPORTANT: Always switch on the motor before MAINTENANCE loading the mixer. • Clean the cement mixer after every use. IMPORTANT: Ensure the tyres are both adequately • Remove dust and dirt frequently. Cleaning is and evenly inflated before loading. best done with a rag or a soft brush. Wear safety 1.
Page 15: Cleaning
CLEANING GENERAL INSPECTION • Regularly check that all the bolts and nuts are • After every mix it is advisable to clear any tight. They may vibrate loose over time. build-up of cement from the mixing paddles inside the bowl. If left to dry the cement can be •...
Page 16: Warranty
WARRANTY Ames True Temper Australia Pty Ltd ABN 34 144 018 280 (ATTA) provides that this product is covered by a 12 month warranty from the date of purchase, against faulty workmanship and/or materials with the exception of pneumatic tyre/s and tube/s, which are covered by a 6 month and 1 month warranty respectively. To make a claim, return the faulty item together with proof of purchase to the place of purchase.
