USER MANUAL
Smart diagnostic tool for understanding
and improving your vehicle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OBDeleven and is the answer not in the manual?

Questions and answers

Summary of Contents for Voltas IT OBDeleven

  • Page 1 USER MANUAL Smart diagnostic tool for understanding and improving your vehicle.
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Do not disassemble, puncture, modify, drop, throw or cause other unnecessary shock to device. Do not use the device if it is damaged or modified as it could harm your vehicle. All wireless data transferring devices produce interference that may affect other devices which are placed nearby.
  • Page 3 Do not submerge or expose to water. Installation and/or handling during a lightning storm is prohibited. Do not use OBDeleven if it distracts driver or causes incovenience due to OBD II placement. Device must not interfere with driver. The device uses SELV limited power source.
  • Page 4 OBDeleven OBDeleven PRO car diagnostics app... Voltas IT PEGI 3 (6,243 ) • 500 thousand MORE INFO INSTALL Contains ads • In-app purchases Download application from App Store (for iOS devices) or Google Play (for Android devices).
  • Page 5: Quick Start

    QUICK START Plug the device into OBD-II port. Start the engine. Make sure power LED is on. Power LED indicates Bluetooth status. RED power LED - device is on. Blinking LED indicates your device is in working condition. The OBD-II port is usually located under the dashboard or in the left side beneath the steering wheel column. It may also be located behind a latch or contain a cover.
  • Page 6 Sign in Sign up ACCOUNT Create an account: connect with Facebook, Twitter or sign up with e-mail.
  • Page 7 CONNECT TO YOUR CAR Pair the device with your smartphone or tablet via Bluetooth. Open OBDeleven application, turn on Bluetooth and click “Add device”. Place your smartphone next to the device to pair. Enter pairing code: 1234...
  • Page 8 Set up password Tekstas apie slaptažodžio keitimą anglų kalba, kadangi jo neturiu tenka rašyti lietuviškai. Type your password Repeat your password Don’t ask on start up Cancel Accept CREATE DEVICE PASSWORD Enter 6 digit code to create unique device password. This will help you to protect and secure your vehicle from unauthorized access.
  • Page 9 OBDeleven PRO license Tekstas apie slaptažodžio keitimą anglų kalba, kadangi jo neturiu tenka rašyti lietuviškai. I have activation code Type your code Cancel Accept Activate PRO ACTIVATION If you bought PRO or ULTIMATE pack you will be asked to activate PRO license. If you already had PRO license on your...
  • Page 10 Headlight washer Inspection service reset LED license plate lamps ONE-CLICK APPS AND CREDITS Package includes credits, which enables to use one touch coding features - activate new functions or disable unwanted ones, unlock cool visual features, control comfort systems, perform service, adjust car lights and more with just one click.
  • Page 11 Works with all iOS 11 and newer iPhones/iPads/iPods Works with all Android 4.4 or newer phones/tablets that support Bluetooth OBDeleven device is designed to fully support diagnostic, programming and coding functions for all* VAG group vehicles: Audi, Volkswagen, Škoda, Seat, Bentley**, Lamborghini**.
  • Page 12: Basic Functions

    BASIC FUNCTIONS Cloud-based automotive diagnostics software for iOS and Android operating systems can fully access your car for: • Vehicle identification from VIN • Read and clear trouble codes from all control units • Read information about control unit • Share diagnostic data log via email •...
  • Page 13 PRO FUNCTIONS OBDeleven device becomes a professional diagnostic tool upgraded with PRO license, which allows: • Trouble code Freeze frame • Advanced control unit information • Live data / Charts • Coding / Coding II / Long coding • Sub control unit coding •...
  • Page 14 NEXTGEN OBDELEVEN SPECIFICATIONS Size 41 x 33 x 24 mm Weight Weight Idle Power Consumption / Max Power Consumption 0.42 W / 0.54 W Input Current 45 mA Input Voltage 12 V Bluetooth Colour Black...
  • Page 15: Troubleshooting Tips

    TROUBLESHOOTING TIPS 1. If your phone do not find OBDeleven device via phone Bluetooth settings: • Make sure that RED power LED on device is active • Disable and then enable phone Bluetooth • restart your phone • Try to search for device via Bluetooth settings with vehicle ignition turned off •...
  • Page 16: Return Policy

    RETURN POLICY We are accepting 14 days return policy. Item must be returned in original package and without marks of use. • Hardware or accessories, purchased online, may be opened for the purpose of inspection (but not used) and may be returned for refund or exchange within 14 days of the dispatch date.
  • Page 17: Warranty

    WARRANTY Voltas IT guarantees its products to be free of any manufacturing defects for a period of 24 months. If a product should fail within this specific warranty time, the product can be: • Repaired • Replaced with a new product...
  • Page 18 VAT or other associated taxes or charges when returning the Hardware. Hardware for which Voltas IT cannot reproduce the claimed defect or for which your purchase cannot be verified will be rejected.
  • Page 19: Regulatory Compliance

    Waste Electrical and Electronic Equipment Directive DECLARATION OF CONFORMITY Refer to article 10(9), shall be provided as follows: Hereby, Voltas IT, LLC declares that the radio equipment type OBDeleven is in compliance with Directive 2014/53/EU. Please note that, in the European Union, any warranty period less than two year shall be increased to two years.
  • Page 20 Custom made in EU. High quality standard by European manufacturers. Developed by Voltas IT, LLC in Lithuania, assembled in Lithuania. Voltas IT, LLC, Inovaciju str. 3, Biruliskes, LT-54469, Kaunas region, Lithuania | TM OBDeleven and Voltas IT, LLC. All rights reserved.
  • Page 21   FCC Regulations:  This device complies with part 15 of the FCC Rules. Operation is subject to the  following  two  conditions:  (1)  This  device  may  not  cause  harmful  interference,  and (2) this device must accept any interference received, including interference  that may cause undesired operation.   This equipment has been tested and found to comply with the limits for a Class B  digital device, pursuant to part 15 of the FCC Rules. These limits are designed to  provide reasonable protection against harmful interference in a residential  installation. This equipment generates, uses and can radiate radio frequency  energy and, if not installed and used in accordance with the instructions, may  cause harmful interference to radio communications. However, there is no  guarantee that interference will not occur in a particular installation. If this  equipment does cause harmful interference to radio or television reception,  which can be determined by turning the equipment off and on, the user is  encouraged to try to correct the interference by one or more of the following  measures:  —Reorient or relocate the receiving antenna.  —Increase the separation between the equipment and receiver.  —Connect the equipment into an outlet on a circuit different from that to which  the receiver is connected.  —Consult the dealer or an experienced radio/ TV technician for help.   Changes or modifications not expressly approved by the manufacturer could  void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an ...
