Healthy Hearth StoveCat Retro-Fit Installation Manual

Congratulations! You have purchased the GraceFire StoveCAT™, a revolutionary new Emission Control Device for wood
burning stoves, heaters and furnaces. Follow these instructions carefully for safe and efficient operation. You will find
additional information @ www.healthyhearth.net
The GraceFire StoveCAT Emission Control Device for Wood Stoves
The GraceFire StoveCAT™ Emission Control Device from Healthy Hearth LLC is a revolutionary catalytic system
designed especially for wood burning stoves. The StoveCAT™ utilizes a patented three stage catalytic design to
capture the pollutants from the wood burning fire without developing any backpressure of harmful blockage. The
StoveCAT™ Catalytic System provides secondary ignition for the wood smoke combustibles preventing them from
leaving the firebox as particulate pollution. The direct flame on the catalytic surface actually cleans the catalytic unit.

Remove the Existing Connector Pipe from the Wood Stove

The StoveCAT™ ECD is 14" high. It is designed to be installed on a top mounted 6" exhaust port. You only need to
remove enough connector pipe to make the installation. On the top of the StoveCAT™ ECD is a 6" DVL adapter from
Duravent. It offers several connection options.
Wood Heater

Position the StoveCAT ECD on the Exhaust Port on the Wood Stove

Wood Heater
The high temperature components of the StoveCAT™ are manufactured from high
quality stainless steel by DuraVent, the world's largest venting component manufacturer.
The catalytic components are state-of-the-art ceramic material from Clear Skies
Unlimited. The StoveCAT™ can either be installed by a chimney sweep or as a "Do-it-
Yourself" project by the homeowner.
The StoveCAT™ is easily installed. It doesn't require any power and only has one
moving part which is internal. The StoveCAT™ catalytic device is installed on the
exhaust port of the wood stove. The installation of the StoveCAT™ converts a
conventional wood burning stove into a cleaner burning heater with better heating
efficiency.
These instructions allow the homeowner to easily install the emission control device on
the wood heater for safe and efficient use. Follow all Safety Instructions.
Insure mounting surface on the wood stove is clean and free of creosote.
The StoveCAT™ ECD is easily installed on the wood heater. It simply rests on the
exhaust port. There are no fasteners or mechanical connections. It is very important
however that the mating surface on the bottom of the StoveCAT™ goes inside of the
exhaust port on the stove. Insure that the StoveCAT™ is aligned properly.
A gasket is bonded to the bottom of the StoveCAT™. It will seal on the mounting
surface of the wood stove. Insure that the gasket is in place prior to installation.
Installation Guide
CAUTION
CAUTION
1
