Summary of Contents for demig DE-BT 1000
- Page 1 Prozessautomatisierung GmbH Manual Terminal DE-BT 1000 By demig Prozessautomatisierung GmbH from version 12.1.1 (2017)
- Page 2 Prozessautomatisierung GmbH This manual was produced using ComponentOne Doc-To-Help.™ Manual Terminal DE-BT 1000...
-
Page 3: Table Of Contents
Installation Instructions ................1 1.1.4. Structure of the Operating Instructions ............2 1.1.5. Security Symbols ..................2 1.1.6. Disclaimer....................2 Brief Explanation of the Industrial Terminal DE-BT 1000 ......... 3 1.2.1. General Explanation ..................3 General Handling of the DE-BT 1000 .............. 3 1.3.1. Commands ....................4 1.3.2. -
Page 5: Chapter: Introduction
General Handling Please read the operating instruction carefully before installing or handling the industrial terminal DE-BT 1000, in order to avoid dangerous situations and damages due to operating errors. This operating manual is limited to the handling of the DE-BT 1000 and does not include all different applications. -
Page 6: Structure Of The Operating Instructions
Protective ground wire (min. 6mm² cross section!) 1.1.6. Disclaimer Possible errors cannot be excluded. demig Prozessautomatisierung GmbH assumes neither a legal responsibility nor the liability for misprints, wrong information and/or omissions or the resultant damages. Suggestions for improvement and advice are always welcome. -
Page 7: Brief Explanation Of The Industrial Terminal De-Bt 1000
1.2.1. General Explanation The industrial terminal DE-BT 1000 is a display and input terminal. As it is only a terminal, a further host system for the control is needed (e.g.: process supervisory system prosys/2). The host system transmits the messages/commands via different communication systems to the DE-BT 1000. -
Page 8: Commands
1.3.1.2. Configuration Menu By the shortcut [SHIFT] + [F8] the configuration menu of the DE-BT 1000 is reached. First you have to answer the security request „Do you really want to open the DE-BT 1000 configuration?“ with „Yes“. In case of „No“ as answer, the user returns to the main display. - Page 9 Information about the preset configuration can be displayed by [SHIFT] + [F2] in the configuration menu in case, the request was confirmed with „Yes“. Besides this information, also the current network configuration is shown. Manual Terminal DE-BT 1000 Chapter: Introduction • 5...
- Page 10 The update program is started with [SHIFT] + [F9] from the configuration menu and by confirming the appearing request with „Yes“. After that the update can be installed by the File Transfer Manager (FTM). 6 • Chapter: Introduction Manual Terminal DE-BT 1000...
-
Page 11: Status Line
Prozessautomatisierung GmbH 1.3.2. Status Line At the upper edge of the display is the status range of the DE-BT 1000. This range is consisting of one line and directly after the start it looks as follows: version communication channel messages Then the version and the communication channel are updated. -
Page 12: Menu
Description of the menu points: 1.3.3.1. START start BT1000 Selecting the first menu point „start BT1000“ the menu is left and the DE-BT 1000 application is started. 1.3.3.2. show logfile The second menu point „show logfile“ serves to show the last log-entries. They are shown in a new window. -
Page 13: Service Menu
Prozessautomatisierung GmbH 1.3.4. Service Menu In this dialog maintenance work at the DE-BT 1000 can be done. The dialog is as follows: When leaving this dialog with “Cancel” you return to the menu. Furthermore, you have the possibility to select one of the following nine menu points with “OK”. - Page 14 1.3.4.8. REBOOT reboot After selecting this menu point the terminal reboots . 1.3.4.9. HALT halt This menu point shuts down the terminal. 10 • Chapter: Introduction Manual Terminal DE-BT 1000...
-
Page 15: Chapter: Service And Technical Data
Use the direct support by e-mail with our service technician. c) Service on site You may request the help of a service technician directly at demig or at the manufacturer. This relates to all software and hardware questions. Manual Terminal DE-BT 1000... - Page 16 Prozessautomatisierung GmbH 2.1.2.1. Contact: Telephone: +49 271 77202-25 or +49 271 77202-29 Fax: +49 271 74704 E-Mail: service@demig.de URL: www.demig.com 12 • Chapter: Service and Technical Data Manual Terminal DE-BT 1000...
-
Page 17: Update Of The System Software
1. Start the FTM on the computer. 2. Set the DE-BT 1000 in the update mode, see chapter 1.3.1.7. 3. Now connect the FTM with DE-BT 1000. As it is the same procedure as for the controller, see the operation manual of the FTM. -
Page 18: Update History
Prozessautomatisierung GmbH 2.2.3. Update History Delivery date ex works: ______________________________ Software version at delivery: ______________________________ Date Installed File Software Version after Update 14 • Chapter: Service and Technical Data Manual Terminal DE-BT 1000... -
Page 19: Technical Data
Storing temperature -20...+60°C • Integrated seal at the rear of the front panel • Mounting space in the switch gear cabinet to the top and the bottom 15 cm • Manual Terminal DE-BT 1000 Chapter: Service and Technical Data • 15... -
Page 20: Pin Assignments
(min. diameter 6 mm , superiorly earth wire). 2.3.3. PIN Assignments 2.3.3.1. Serial Interfaces Male Connector: Female Connector: Pin: RS232 RS485/422 Sender Receiver 2.3.3.2. 2.3.3.3. Power Supply Pin: Ground 16 • Chapter: Service and Technical Data Manual Terminal DE-BT 1000... -
Page 21: Installation Dimensions And Measurements Of Rack-Housing
The connections of the DE- BT1000 are on the bottom side of the device. Assembly measurements: 176 x 240 x 80 mm W x H x D Wall thickness mounting 10mm max Manual Terminal DE-BT 1000 Chapter: Service and Technical Data • 17... -
Page 22: Connections
Prozessautomatisierung GmbH 2.4.2. Connections 18 • Chapter: Service and Technical Data Manual Terminal DE-BT 1000... -
Page 23: Chapter: Appendix
* ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT * (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF * THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Manual Terminal DE-BT 1000 Chapter: Appendix • 19... - Page 24 # THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT # (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE # OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. 20 • Chapter: Appendix Manual Terminal DE-BT 1000...
-
Page 25: Index
Update 6 Update History 10 Update of the System Software 13 Halt Terminal 10 Handling 13 Updatehistory 14 Information Display 5 Installation Dimension 17 Potentials 16 Installation and mounting 15 Installation Instructions 1 Manual Terminal DE-BT 1000 Index • 21...
