Fibretronic CONNECTED WEAR IPRF Manual

OPERATING RANGE

The Transmitter Module will wirelessly
commands from the keypad or joystick controller up to a
maximum distance of 10 metres from the Receiver Module.

TECHNICAL SPECIFICATION

Product Code IPRF
Transmission Radio Frequency
Frequency 433.92 MHz
Operating Range up to 10 metres
Battery CR2032 3V
iPod Connection 30 pin dock connector
Compliance FCC part 15C, CE, RoHS
iPod Compatiblity All iPods with dock connector
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must
accept any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
transmit the
The IPRF modules allow you to wirelessly control your
iPod from your garment, bag or glove. Plug the IPRF
Transmitter Module into any product that has a
CONNECTED-wear Keypad or Joystick controller.
iPod Compatibility
The IPRF Receiver Module is compatible with all
iPod players except; iPod 1st Generation, iPod
2nd Generation and iPod Shuffle. This is a
'Made for iPod' licensed product.
CONNECTED-wear, by Fibretronic, is a unique system of
integrated controls in garments, bags and other soft goods.
CONNECTED-wear Keypad and Joysticks can control audio
players, mobile phones and other personal electronics. Just
select the CONNECTED-wear module of your choice and get
CONNECTED....
www.connectedwear.com
IPRF
iPod is a trademark of Apple Inc.,
registered in the U.S. and other countries
CONNECTED-wear and Fibretronic are
trademarks of Fibretronic Limited
IPRF
wearable technology
