HANKY & PARTNERS TP-600MFVS Operation Manual

Silk screen printer
Hide thumbs

Advertisement

Quick Links

Download this manual
O
P
E
O
P
E
Silk Screen Printer
Model No.:
HANKY & PARTNERS (TAIWAN) LTD.
HANKY & PARTNERS (TAIWAN) LTD.
HANKY & PARTNERS (TAIWAN) LTD.
HANKY & PARTNERS (TAIWAN) LTD.
No.66, Wuchuan 7th Rd., Wuku Dist., New Taipei City 24890, Taiwan
Tel
+886-2-2299-3866
E-mail
info@hanky,com,tw
R
A
T
I
O
R
A
T
I
O
Fax
+886-2-2299-3868
Web http://www.hanky.com.tw
N
M
A
N
M
A
TP- - - - 600MFVS
TP
TP
TP
600MFVS
600MFVS
600MFVS
N
U
A
L
N
U
A
L

Advertisement

loading

Summary of Contents for HANKY & PARTNERS TP-600MFVS

  • Page 1 Silk Screen Printer TP- - - - 600MFVS 600MFVS 600MFVS 600MFVS Model No.: HANKY & PARTNERS (TAIWAN) LTD. HANKY & PARTNERS (TAIWAN) LTD. HANKY & PARTNERS (TAIWAN) LTD. HANKY & PARTNERS (TAIWAN) LTD. No.66, Wuchuan 7th Rd., Wuku Dist., New Taipei City 24890, Taiwan +886-2-2299-3866 +886-2-2299-3868 E-mail...

  • Page 2: Machine Introduction

    HANKY Machine introduction Model: TP -600FVS Semi-auto Silk Screen Printer(Single color). Suitable for Key board, Panel, Electric toys, Lens, Pat try Stationery etc substrate. Installation environment: 1)Ambient temperature: 0~45 ℃ (Recommended temperature 22 ℃) 2)Ambient humidity : Humidity must be below 85% without dew condensation. 3)The atmosphere at the installation site must be free of dust, mist, salt, corrosive gas, and other elements which could damage the machine.
  • Page 3 HANKY Safety manual 1. General Safety Regulations Please read this safety guidebook carefully and check safety procedures before starting any operation. Always keep this guidebook at a designated place near the machine so that it can be easily accessed whenever required. (1) If problems occur while operating the machine, please press the emergency button immediately to stop the power from running.
  • Page 4 HANKY 3. Installation 1)The foundation for machine base must be leveled and strong enough to support the machine’s weight. 2)Requirements for installation environment: 1Ambient temperature: 0~45 (Recommended temperature 2 ) ). ℃ 2 ℃ 2Ambient Humidity: Humidity must be below 85% without dew condensation. 3The atmosphere at the installation sire must be free of dust, mist, salt, corrosive gas, and other elements which could damage the machine.
  • Page 5 HANKY 13)Note the following points for trial run (1)The control panel has the manual function for operation under a trial run. (2)Ensure squeegee/ inking blade assembly is completely secured. (3)The compression force from the pad on the printing object should not be too intense. Slowly adjust into a suitable level.
  • Page 6 HANKY Installation 1. Preparation before operating the machine 2. Moving and Unpacking machine 3. Installation 1.Preparation before operating the machine (1)Other requirements Machine’s base should be at least 15cm above ground base level and should be strong enough to support the machine’s weight . It is recommended if the ground contains steel. The main power cord should be located underground and should be well covered to prevent accidents.
  • Page 7 HANKY 2. Moving and Unpacking the Machine The machine can be delivered by freight. The carrier must be a qualified person. Personnel /individuals are restricted from walking under the machine when it is lifted above air. Move machine with care to prevent strike or shock. (1)Requirements when Transporting Facilities Forklift is needed for transporting the wooden case.

  • Page 8: Level Adjustment

    HANKY 3. Installation Read this guidebook and the installation manual thoroughly and make sure the contents are completely understood to ensure personnel safety. Installation procedures (1)Level Adjustment Adjust the machine to the ground level before removing the rollers off the ground. Diagram A7 FLOOR 3-1-1.
  • Page 9 HANKY 4. Install squeegee, inking blade holder Fix the squeegee and inking blade onto the squeegee/inking blade holder. Then install the squeegee assembly to the squeegee seat. 5. Adjust squeegee/ inking blade for screen Refer to Figure A12 for adjusting the level for squeegee/ inking blade to screen. F i g u r e F i g u r e A 1 2 F i g u r e...
  • Page 10 HANKY Operation Manual Read this guidebook and the operation manual thoroughly and make sure the contents are completely understood. 1. Socket illustrate Figure.A24 103 Power Connect 104 Footswitch connect 105 Fuse 2. The The explanation of main sensor switch explanation of main sensor switch explanation of main sensor switch explanation of main sensor switch L e f t s a f e t y s e n s o r s w i t c h .

  • Page 11: Emergency Stop Switch

    HANKY 3. Operation Panel illustrate Name Name Name Name Part number Part number Part number Part number Specification description Specification description Specification description Specification description 1 1 1 1 left/rig left/right ht ht ht left/rig left/rig 15000015 Selector Switch AR22PR-211B 1A1B 2 2 2 2 Print head raising Print head raising...
  • Page 12 HANKY 4. Touch Panel Function display Footswitch lndicator S W 3 S W 1 S W 4 S W 2 No.1 Section area C O N T R O L A U T O M A N U A L D O M N S Q U E E G E E No.2 Section area...
  • Page 13 HANKY No.3 Section area Select Key : To change memory system such as quantity, speed, and print. Speed Key : Qty Set Key : Use memory system for printing 1000 pieces. After print, the machine will stop and a buzz sound will start alarming. The memory system is generally used for full automatic mode.

  • Page 14: Pressure Regulator

    HANKY 5. Preparation Before Printing (1)Check if the fuse is fixed. (2)Check if the power source is running properly. (3)Secure the air pipe. ( 4 ) C heck if the air compressor’s pressure gauge is functioning normally. (5)Inspect service unit: - (1) Filter. (2) Pressure regulator if they are functioning normally Service unit has two components: Filter –...

  • Page 15: Connect Footswitch

    HANKY 7. Sequence of machine start. (1)Machine Start and Activity Confirmation Connect the power source to the outlet ( AC 1¢ 110V/220V) . Connect footswitch. Adjust service unit’s pressure and make sure it maintains between 5~6Kg/cm If pressure is under 5Kg/cm, the machine will operate abnormally or reduce in speed. Restart the machine and power source indicator will light in red.
  • Page 16 HANKY Maintenance Description Read this guidebook thoroughly and make sure the contents are completely understood to ensure personnel safety. 1. General Operations and Maintenance Adequate maintenance is needed to ensure safety and to prolong the lifespan of the machine. Components may start to wear out at the initial stage after setting up the machine into use. Lubricate the components regularly.
  • Page 17 HANKY 2. Daily Inspection and Maintenance Follow the maintenance manual for regulated maintenance. The machine has to be Inspected and maintained under power on condition. Please contact with your local electricity regulators for enquiry. (1)Daily Maintenance Inspection The operator mainly needs to clean and examine the machine if it is functioning normally. Please refer to table 2-1.
  • Page 18 HANKY 3. Elimination of Breakdown (1) The causes of problems and methods of solution Problem Cause Solution Sliding part’s cylinder Cylinder air leakage Replace cylinder moving Cylinder (moves Magnet of cylinder take off Replace cylinder horizontally) moving Solenoid valve is unable to Solenoid valve’s seal damaged Replace solenoid valve’s seal perform interchange action...
  • Page 24 Part No. Q'ty C400090041 35410011 C400090030 C400090020 台灣恒基股份有限公司 Ass'y TEL:(02)2299-3862 Dwg No.: C0009-W-010 Scale: Dwg By: Henry FAX:(02)2298-8132 HANKY & PARTNERS (TAIWAN) LTD.
  • Page 26 Part No. Q'ty C400310050 C400130050 C400310040 C400130100 C400130110 C400410050 C400410060 C400410040 C400310080 10 N597220149 11 C400130090 台灣恒基股份有限公司 Ass'y Dwg No.: C0041-H-010 Scale: 1:10 Dwg By: Henry HANKY & PARTNERS (TAIWAN) LTD.
  • Page 27 Part No. Q'ty 04244330 04244340 04244350 04260181 04260931 05200151 15000051 35410011 55030032 55101003 55103213 台灣恒基股份有限公司 Ass'y TEL:(02)2299-3862 Dwg No.: TP4-D-060 Scale: Dwg By: Henry FAX:(02)2298-8132 HANKY & PARTNERS (TAIWAN) LTD.
  • Page 28 Part No. Q'ty 04115641 04200262 04115651 15600049 04115660 04000260 04115630 台灣恒基股份有限公司 Ass'y TEL:(02)2299-3862 Dwg No.: TP4-D-070 Scale: Dwg By: Henry FAX:(02)2298-8132 HANKY & PARTNERS (TAIWAN) LTD.
  • Page 29 Part No. Q'ty 04240021 04240013 04240034 Ass'y 台灣恒基股份有限公司 TEL:(02)2299-3862 Dwg No.: TP5-A-03_D Scale: Dwg By: Henry FAX:(02)2298-8132 HANKY & PARTNERS (TAIWAN) LTD.
  • Page 30 Part No. Q'ty 04260007 04260010 04260021 45215000+45040201 台灣恒基股份有限公司 Ass'y TEL:(02)2299-3862 Scale: 1:12 Dwg No.: TP6-A-01_E Dwg By: Cindy FAX:(02)2298-8132 HANKY & PARTNERS (TAIWAN) LTD.
  • Page 31 編號 料號 數量 04115510 04115530 04115540 04115550 04115681 04115691 04240682 04244220 04244230 04244240 04244250 04244440 04244470 04244480 04260512 05060040 05260070 25000100 25010028 35380086 45280020 C497250151 台灣恒基股份有限公司 組 TEL:(02)2299-3862 圖號: 比例: TP6-B-07_D 繪圖: Cindy FAX:(02)2298-8132 HANKY & PARTNERS (TAIWAN) LTD.
  • Page 32 Part No. Q'ty 04240084 04240101 04240190 04240123 04240132 04240150 04260031 04240142 04240160 04240205 04240670 04244522 05050620 05051102 05200101 16 C497240041 05240191 45220002 45270062 55080004 55002005 55103248 55103247 04244531 55103300 Ass'y 台灣恒基股份有限公司 TEL:(02)2299-3862 Dwg No.: TP6-C-010_D Scale: Dwg By: Henry FAX:(02)2298-8132 HANKY &...
  • Page 33 Part No. Q'ty 04000341 04000391 04000720 04240450 04240460 04240471 04240480 04240490 04240560 04240570 04240581 04240591 04240602 04240610 04240620 04240630 04240770 04240780 04243740 04260211 05014150 05240791 45270024 55003001 55103022 台灣恒基股份有限公司 Ass'y TEL:(02)2299-3862 Dwg No.: TP6-D-040_B Scale: Dwg By: Henry FAX:(02)2298-8132 HANKY & PARTNERS (TAIWAN) LTD.
  • Page 34 Part No. Q'ty 04240682 04240770 04240780 04240850 04240860 04240873 04240880 04240900 04240910 04260242 04260260 05240791 45280022 55001009 55103049 C400410100 C400410110 Ass'y 台灣恒基股份有限公司 TEL:(02)2299-3862 Dwg No.: TP6-F-021 Scale: Dwg By: sung bor Lan FAX:(02)2298-8132 HANKY & PARTNERS (TAIWAN) LTD.
  • Page 35 Part No. Q'ty 04240682 04240770 04240780 04240873 04240890 04240910 04240930 04260242 04260270 05012002 05240791 C400410100 C400410110 台灣恒基股份有限公司 Ass'y TEL:(02)2299-3862 Scale: Dwg No.: TP6-F-03_A Dwg By: Cindy FAX:(02)2298-8132 HANKY & PARTNERS (TAIWAN) LTD.

  • Page 36: Product Name

    HANKY Material Name Specification list ： NO. Part No. Product Name Specifications 04000250 Locking Washer φ20x2 04000260 SUS304 φ10x12 04000341 Positioning Handle for Guide Rod S45C 04000391 Micro-adjustment Screw 04000720 Washer 04115510 Pulley P20-T10-25-6F 04115530 Pulley P20-T10-25-33F 04115540 Clip Plate for Belt (A) T6 9x48.5x102 04115550 Clip Plate for Belt (B)
  • Page 37 HANKY 04240490 Fixing nut M16x1.5 Black Fixing Block for Squeegee Holder 04240560 SS41 Bracket 04240570 Black Link Plate for Squeegee Holder Bracket SS41 04240581 Squeegee Holder Bracket SS41 04240591 Ling Block for Squeegee Holder Bracket SS41 04240602 Adjustment Ring S45C 04240610 Fixing Holder 30x40x280...
  • Page 38 HANKY 04242662 Ink Blade 20CM T6 36x78x350 A3 04242682 Ink Blade 30CM T6 36x78x350 A3 04242702 Ink Blade 40cm 36x78x430 A3 04243741 Printing Head 04243754 Vacuum Seat 04244220 Fixed Plate for Screen Frame Holder T6 22x120x200 A2 04244230 Shaft for Gear SUS 304 04244330 Bracket...
  • Page 39 HANKY 115. 05200101 Hand Wheel 3070-125-B12.7 1013-21-M8 116. 05200151 Handle Screw #42 M6x30 117. 05240191 Handle Screw #80 M10x65 118. 05240231 Handle Screw #65 M8x55 119. 05240791 Handle Screw #65 M8x30 120. 15000005 Micro Switch Z-15GQ22-B 15A Z-15GQ22-B 15A 121. 15000011 Micro Switch AH-74555...
  • Page 40 HANKY 152. 15328918 PC Board HC-20103 SA-24V HC-20103 SA-24V 153. 15328919 Motor Speed Control Board HC-20106 154. 15328920 Speed Control HC-20105(TS 20105) 155. 15328921 Cable HC-20P115CM 156. 15400001 Power Cord LT-501+LT-202 L:1.8M 157. 15400008 Power Cord for Foot Pedal WTP-002(1.7M) 158.
  • Page 41 HANKY 191. 45270024 C type Ring RTW-24 RTW-24 192. 45270062 C type Ring RTW-62 RTW-62 193. 45280020 C type Ring STW-20 STW-20 194. 45280022 C type Ring STW-22 STW-22 195. 45291013 Hose Lock 1/2" 15mm 196. 45291051 Restrain Ring φ51mm φ51mm 197.
  • Page 42 HANKY 226. 55200801 Straight Joint C-801 1/8 PU6 C-801 1/8 PU6 227. 55200802 Straight Joint C-802 1/4 PU6 C-802 1/4 PU6 228. 55210601 Bent Joint L-601 1/8 PU4 L-601 1/8 PU4 229. 55210802 Bent Joint L-802 1/4 PU6 L-802 1/4 PU6 230.
  • Page 43 HANKY 265. C9100160 Sensor Block (Right) 266. C9100180 Sleeve S45C 267. G-500X700 Vacuum Plate 500x700 φ1.5 268. R5621045 Spring 30mm 5/13/2014 8 of 8...
  • Page 44 HANKY Tool Box Material Name Specification Tool Box Material Name Specification L L L L ist ist : : : : Tool Box Material Name Specification Tool Box Material Name Specification Q Q Q Q ’ ’ ’ ’ ty ty ty ty NO.
