5Pascal LIOSMART 100 User Manual

Freeze dryer

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

User Manual

FREEZE DRYER

LIOSMART 100

January, 2020

Table of Contents

Need help?

Do you have a question about the LIOSMART 100 and is the answer not in the manual?

Questions and answers

Summary of Contents for 5Pascal LIOSMART 100

Page 1 User Manual FREEZE DRYER LIOSMART 100 January, 2020...
Page 2 Warranty is valid for 13 months from date of shipping and includes spare parts and labor. Type: LIOSMART 100 Serial number: 19116384 Date of shipping: Signature/Stamp: Manufacturer: Cinquepascal S.r.l...
Page 3: Table Of Contents
User Manual LIOSMART 100 CONTENT 1.0 WARNINGS AND SAFETY PRECAUTIONS ...................... 4 2.0 INTRODUCTIONS ............................5 3.0 TECHNICAL DATA ............................6 4.0 USE PURPOSE AND SAFETY ELEMENTS ..................... 13 5.0 INSTRUCTION FOR USE ..........................14 5.1 Vacuum pump ............................14 5.2 Control panel ............................
Page 4: Warnings And Safety Precautions
User Manual LIOSMART 100 WARNINGS AND SAFETY PRECAUTIONS READ ALL INSTRUCTIONS BEFORE USE! Reduce the possibility of injury and failure! WARNING Before you perform any kind of maintenance, disconnect all electrical power to the unit! DO NOT operate this unite without a properly grounded,...
Page 5: Introductions
User Manual LIOSMART 100 INTRODUCTIONS Appliance description Controller This unit is equipped with microprocessor controller which is specially designed for automatization of freeze drying cycles. Controller enables 50 different programs. Each of these 50 programs has ability to set 50 different cycle steps.
Page 6: Technical Data
User Manual LIOSMART 100 TECHNICAL DATA LIOSMART 100 Exterior dimensions (W x D x H) 1400 X 2178 x 1920 mm Chamber dimensions (W x D x H) 750 x 1400 x 1000 mm Ice condenser capacity 100 kg Condenser...
Page 7 User Manual LIOSMART 100 Dimensional drawing:...
Page 8 User Manual LIOSMART 100 Dimensional drawing - shelves view:...
Page 9 User Manual LIOSMART 100 Connections:...
Page 10 User Manual LIOSMART 100 Shelves removal at maintenance: 1. Switch off device 2. Remove trays (use rod for tray removal) 3. Close all 4 ball valves at shelves connections 4. Disconnect flexible tubes (tri-clamp TC 50.5 connections) 5. Connect trolley to chamber (use two trolley safety bolts) 6.
Page 11 User Manual LIOSMART 100 Shelves lock mechanism Tri-clamp Flexible tube Flexible tube Tri-clamp Ball valve Ball valve Ball valve Ball valve...
Page 12 User Manual LIOSMART 100 Trolley safety bolt Shelves safety bolt Trolley...
Page 13: Use Purpose And Safety Elements
User Manual LIOSMART 100 USE PURPOSE AND SAFETY ELEMENTS This freeze dryer is designed and build for many pilot and research or even small production purposes. Given the wide scope of specification, appliance is useful in many areas as, pharmacy, food industry, biotechnology, …...
Page 14: Instruction For Use
User Manual LIOSMART 100 INSTRUCTION FOR USE ATTENTION: Safety gloves use is a must when working with high/low temperatures! Transport is usually carried in the original packaging. In case that the appliance has to be replaced, it must be manually placed on a transport palette and only then lifted and transported with a vehicle.
Page 15: Control Panel
User Manual LIOSMART 100 5.2 Control panel Manual cycle Automatic cycle Cycle ended Error Settings ON Printer ON (Printer error if light flashes) Confirmation Main menu Start program Stop program Value increase/decrease Clear Nun pad Exit form menu Parameter selection...
Page 16: Display
User Manual LIOSMART 100 * An operation is currently running if a function on the screen is colored in yellow. Example: Gas inlet is ON  5.3 Display Tsh … current shelf temperature P … current/ set pressure in chamber Tm …temperature on material probe...
Page 17: Program Selection And Start
User Manual LIOSMART 100 5.5 Program selection and Start Turn on the main switch Display: Tsh = 15.6°C …current shelve temperature Tc = 19°C …current condenser temperature P = 1015.0mb …current vacuum / pressure in chamber Pp = 1015.0mb … current vacuum / pressure in vacuum pump Tm = 13.1°C...
Page 18 User Manual LIOSMART 100 Press To choose between programs press on the number (below display) or use and press In the process Meaning: STEP Nr: 1: 10:00 First step in the process. Time set to 10 minutes [when temperature reaches the tolerance area and parameter Tsh/Tm in in set limit the time count down starts.
Page 19: Settings
User Manual LIOSMART 100 SETTINGS Parame Press to enter main menu Display: If you press the number next to the written description you enter the described sub menu. Press ATTENTION: If you press 2 – MANUAL manual program starts immediately! Parameters for manual...
Page 20 User Manual LIOSMART 100 1. Select program  Select desired program to set settings. Program 0 is reserved for manual program 2. Program name  Enter program name (the selected program can be named). Use numpad to enter letters and numbers 3.
Page 21 User Manual LIOSMART 100 8. Recording period  Recording interval can be set from 1 in 200 minutes or switched off ATTENTION: If you set value lower than 1 minute recording is set to OFF!
Page 22 User Manual LIOSMART 100...
Page 23: Parameter Settings - Automatic Program
User Manual LIOSMART 100 Parame These parameters are set for each step! 1. Choose desired program to set settings:  choose program from 1-50 To change program number press 2. Program name  Enter program name (the selected program can be named). Use numpad to enter letters and numbers.
Page 24 User Manual LIOSMART 100 4. Recording period:  Here you can set the printing interval for printer. You can set the interval from 1 min to 200 min. If printer is not connected to the machine printing should be switched off = 0 min! To change value press 5.
Page 25: Special Setup
User Manual LIOSMART 100 SPECIAL SETUP Special Setting Press to enter main menu Display: Press number to enter special setup menu Display Press number to enter sub menu time setup Display To change value under blinking line press , to move blinking line press...
Page 26: Corrections Setup
User Manual LIOSMART 100 Correct ions To enter this menu press button. Display: Press to enter special setup menu Display: Press to enter correction setup menu To enter correction setup during program in operation hold for app. 10s.! If password protection is active you must enter password:...
Page 27: Corrections Setup Scheme
User Manual LIOSMART 100 Correct ions...
Page 28 User Manual LIOSMART 100 1-4: Temperature shelve probe correction  4 corrections points are defined. (-40, 0,+30,+70) For each correction point correction can be set. To change value use 5-8: Material temperature probe correction probe  For material temperature , 4 corrections points are defined.
Page 29 User Manual LIOSMART 100...
Page 30: Special Setup - User Passwords
User Manual LIOSMART 100 Special Setup – To enter this menu press button. Display: Press to enter special setup menu Display: Press to enter user passwords setup menu WARNING: Changing passwords is enabled only with the administrator password login! OPERATOR PASSWORD SETUP: We have passwords for two operators.
Page 31 User Manual LIOSMART 100 ADMINISTRATOR PASSWORD SETUP: PASSWORDS SETUP 5 – ADMINISTRATOR PASSWORD : 5*** NAME : 5 We have one administrator password. The administrator password allows us to access and modify all settings. WARNING: If the administrator password is set to 0000, are all passwords turned off! 7.5 Special Setup –...
Page 32: Service And Maintenance
User Manual LIOSMART 100 SERVICE AND MAINTENANCE WARNING In case of maintenance interventions, disconnect all electrical power to the unit! Maintenance and service within the warranty period may only be performed by the authorized service person. Please advise manufacturer in before alternation & modification. It is not allowed to change or rebuild any part of the construction without producer's written permit.
Page 33: Required Space And Connections
User Manual LIOSMART 100 REQUIRED SPACE AND CONNECTIONS The appliance must be installed at least 500 mm away from the nearest wall. It must also be in a dry and well ventilated room. Additional space or relocation of the apparatus may be necessary when carrying out any maintenance or servicing.
Page 34: Dismantling And Disposal
User Manual LIOSMART 100 10.0 DISMANTLING AND DISPOSAL This symbol means do not dispose of your product with your other household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment.
Page 35: Attachments
User Manual LIOSMART 100 ATTACHMENTS 11.1 CE declaration of conformity 11.2 Electro diagram...
