Summary of Contents for StellaX ZoomX X-003
- Page 1 CREATED BY STELLAX COMPANY -003 Instruction Manual for Monocular MONOCULAR 10x42 waterproof...
-
Page 2: Table Of Contents
www.zoomx.company CONTENTS Instructions for use • Information for Your Safety • Risk of Swallowing • Eyecup Adjustment • Focus Adjustment • Objective Lens Cover Setting up the Smartphone Adapter How to Attach the Tripod Care and Maintenance Waterproof/Fog-proof Information Warranty... -
Page 3: Instructions For Use
Instruction for use Congratulations on purchasing your new ZoomX «X-003» monocular. Enjoy the sharp, bright, high-resolution view offered by these outstanding optics. Follow the instructions for use and your product will be a reliable companion for many years to come. Information for your safety Do not, under any circumstances, look through the monocular at the sun or laser light sources! - Page 4 Tripod Adapter Eyepiece cover Socket with 1/4” threads (under the screw) Ocular Lens (Eyepiece) Focus Knob Objective Tripod lens cover...
-
Page 5: Eyecup Adjustment
Eyecup Adjustment Eyecup in «Up» Position Eyecup in «Down» Position (for use without eyeglasses) (for use with eyeglasses) Pic. 1 Pic. 2 Your ZoomX «X-003» monocular is fitted with twist-up eyecup that provide a comfortable view of the full image and help to exclude extraneous light. For use without eyeglasses or sunglasses, twist the eyecup upwards, rotating it counter-clockwise until it lock into the fully «Up»... -
Page 6: Focus Adjustment
Focus Adjustment Focus wheel To obtain a sharp view through your monocular, you need to adjust the focus. Rotate the focus wheel until you have a sharp image. Hint: Eyeglasses worn for nearsightedness should be worn when using monoculars, as you may not be able to reach a sharp focus at infinity without them. -
Page 7: Objective Lens Cover
Objective Lens Cover When using your «X-003» monocular, flip open objective lens cover. prevent accidental loss, the cover is tethered to (remov- able) rubber security ring. When you have finished using the monocular, put the cover back in place to protect the monoculars' lens. - Page 8 Smartphone Adapter How to use the Smartphone Adapter with iPhone Align the camera Tighten the locking bolt Set your smartphone Align the hole of the adapter to Smartphone Adapter. with the camera of your smartphone. Tighten the locking bolt.
- Page 9 Attach the smartphone adapter Remove the front cover cap to the monoculars’ eye socket. from the monoculars’ lens. Turn on the camera Zoom in a little on your smartphone of your smartphone. to get a rectangular image.
-
Page 10: Setting Up The Smartphone Adapter
Setting up the Adapter for Dual-Camera Smartphones Some smartphones have two or more cameras on the back of the device. For example: Apple iPhone 8 Plus, Apple iPhone XS Max To connect your smartphone to the smartphone adapter, you need to use the main camera. -
Page 11: How To Attach The Tripod
How to Attach the Tripod Remove the screw from the Tripod Adapter Socket Mount the tripod into the adapter socket Pull out the extension legs... -
Page 12: Care And Maintenance
Care and Maintenance First, blow or brush away any dust or debris on the lens (using «canned air» or a soft lens brush). To remove dirt or finger prints, clean with the supplied soft storage bag (made of washable micro-fiber cloth), rubbing in a circular motion. -
Page 13: Waterproof/Fog-Proof Information
Waterproof/Fog-proof Information IPX7 Your ZoomX «X-003» monocular has been designed and built utilizing the latest waterproof and fog-proof technology. Fog-proof protection is achieved from dry nitrogen purging that removes all internal moisture. -
Page 14: Warranty
Activate your Lifetime Warranty: www.zoomx.company/warranty Or scan this QR code You should do this immediately: The product must be registered within 20 days of purchase. ZoomX product line belongs to the StellaX trademark.
