Installation Manual: Easy Grow A48 (48 Planter) structure system
READ THIS DOCUMENT BEFORE YOU BEGIN
Thank you for purchasing Easy Grow A48 hydroponic system. When properly assembled and maintained,
this system will provide years of reliable service. These instructions include helpful hints and important
information needed to safely assemble and properly maintain the system. Please read these instructions
before you begin.
If you have any questions during the assembly, contact Customer Service at +91 77859-77859 for
assistance.
UNPACK AND IDENTIFY PARTS
1. Unpack the contents of the shipment and place where you can easily inventory the parts. Refer to the
Bill of Materials/Spec Sheets.
2. Verify that all parts listed on the Bill of Materials/Spec Sheets are present. If anything is missing or you
have questions, consult the Pictorial Parts Guide and all diagrams for clarification, or contact Customer
Service.
PICTORIAL GUIDE
The following graphics and photos will help identify different parts of the EASY GROW hydroponic
system. (Some parts may not be shown)
1) A shape Iron frame Qty - 2
3) 75mm Pipes connected with Reducers and 2'' Pipes Qty – 8
5) Water Pipe T Connector Qty – 1
2) 43'' connectors for Iron Frame Qty - 2
6) Water Pipe Nozzle Qty – 2
4) 40mm Pipe connectors Qty - 6
Advertisement
Table of Contents
Summary of Contents for AgroArt Easy Grow A48
- Page 1 Installation Manual: Easy Grow A48 (48 Planter) structure system READ THIS DOCUMENT BEFORE YOU BEGIN Thank you for purchasing Easy Grow A48 hydroponic system. When properly assembled and maintained, this system will provide years of reliable service. These instructions include helpful hints and important information needed to safely assemble and properly maintain the system.
- Page 2 7) 75mm End caps Qty – 2 8) Drainage Pipe Connector Qty - 1 Getting Started Assembly Procedures Step 1: Assemble the Iron Frame Stand. Use the A shape Iron frame (1) and connect it with 43’ connectors (2). See the red circles in below image to see how to connect it exactly. Connect both the connectors. 43’’...
- Page 3 75mm pipe Reducer 40mm pipe 75mm pipe connector 43’’ connectors Step 3: Connect the other connectors also in the same way as shown below. Also fix the other side in same manner. 40mm pipe connector 40mm pipe connector 75mm pipe Step 4: Connect the water pipe T connector (5) with water pipe nozzle (6) on both of the top pipes as shown below.
- Page 4 Water pipe T connector Water pipe T connector Water pipe Nozzle Water pipe Nozzle 75mm End caps Step 5: Connect the Drainage pipe (8) and attached it to the reservoir bucket and motor. Fill bucket reservoir with Water and Nutrients as per the Nutrients Guide given. See the below images. Bucket Motor Drainage Pipe...
- Page 5 A Shape NFT Step 6: Fill Net Pots with clay pebbles and plants and put it into the spaces/holes given in pipes. Make sure to keep the roots outside the net pots so that plant root touches the water flows into the pipes.
